Richard Liu

***The print profile contains all 3 versions, just delete the one(s) you don't want before printing***&nbsp;After many, many iterations I finally have a splitter I'm happy with. I primarily designed it as a 5 way splitter but it's more or less parametric so I was able to produce 2 and 3 way versions. 4, 6 and maybe 7 way splitters may be possible with a bit more tweaking, if there's interest let me know. Here are the main features I aimed for:<ul><li>Angled inlets to minimize the number of curves the filament has to go through</li><li>Built in PTFE connectors that do not reduce the diameter or deform the inside of the PTFE tube</li><li>Prints without support</li></ul>Here are the printing / installation instructions (PLEASE READ BEFORE USING):<ul><li>Print upright and use the smallest layer hight your printer is capable of. I printed mine at .16mm</li><li>If you have adhesion issues print with an outside brim</li><li>This splitter is designed for PTFE tubes with 4mm OD and 2mm ID</li><li>To make installation easier, each PTFE tube needs to have a thread cut into it</li><li>For all tubes, make sure they are all cut square, and the openings are round, not squished, otherwise you'll have problems</li><li>Using tape or a marker, from the end measure 15 mm for the outlet PTFE tube and 17mm for each of the inlet PTFE tubes</li><li>Use the bottom, middle opening as a die to cut the thread into the PTFE tubes, use light force to push the PTFE tube as you turn it in, it should go in as far as the marking you made, 5 or 6 full turns should do it</li><li>If you have trouble gripping the PTFE tube try wrapping it with masking tape</li><li>Since the tubes are turned into place it's best if the other ends are unplugged during assembly</li><li>Install the top tube until it bottoms out which is about 15mm</li><li>Install the bottom tubes until you reach 17.5mm or until you feel it bottoming out. ONCE YOU DETECT THE BOTTOM DO NOT TIGHTEN ANY FURTHER. This is because the channel is tapered and it will squish the PTFE tube inward causing unwanted friction</li><li>Test each filament path once assembled, you may need to screw in/out some of the PTFE tube as needed.</li></ul>That's it, let me know if these work for you or not.

Bowden 2-3-5 Way Splitter

工具

angrelou

Update 03/03/2024Thank you all for the support. I uploaded a new design of Darth Vader's signature ship, the TIE Advanced x1.&nbsp;Hello everyone, I know there are already designs for this model, but the reason I created a new design is to make it compatible with color (ams).As you can see, it has a more complete design by having more pieces and details, such as color on both sides of the wings, which makes this design unique.Tips: 1.- Remember to calibrate the bed before making this design. 2.- It is designed to use a bit of force and not require glue.If you liked the design, check out my profile and subscribe, you won't regret it.

Tie Fighter kit card Star wars

玩具

Gatto

Dragon Ball - Son Goku Chibi Figure&nbsp;From the popular manga and anime series, Dragon Ball, comes this adorable chibi figure of the main character, Son Goku! Our strong hero with a pure heart is 7,8 cm tall but can be resized to your liking. No print supports are needed with these dimensions, but if you modify them, they may be necessary! PRINTING TIPS:Goku stands up even in the standard infill version, but if you want more stability you can print the &#34;WEIGHTED BOTTOM&#34; version that you can find in the 3mf file.Personally, I didn&#39;t have any problems printing it without brim, but if you notice loss of adhesion it might be necessary to activate it.  <a target="_blank" href="https://makerworld.com/en/@Gatto" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000453618/design/2024-04-15_4fefedc8921d9.gif"></a><figure class="image"><a href="https://makerworld.com/en/@Gatto" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000453618/design/2024-06-16_32117daa8fb33.jpg"></a></figure><a target="_blank" href="https://makerworld.com/en/@Gatto" rel="nofollow noopener">Check out my profile for other models and follow MEOW!</a>

Son Goku Chibi Figure - 孫 悟空

卡通

鱼小兑

NAU模块化桌面支架说明书NAU Modular Desktop Stand Instruction Manual 大部分功能在视频中都有提到 其余还有几处可固定走线的位置，期待你解锁更多新功能Overview: The NAU Modular Desktop Stand boasts a myriad of functions, many of which have been highlighted in my video, with additional cable management features awaiting your discovery for even more utility.<figure class="image image_resized" style="width: 33.59%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000451095/design/2024-05-02_4bef7395861ca.jpg"></figure>**打印**&nbsp;打印文件为3mf文件，包含我设置好的切片参数，以180mm打印盘为基础设计，所以适配大部分打印盘尺寸 匹配自己的打印机型号、打印盘类型、耗材这三者即可打印 我使用的是petg，需要在底板喷胶，否则会翘边 组装组件为 底座+上半主体+耳机挂架+拓展增高模块+卡盒（可选）+任选组件 以按照我推荐的白灰蓝配色进行分盘，不需要ams（多色打印模块）Printing Guidelines:<ul><li>File &amp; Settings: The provided 3mf file includes pre-configured slicing parameters tailored for a 180mm print bed, ensuring compatibility with most bed sizes. Adjust your printer model, bed type, and filament choice accordingly. I utilized PETG, requiring bed adhesion to prevent warping.</li><li>Components: Assemble with the base, upper body, headphone hanger, expansion riser module, card holder (optional), and any chosen accessories. For aesthetics, follow my recommended white-gray-blue color scheme without the need for multi-color printing modules.</li></ul><figure class="image image_resized" style="width: 28.52%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000451095/design/2024-05-02_adee64458a024.png"></figure> **安装**&nbsp;在测试后我使用0公差设计，支架主体的槽口有一定形变能力，在使用petg材料时可以提供足够的固定力，pla未测试 但即便是同类型材料，不同品牌的收缩性亦有区别， 所以可能导致部分组件太松或者太紧，以下是我的建议&nbsp;如果组件太紧 请尝试打磨与槽位结合的几条边缘 尤其是有brim的组件&nbsp;如果组件太松 对于需要受力的组件，太松会直接导致掉落，最好的方法是确定位置不需要更换后，再用胶水固定 其次建议垫些薄纸片加固，这样不会丧失灵活性&nbsp;打印完成可在底部预留的四个圆孔位置贴上胶贴防滑 如果希望支架整体可以更稳一点，除了在底部放物品外，可以打印时提高底座的稀疏填充的百分比（默认是10%的自适应立方体）&nbsp;Assembly Instructions:<ul><li>Design Tolerance: After thorough testing, a zero-tolerance design was adopted. The stand&#39;s slots possess some flexibility, providing ample retention with PETG; PLA no tested. Due to varying shrinkage rates across brands, components may fit too tightly or loosely. Here are my recommendations:<ul><li>If Too Tight: Gently sand the edges that mate into the slots, particularly those with brims.</li><li>If Too Loose: Glue is ideal for load-bearing parts if they&#39;re excessively loose after positioning. Alternatively, consider slipping thin paper shims to reinforce without compromising adjustability.</li></ul></li><li>Anti-Slip Measures: Attach adhesive pads to the four designated circular holes on the base for added stability. Enhance overall sturdiness by increasing the infill density of the base during printing (default is 10% adaptive cubic).</li></ul>&nbsp;**修改**&nbsp;我提供了以fusion360为基础的源文件，如果有一定基础，你可以打开后自定义修改组件&nbsp;未来可能的升级方案 1.便携式SD卡盒设计 2.可旋转的地台 3.超级模块化+更多可替换组件Customization:<ul><li>Source Files: For advanced users, Fusion360 source files are included, enabling customization of individual components.</li></ul>Future Upgrade Possibilities:<ol><li>Portable SD Card Holder Design</li><li>Rotatable Base Platform</li><li>Enhanced Modularity + Additional Swappable Components</li></ol><figure class="image image_resized" style="width: 31.3%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000451095/design/2024-05-02_a5de48f511f26.png"></figure>感谢大家的支持，我是鱼小兑，https://space.bilibili.com/313019007 别忘了常来B站看看我的新视频哦~Acknowledgments: Thank you for your support. I&#39;m YOTURN, remember to drop by my Bilibili space at <a target="_blank" href="https://space.bilibili.com/313019007" rel="nofollow noopener">https://space.bilibili.com/313019007</a> for fresh content and videos!Please note that this translation captures the essence of your original text and aims to maintain clarity and technical accuracy for English readers.
