TeckMec

Benjamin Kott

<p><span style="color:#E14747;"><i>This model is intended for continual development, fostering openness. If you have suggestions or requests, please share them in the comments or via direct message. <strong>Please do not upload different sizes as remixes</strong>, add it as a profile instead here - better ask for it and I will do it for you and also maintain the profile. If you like it, press the button!</i></span></p><h2>Display Case (Fully Parameterized)</h2><p>In the process of reorganizing my assortment of Designer Toys, Transformers, and various Collectibles, I sought out a display solution that offered both illumination and versatility. Opting to craft my own, I present to you my interpretation of a display case. While it may not redefine the landscape of display cases, it effectively addresses my needs – and perhaps it could serve yours as well.</p><h3><strong>Design Decisions</strong></h3><p>In my quest for the ideal display case, I outlined several key requirements to ensure functionality and practicality:</p><ul><li><strong>Printability: </strong>The design should facilitate efficient printing within a reasonable timeframe, ensuring convenience and accessibility.</li><li><strong>Ease of Assembly:</strong> Simple construction and assembly procedures are essential for a hassle-free experience, allowing for quick setup and utilization.</li><li><strong>Utilization of Plexiglass/Acrylic Sheets:</strong> Taking advantage of readily available Plexiglass/Acrylic sheets found on platforms like Amazon, the case design accommodates common materials for widespread accessibility.</li><li><strong>Illumination Capability:</strong> Incorporating provisions for illumination, the case enhances the presentation of collectibles, offering optimal visibility and aesthetic appeal.</li><li><strong>Customizability:</strong> Designed with scalability in mind, the case offers flexibility for future expansion or modifications, enabling personalized adjustments as collections evolve.</li><li><strong>Aesthetic Appeal: </strong>With a focus on visual appeal, the design ensures that the display case complements its surroundings, appealing to both practical and aesthetic sensibilities – ensuring the approval of discerning partners like my wife.</li><li><strong>Light Blocking Connections:</strong> To maintain the integrity of the display, the connections should effectively prevent light from passing through, ensuring minimal interference with the presentation of collectibles.</li></ul><p>By adhering to these criteria, the resulting display case not only fulfills my specific requirements but also provides a practical solution adaptable to diverse needs and preferences.<br><br><i>Avoid using images featuring Transformers or similar collectibles to seek your wife's approval, as it may not resonate positively with all tastes. In my experience, approval was granted only after removing the Transformer from the display case. </i>🤣</p><h3>Printing</h3><p>Each component is meticulously designed to be printed without the need for support structures. While certain sections, such as the bars and corners, may exhibit slight imperfections due to overhangs, it's important to note that these imperfections are not visible upon assembly. Additionally, these minor irregularities enhance the grip and friction of the connectors.</p><p>&nbsp;</p><p>Example: This part is not visible after assembly.<br><br><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_6b74438b1ad6a.jpg"></p><p>&nbsp;</p><p>It's essential to consider that the name of the print profile corresponds to the specific sheets required for assembly. Each profile includes a complete set of components, and the estimated print time provided is realistic.</p><p><br>Example: <br><strong>20 x 15 cm x 2-3mm - Sheet Size</strong><br>Will require 4 sheets sized 20 x15 cm x 2mm to a max of 3mm ( If you plan to add sheets )<br>Like: <a target="_blank" href="https://amzn.eu/d/aHx4c2u" rel="nofollow noopener">https://amzn.eu/d/aHx4c2u</a></p><p><br><i>The provided profiles have the max value set, supporting more variants to avoid spamming profiles.</i></p><p><i><strong>Please let me know if you would like to see additional sizes.</strong></i></p><h4>Led Cable Guide</h4><p>It depends on how and if you want to add illumination. I opted not to provide any preset holes to guide the cable through.<br>Instead please add them directly in the slicer to match your needs.<br><br><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_09474d7e0141.png"></p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_4ad83af5f8bba.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_230151c47c34b.png"></figure><h3>Model</h3><p>The model offers full customization to accommodate diverse needs and various sheet sizes available in the market. If you believe a different sheet size could benefit others, I'm happy to extend the provided profiles and handle the adjustments using Fusion Sources. While some parameters are marked as favorites for easier adjustment, every aspect of the model is parameter-based and can be fine-tuned according to your requirements.<br><br>- <strong>glass_face_width: </strong>glass panel width on the front<br>- <strong>glass_side_width: </strong>glass panel width on the side<br>- <strong>glass_height: </strong>general glass panel height</p><p>&nbsp;</p><figure class="media"><div data-oembed-url="https://youtu.be/GU8QqESnBO0"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/GU8QqESnBO0" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure><figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_e6f18cecc059.png"></figure><p>Assembled View</p></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_45711d8899c9e.png"></figure><p>Explosion View</p></td></tr></tbody></table></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_d01c1f4cd47b5.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_03170aa7e4c9d.png"></figure><h3>Components</h3><h4>Bars and Corners</h4><p>The bars and corners are thoughtfully designed with chamfered edges, effectively preventing light from passing through. They fit together seamlessly, creating a cohesive structure. Additionally, they incorporate a channel specifically for LED strips, accommodating widths of up to 14mm with a +2mm tolerance.</p><p>&nbsp;</p><p><span style="background-color:rgb(255,255,255);color:rgb(17,17,17);font-size:16px;">The bars feature slots, allowing you to </span><strong>customize</strong><span style="background-color:rgb(255,255,255);color:rgb(17,17,17);font-size:16px;"> your display case. You can either use the </span><strong>included inlay holders</strong><span style="background-color:rgb(255,255,255);color:rgb(17,17,17);font-size:16px;"> or get creative and </span><strong>craft your own</strong><span style="background-color:rgb(255,255,255);color:rgb(17,17,17);font-size:16px;">. Whether it’s hanging decorations or any other imaginative idea, the choice is yours!</span></p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_076c1f1de0fb7.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_4a56e8875824f.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_a4c3e7e92c9ff.png"></figure><h4>Connectors</h4><p>The connectors join the corners with the bars, designed for a press-fit assembly that securely holds them in place without the need for glue.</p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_df3d85f3b7bbc.png"></figure><h4>Inlay Holder</h4><p>The inlay holders can be positioned freely within the case, effortlessly sliding into the slots on the bars. These holders have a compact surface area that aligns with the glass plate either above or below, securely keeping it in place. It’s important to note that the glass plate should have a specific thickness to prevent bending. Additionally, these holders can serve as guards for LED strips or be utilized for hanging objects.</p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-17_55604275fc179.png"></figure><h4>Cover</h4><p>The top cover can be effortlessly removed, providing convenient access to the object while also safeguarding it from dust.</p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_6e43818eb8ecf.png"></figure><h4>Riser</h4><p>The riser is positioned at the base of the display case. Its purpose is to align the object with the height of the frame bars. Additionally, it is chamfered to prevent any obstruction of light from the LED strip when applied from the sides.</p><h4><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_a9769c9805aed.png"><br> </h4><h3>Assembly</h3><figure class="table" style="width:100%;"><table class="ck-table-resized"><colgroup><col><col></colgroup><tbody><tr><td style="vertical-align:top;"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_d69a6182888bc.jpg"></figure><p>Insert the connectors into the bars. Two connectors are provided: ideally, utilize the first with a 0mm tolerance for a precise fit. If insertion is impossible, indicating tight tolerances, opt for the second connector with a 0.2mm tolerance. If any connector feels excessively loose and lacks the necessary resistance for secure assembly, consider applying adhesive for added stability.</p></td><td style="vertical-align:top;"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_b82268df72af7.jpg"></figure><p>Repeat this step until no connectors are left, ensuring each bar has two connectors inserted.</p></td></tr><tr><td style="vertical-align:top;"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_dae9f17a949a4.jpg"></figure><p>Now, we are beginning to construct the base. Take a bar intended for facing the front along with two corners.</p></td><td style="vertical-align:top;"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_711003044a5db.jpg"></figure><p>Now, connect the two corners with a bar. Repeat this 4 times.</p></td></tr><tr><td style="vertical-align:top;"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_af20d17199766.jpg"></figure><p>Next, add two bars for the sides and close the frame. Repeat this step 2 times.</p></td><td style="vertical-align:top;"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_8e36a37ac8416.jpg"></figure><p>Please confirm that you now have two bars intended for vertical use and two closed top frames.</p></td></tr><tr><td style="vertical-align:top;"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_d6787ae29febc.jpg"></figure><p>If you have chosen to use the riser on the base, please have them available.</p></td><td style="vertical-align:top;"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_eac8492f7208e.jpg"></figure><p>The riser clips onto one of your closed frames. It features four connectors on the underside that need to align with one of your closed frames. Some force is required to put it in place. This frame will now serve as the base for the display case.</p></td></tr><tr><td style="vertical-align:top;"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_9df6caeca645d.jpg"></figure><p>Now it's time to insert the remaining four bars.</p></td><td style="vertical-align:top;"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_2bfba3c750d1e.jpg"></figure><p>Next, simply slide the acrylic glass sheets into the slots.</p></td></tr><tr><td style="vertical-align:top;"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_2537db721b898.jpg"></figure><p>Add the remaining frame to the top.</p><p>&nbsp;</p></td><td style="vertical-align:top;"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/730318/2024-03-18_b38babecdab64.jpg"></figure><p>Attach the cover to the top, and you're done! Congratulations!</p></td></tr></tbody></table></figure><p>&nbsp;</p><p><strong>I hope you enjoy the design, please leave a comment/rating if you enjoy it or share your feedback!</strong></p>

Display Case

Cosplay

Lights

dylan.gale77

<p>Funny bathroom sign to help shame your bathroom guests into putting the toilet paper correctly on the roll.</p>

Beards are Cool... Mullets are Not Bathroom Toilet Paper Orientation Sign

Signs

lloydliu

<p>为拓竹AMS设计的干燥剂盒，带有一个方便拿取的提手，以及一个经过特别设计的盒盖，盒盖带有两片刀刃型侧板，在向外翻转打开时，可以形成一个小漏斗，辅助装填分子筛或球形变色硅胶干燥剂颗粒。干燥盒分为标准型和薄型两款，分别用于放置在料盘中间的槽位空隙和紧贴边缘的窄间隙位置。</p><p>&nbsp;</p><p>11-22更新：</p><p>1、为统一适配温度计版和标准版干燥盒，重新调整了翻盖的造型（原版本保留，可选择性打印，但互不兼容）；</p><p>2、根据新的翻盖重新调整了标准型干燥盒翻盖结构（原版本保留，可选择性打印,但互不兼容）；</p><p>3、缩小了薄型干燥盒的手柄，以避开料盘；</p><p>4、经测试发现镂空翻盖在打印时容易出现首层不良，因此去掉了盖子的镂空；</p><p>5、重新上传了所有3mf和stl文件。</p><p>&nbsp;</p><p>&nbsp;</p><p>The drybox designed for Bambulab AMS has an easy-to-reach handle and a specially designed cap with two knife-edged side plates, that can be flipped outwards to create a small funnel to assist in filling molecular sieves or spherical color-changing silica gel desiccant granules. The drybox is available in two</p><p> versions, standard and slim, and is used to place the slot gap in the middle of the tray and the narrow gap close to the edge, respectively.</p><p>Update in 11-22:</p><p>1. In order to uniformly adapt the thermometer version and the standard version of the drybox, the shape of the cap has been readjusted (The original version is retained and can be optionally printed, but two version are incompatible) ;</p><p>2. The structure of the standard drying box was readjusted according to the new cap (The original version is retained and can be optionally printed, but two version are incompatible) ;</p><p>3. The handle of the slim drybox has been reduced to avoid interfering the spool;</p><p>4. After testing, it was found that the hollow cap was prone to defective first layer when printing, so the hollowing out of the cap was removed;</p><p>5. Re-uploaded all the 3mf and STL files.</p>

AMS干燥盒 Drybox for AMS

Bambu Lab

Board_Game_Tiles - Dorfromantik
