<h2>This is the MPCNC from VH1 (https://docs.v1e.com/mpcnc/intro)</h2><h2>Mostly Printed CNC / Multi-Tool</h2>These parts are for 23.5mm OD conduit. 25mm OD here-<a target="_blank" href="https://www.thingiverse.com/thing:790533" rel="nofollow noopener">http://www.thingiverse.com/thing:790533</a> 25.4mm OD here- <a target="_blank" href="https://www.thingiverse.com/thing:1671517" rel="nofollow noopener">http://www.thingiverse.com/thing:1671517</a>Changelog 10/15/18 - BURLY Center Revisions 3/19/18 - New foot design. 5/9/17 - New XYZ Part to allow for T8 Leadscrew driven Z axis. 7/13/16 - New Roller Assemblies. New size added. 5/25/16 - New Center and Z Axis assemblies, universal tool mount. 4/24/16 - New Corner assembly.The "MPCNC" a minimal cost CNC machine that is easily sourced worldwide and can easily swap out its functionality.For More Information and to purchase parts please visit, <a target="_blank" href="https://www.v1engineering.com/" rel="nofollow noopener">https://www.V1Engineering.com/</a>Printing info <a target="_blank" href="https://www.v1engineering.com/blog/parts/" rel="nofollow noopener">https://www.V1engineering.com/blog/parts/</a>Please ask all questions in the forums, or help out if you can. The forums are extremely active and very beginner friendly. <a target="_blank" href="https://www.v1engineering.com/forum/" rel="nofollow noopener">https://www.v1engineering.com/forum/</a>The only special tools needed are a hacksaw, and a drill to for 4 holes.This can be easily expanded to almost any length, width, and depth depending on rigidity required. Shorter lengths = more rigid. This is built using hardware store emt conduit (In the US it is sold as 3/4" (ID)), or as an upgrade you can use stainless steel tubing.Most woods and plastics should be no problem, <a target="_blank" href="https://youtu.be/Ub2qablc-GE" rel="nofollow noopener">https://youtu.be/Ub2qablc-GE</a>. I milled Aluminum with a footprint of 23.5in x 32in x 4in. Aluminum works well <a target="_blank" href="https://youtu.be/BRFeZESDo4k" rel="nofollow noopener">https://youtu.be/BRFeZESDo4k</a> Yes, even some Steel <a target="_blank" href="https://youtu.be/1CX3qui0-Yo" rel="nofollow noopener">https://youtu.be/1CX3qui0-Yo</a>.You can switch the spindle out with a drag knife, laser, Extruder, ect, making it a great prototyping multi-tool. By adding length and depth It could easily be used to shape large easily milled things like wood, foam, or plastics. Keep it small for metals.<h2>Add Ons</h2>Dual End Stop Mounts <a target="_blank" href="https://www.thingiverse.com/thing:2847042" rel="nofollow noopener">https://www.thingiverse.com/thing:2847042</a>MK8 MK9 extruder mount 3D printer <a target="_blank" href="https://www.thingiverse.com/thing:868983" rel="nofollow noopener">http://www.thingiverse.com/thing:868983</a>Dewalt DW660 Mount <a target="_blank" href="https://www.thingiverse.com/thing:944952" rel="nofollow noopener">http://www.thingiverse.com/thing:944952</a> <a target="_blank" href="http://amzn.to/1D7xByM" rel="nofollow noopener">http://amzn.to/1D7xByM</a>DW660 perpendicularity tester <a target="_blank" href="https://www.thingiverse.com/thing:1525661" rel="nofollow noopener">http://www.thingiverse.com/thing:1525661</a>Pen Mount <a target="_blank" href="https://www.thingiverse.com/thing:1612207" rel="nofollow noopener">http://www.thingiverse.com/thing:1612207</a>Blank Tool Mounts <a target="_blank" href="https://www.thingiverse.com/thing:805803" rel="nofollow noopener">http://www.thingiverse.com/thing:805803</a>Laser (Leo69) Mount <a target="_blank" href="https://www.thingiverse.com/thing:1636811" rel="nofollow noopener">http://www.thingiverse.com/thing:1636811</a>If what you are looking for isn't here search "MPCNC"<h4>Print Settings</h4><ul><li>Printer:</li></ul>MP3DP<ul><li>Rafts:</li></ul>Doesn't Matter<ul><li>Supports:</li></ul>No<ul><li>Infill:</li></ul>See http://www.vicious1.com/blog/parts/<ul><li>Filament brand:</li></ul>Doesn't matter<ul><li>Filament material:</li></ul>PLA<h4>Instructions</h4>&nbsp;Wood Demo <a target="_blank" href="https://youtu.be/j_O9fbzjSn8" rel="nofollow noopener">https://youtu.be/j_O9fbzjSn8</a>3D Printing <a target="_blank" href="https://youtu.be/amo8czFC75Y" rel="nofollow noopener">https://youtu.be/amo8czFC75Y</a>4 Head Madness! Just to show the platforms capabilities. <a target="_blank" href="https://www.youtube.com/watch?v=DeVeyUas5vU" rel="nofollow noopener">https://www.youtube.com/watch?v=DeVeyUas5vU</a><h2>Electronics</h2>I am using marlin, there are a lot of options if you don't like this, grbl, tiny g, ect.The X and Y steppers are wired in Series or Individually. <a target="_blank" href="http://www.vicious1.com/ramps-wiring/" rel="nofollow noopener">http://www.vicious1.com/ramps-wiring/</a>Pre-configured firmware here- <a target="_blank" href="http://www.vicious1.com/marlin-firmware/" rel="nofollow noopener">http://www.vicious1.com/marlin-firmware/</a><h2>Bill Of Materials</h2>Current List - <a target="_blank" href="http://www.vicious1.com/blog/parts/" rel="nofollow noopener">http://www.vicious1.com/blog/parts/</a><h2>Software</h2>3d CAM<a target="_blank" href="http://www.estlcam.com/" rel="nofollow noopener">http://www.estlcam.com/</a> Looks like we have a winner! Free full featured, consider buying it for $50. Clean and simple. <a target="_blank" href="http://www.vicious1.com/estlcam-basics/" rel="nofollow noopener">http://www.vicious1.com/estlcam-basics/</a>Controller <a target="_blank" href="http://www.repetier.com/" rel="nofollow noopener">http://www.repetier.com/</a> Right now I use Repetier-Host <a target="_blank" href="http://www.vicious1.com/repetier-host/" rel="nofollow noopener">http://www.vicious1.com/repetier-host/</a>Fusion 360 for the intermediate users with some experience.Many others work as well.&nbsp;

Mostly Printed CNC "MPCNC" BURLY C-23.5mm OD

machines and such

Maker1O1

Originally made by Boxandloop and licensed under CC-BYModified for cheaper servos by 3dxav- download the DocumentationOptimized for fast printing on Bambulab P1 / X1 DOME01 and brow_side is cutted in half, for easier printing, those need to be glued together.&nbsp;Original author:Iron Man MK5 HelmetUpdate 2: Uploaded mk5_sketch_ADJUSTABLE code file. With this file you can adjust global and individual servo movement. Line 6-7 --> Adjust overall movement of small servos. Do not make large changes (over 25-50) because the servos will be taken pass their physical ranges and damage can happen. Lines 27-38 --> Adjust each servo. Do not make large changes for main servos (over 100) for same reasons.Update: Apologies, uploaded an older version of code. Uploaded the correct version - mk5_sketch_11-28-2021.inoFully articulated, Wearable, Chargable. Easy to print, harder to build. Step by step guides are here to help you.While download is broken, please find files and extras here: <a target="_blank" href="https://thangs.com/m/35449" rel="nofollow noopener">https://thangs.com/m/35449</a>Video Guide: <a target="_blank" href="https://youtu.be/0pcbx-TdSnw" rel="nofollow noopener">https://youtu.be/0pcbx-TdSnw</a> Helmet in Action: <a target="_blank" href="https://youtu.be/f6bQGWkdc1A" rel="nofollow noopener">https://youtu.be/f6bQGWkdc1A</a>What's included: 28 STL files 3 Guides (build, wiring, printing) 1 Code file 1 Parts listFeatures: 10 servos driving the action of 10 parts in the facemask. Single powerbank drives everything and can be recharged while still inside, no batteries needed. 2 power switches, one for Arduino, one for Servos. Trigger is located in the chin. Wire management.Enjoy this build! If you really enjoyed, consider buying me a coffee: <a target="_blank" href="https://www.buymeacoffee.com/BoxAndLoop" rel="nofollow noopener">https://www.buymeacoffee.com/BoxAndLoop</a>FAQ: Can I scale this helmet? No, nope, not a chance. How big is this helmet? Will it fit my head? There is a "cage" you can print to test for fit. Can I see through the eyes? Yes, but not in the dark. Can I dim the eyes down? Not in this version, maybe in the future. Why do all the servos buzz when the helmet is open? 9g servos are not strong enough to keep everything open without power. Keeping the power to servos creates buzz. How long does one charge last? Not sure, but it is in the hours, not in minutes. How long will it take to print everything? Depends on your printer and nozzle size. On my Ender 5Pro with a 0.6mm nozzle, total print time is about 48 hours. How much filament do I need? 1kg roll should cover it all.
