Stokedman Studios

imovillima

F1 RC car 1/10&nbsp;23/05/2024<ul><li>Updated Manual</li><li>Updated printer profile, added antiwarp tab on some pieces.</li></ul>&nbsp;14/05/2024 - V2 Update&nbsp;Change material type, see on print profile for changes.<ul><li>NEW - Rear Pod, change motor mount, version V2</li><li>NEW - Rear ride height adjusters V2, to use with new Rear POD motor mount V2</li><li>NEW - Front, added optionals fixed caster, two solutions 6 and 9</li><li>NEW - Front, add another support for Schumacher servo-saver, -1mm thickness</li><li>NEW - Mid, add a new side link more stiff.</li><li>UPDATE - Mid, center chassis, minor update (not essential)</li></ul>&nbsp;24/04/2024 - First revision published&nbsp;<h2>THIS IS A PROTOTYPE</h2>&nbsp;On Truck test  <figure class="media"><oembed url="https://www.youtube.com/watch?v=mcF9s4QFyug"></oembed></figure> Remember, this is an hobby for me, I&#39;m not responsible for any damage during assembly fase. Use your brain and have fun. Remember, this is a 3D printed car, do not overtight screw during assembly. This car is designed by using Fenix Racing F1Tyres Changing tyres may be change track with car, you may use different shim to adjust front and back global with. To finish the car you must buy different material, this is the list of most important material i use:<ul><li>Differential gear from Fenix Racing</li><li>Composite Steering Block - Tamiya or Xray etc etc (I&#39;m using from an OLD Tamiya only because I&#39;ve have it at home)</li><li>Kingpin from Schumacher Icon F1 world - U8671 ( this is important, 36mm length )</li><li>Low pivot from Schumacher Icon F1 - U8136 ( you can use pivot from Xray F1 or roche F1)</li><li>Servo saver from Schumacher - U4328</li></ul>In my setup i use:<ul><li>ESC - Hobbywing XR10 Justock G3S</li><li>Motor - Hobbywing XR10 Justock 21,5t</li><li>Servo - Team Powers Digital Coreless Servo V3</li></ul>

F1 Rc car 1/10

toys

Deepsix

This is a remix of the design created by DarkArtsLab to connect your Bambu Labs P1S, X1 printers to a 2.5&#34; exhaust hose coming down from above the printer. The holes in the mounting flange allow you to connect it via a few short sheet metal screws into the three open holes on the back of the printer. I recommend using bolt head style screws to be able to turn in the one at the top of the printer.&nbsp;Supplied with these files are the 3MF, STL, STEP files as well as the SOLIDWORKS part file that I created this in. If you have access to SOLIDWORKS you can edit the file as needed.

P1S, X1 Exhaust Vertical Vent Adapter

Printer

Dynarun

This fan grill is designed for 120mm fans and watercooling radiators. For a clean and smooth surface, I activated ironing with 25% flow. Printed with PLA Pink Pearl.

Lüftergitter / Fan Grill 120mm

Van prints

MechEng67

This is a small storage box with a lid that features a beautiful Kumiko pattern. All parts can easily be printed without supports.&nbsp;I&#39;ve included four different options to divide the box:<ul><li>Option A (pictured) divides the internal section in 2</li><li>Option B - No division</li><li>Option C - Two levels, bottom is divided in three sections and top is not divided</li><li>Option D - Divided in 3 sections (same as option C but single level)</li></ul>External Dimensions:<ul><li>Width: 126.10mm</li><li>Depth: 82.10mm</li><li>Height: 43mm</li></ul>&nbsp;Internal Dimensions (without division, option B):<ul><li>Width: 114mm</li><li>Depth: 70mm</li><li>Height: 35mm</li></ul>&nbsp;Additional information:<ul><li>A1 Mini compatible</li><li>Glue is not required, all parts were designed with very tight tolerances and snap together.</li><li>All parts are printed, no hardware.</li><li>See exploded view in photos for the installation sequence.</li><li>The “ring” part is optional to give an extra line in the middle of the box. It can be omitted without changing anything else.</li></ul>*Warning: Given the tight tolerances between parts, I am not sure that scaling this model will give good results. Parts may be too loose or too tight.
