Hi,&nbsp;This model consist in two tools designed to help drilling holes at the right place when installing a concealed print in place hinge.(model here : <a target="_blank" href="https://makerworld.com/en/models/195411#profileId-215987)" rel="nofollow noopener">https://makerworld.com/en/models/195411#profileId-215987)</a>&nbsp;The first tool is a basic L shaped print with 2 holes where you should drill.This tool must be used on the furniture side (the fixed part).&nbsp;The second tool is more complex.You can screw a M4 screw in the hole to tune the friction of the caliper.It then has two functions:<ul><li>Measure/Visualise the overlap you want</li><li>Report it on the door</li></ul>(You will undestand how it works by looking at the photos)
