<p><i>This is the original #3DBenchy directly from Creative Tools. Not a download of a download, nor all the slightly modified versions found elsewhere (ie, BambuLab Studio, Printables, etc…)</i></p><p>&nbsp;</p><p><strong>I would like to introduce the #3DBenchy to Maker World. During the close beta period, there was no #3DBenchy available to send to the printer from the phone app so I uploaded it here. </strong></p><p>&nbsp;</p><p><strong>Please add your profiles as you see fit for the community to use to run tests. Thanks!</strong></p><p>&nbsp;</p><p>Community members have provided a ton of different profiles. I hope you find one that fits your testing needs. Remember, a bad Benchy print could mean your filament calibrations are off, or a sign of mechanical error (for Bambu Printers.)</p><p>&nbsp;</p><p><i>All models uploaded and the below content is extracted from 3Dbenchy.com.</i></p><figure class="media"><div data-oembed-url="https://youtu.be/_epwuDI9FBI"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/_epwuDI9FBI" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure><p>&nbsp;</p><figure class="image"><a href="http://www.3dbenchy.com/features/" target="_blank" rel="nofollow noopener"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/3DBenchy__Low-slope_surfaces_1-300x300.png"></a></figure><p>#3DBenchy is designed to offer a large array of challenging geometrical features for 3D printers, and touch on different issues related to additive manufacturing.</p><p>The 3D model is designed to print at 1:1 scale without support materials. It is challenging for most 3D printers but the small volume (15.55 cm3) typically prints in well under two hours and does not require much material.</p><p>The different surfaces of the #3DBenchy model reveal typical issues regarding surface finish, model accuracy, warping, etc.</p><p>Visit <a target="_blank" href="http://www.3dbenchy.com/sample-page/features/" rel="nofollow noopener">this link</a> to see a complete list of each feature and correspondent descriptions.</p><figure class="image"><a href="http://www.3dbenchy.com/dimensions/" target="_blank" rel="nofollow noopener"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/3DBenchy_about_features-300x287.png"></a></figure><p>Use #3DBenchy to test and calibrate your 3D printer by adjusting hardware and software settings for optimal results.</p><p>The shape and size of this 3D model is designed to challenge 3D printers. Compare your #3DBenchy results with the dimensions illustrated in <a target="_blank" href="http://www.3dbenchy.com/dimensions/" rel="nofollow noopener">this link</a>. These are easy to measure with a caliper.</p><p>Print and check your 3D-printer’s result for dimensional accuracy, tolerances, warping and deviations related to changes in printing parameters and material types.</p><p>&nbsp;</p><h2>Features</h2><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/3DBenchy_page_features_main_image.png"></figure><p>#3DBenchy is designed to offer a large array of challenging geometrical features for 3D printers, and touch on different issues related to additive manufacturing.</p><p>The 3D model is designed to print at 1:1 scale without support materials. It is challenging for most 3D printers but the small volume (15.55 cm3) typically prints in well under two hours and does not require much material.</p><p>The different surfaces of the #3DBenchy model reveal typical issues regarding surface finish, model accuracy, warping, etc.</p><p>Please see a complete list of each feature and correspondent descriptions below.</p><p>&nbsp;</p><h2>The Hull</h2><p>The hull is a large, smooth overhanging curved surface that is challenging to 3D-print, and clearly reveals any surface deviations.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_hull_curved_overhang-300x300.png" alt="Feature_hull_curved_overhang"></figure><p>&nbsp;</p><h2>Symmetry</h2><p>#3DBenchy is perfectly symmetrical which makes any skewness and warping easy to detect.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_symmetry-300x300.png" alt="Feature_symmetry"></figure><p>&nbsp;</p><h2>High-Resolution STL file</h2><p>The STL file is triangulated at a very high resolution which yields smooth surfaces. The maximum deviation from the original CAD file is set to 0.001 mm.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_high-res_stl_mesh-300x300.png" alt="Feature_high-res_stl_mesh"></figure><p>&nbsp;</p><h2>Planar Horizontal Faces</h2><p>The top surfaces of the deck, box and chimney are planar, horizontal and parallel to the bottom plane.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_planar_horizontal_faces-300x300.png" alt="Feature_planar_horizontal_faces"></figure><p>&nbsp;</p><h2>Tiny Surface Details</h2><p>If you have a high-resolution 3D printer, this is where you can shine! The letters on the stern are less than 2 mm tall and the thickness of #3DBenchy’s nameplate is just 0.1 mm.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_3DBenchy_nameplate_tiny_detail-300x300.png"></figure><p>&nbsp;</p><h2>Cylindrical Shapes</h2><p>The chimney is designed to define concentrical cylindrical shapes with inner and outer diameters. These clearly show deviations in roundness.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_conentrical_cylindrical_shapes-300x300.png" alt="Feature_conentrical_cylindrical_shapes"></figure><p>&nbsp;</p><h2>Overhang Surfaces</h2><p>Overhang issues are the Achilles’ heel of 3D printing. #3DBenchy offers several challenging areas such as in the difficult-to-reach inside of the bridge.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_overhang_bridge-300x300.png" alt="Feature_overhang_bridge"></figure><p>&nbsp;</p><h2>Low-Slope-Surfaces</h2><p>Low-slope-surfaces clearly show the layered structure of 3D printing. If printed horizontally, #3DBenchy’s gunwale and roof of the bridge will reveal the layer-steps.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_low-slope-surfaces-300x300.png" alt="Feature_low-slope-surfaces"></figure><h2>Large Horizontal Holes</h2><p>The rear window offers a large circular horizontal hole and the boat’s wheel offers a round difficult-to-reach secluded feature.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_large_horizontal_hole-300x300.png" alt="Feature_large_horizontal_hole"></figure><p>&nbsp;</p><h2>Small Horizontal Holes</h2><p>The hawsepipe represents a small short horizontal hole and has a very thin flange against the hull.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_hawsepipe_small_hole-300x300.png" alt="Feature_hawsepipe_small_hole"></figure><p>&nbsp;</p><h2>Slanted Small Holes</h2><p>The fishing-rod-holder provides a very small slightly-slanted blind hole.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_fishing-rod-holder_slanted_small_hole-300x300.png" alt="Feature_fishing-rod-holder_slanted_small_hole"></figure><p>&nbsp;</p><h2>First-Layer-Details</h2><p>The shallow letters at the bottom of the boat clearly reveal typical first-layer-squashing.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_shallow_letters_bottom_plate-300x300.png" alt="Feature_shallow_letters_bottom_plate"></figure><h2> License</h2><figure class="image"><a href="http://www.3dbenchy.com/wp-content/uploads/2015/04/3DBenchy_frontpage_slider_sea_v041.jpg" target="_blank" rel="nofollow noopener"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/3DBenchy_frontpage_slider_sea_v041-1024x402.jpg"></a></figure><p>&nbsp;</p><p>#3DBenchy by <a target="_blank" href="http://creative-tools.com/" rel="nofollow noopener">Creative-Tools.com</a> is licensed under a <a target="_blank" href="http://creativecommons.org/licenses/by-nd/4.0/" rel="nofollow noopener">Creative Commons Attribution-NoDerivatives 4.0 International License</a>. Permissions beyond the scope and typical usage examples are explained below.</p><p>&nbsp;</p><h2>Feel free to …</h2><ol><li>… <strong>download</strong> the <a target="_blank" href="http://www.3dbenchy.com/download/" rel="nofollow noopener">#3DBenchy STL file</a> and 3D-print it as you please.</li><li>… <strong>give away</strong> and even <strong>sell</strong> 3D-prints of the <a target="_blank" href="http://www.3dbenchy.com/download/" rel="nofollow noopener">#3DBenchy STL file</a>.</li><li>… <a target="_blank" href="http://www.3dbenchy.com/share/" rel="nofollow noopener"><strong>publish</strong></a> images and videos of your 3D-prints – <i>you own them!</i></li><li>… <strong>redistribute</strong> the <u>unmodified</u> <a target="_blank" href="http://www.3dbenchy.com/download/" rel="nofollow noopener">#3DBenchy STL file</a> as you please. Such as hosting your own downloads, attaching to emails, including the file on DVDs, USB-sticks, and in software distributions, bundling the STL or pre-sliced print file with 3D printer kits, etc.</li><li>… <strong>experiment</strong>, be <strong>inventive</strong> and <strong>creative</strong>! We made #3DBenchy as a tool for playing around with and testing 3D printers. Improve your skills and challenge your machine and its software. Try every setting, variation and material you can think of!</li><li>… modify #3DBenchy for <strong>personal</strong> use. Feel free to publish texts, images and videos of your experimentation (these are your work and you own them!). Please respect the above list items regarding not distributing modified STL files of #3DBenchy.</li></ol><h2>Consistency</h2><p>#3DBenchy is designed to be a calibration tool for testing 3D print settings and comparing the performance of different 3D printers. Therefore it is <u>important</u> that the same unmodified <a target="_blank" href="http://www.3dbenchy.com/download/" rel="nofollow noopener">STL</a> file is consistently used for this purpose.</p><h2>Attribution</h2><p>We designed the little #3DBenchy boat and this expanding web page <u>to help</u> 3D printer operators on this planet to better navigate the vast sea of 3D printing possibilities!</p><p>It is also meant to be a fun object to experiment with and discover 3D printing. If you enjoy #3DBenchy and the content on this site, please give us attribution in your publishings. Simply include the word <a target="_blank" href="https://www.google.se/webhp?sourceid=chrome-instant&ion=1&espv=2&ie=UTF-8#q=%233dbenchy" rel="nofollow noopener">#3DBenchy</a> and the URL <a target="_blank" href="http://3dbenchy.com/" rel="nofollow noopener">3DBenchy.com</a>. The team behind #3DBenchy highly appreciates your help!</p>

BENCHY

Tests

K-Studio.ca

<p>A tool to hold microfiber towel to clean build plates with ease.</p><ul><li>Print in PLA</li></ul><h4>Filament used in photo:</h4><ul><li>Bambu PLA Metal</li><li>Bambu PLA Matte</li></ul><h4>Updates </h4><p>March 23, 2024</p><ul><li>Added an alternative knob for thin cloth or sandpaper.</li><li>Original is designed to bottom out to prevent vertical force to break the print apart.</li></ul><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/754191/2024-03-23_13ab91d9f5c498.jpg"></figure><h4>Instruction</h4><ol><li>Simply take the two blocks align to the microfiber and cut to the same rectangle size.</li><li>Wrap the microfiber around the edge and crimp it down.</li></ol><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/754191/2024-03-23_6dbc3edb91bb7.jpg"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/754191/2024-03-21_757e6c3f7297d8.gif"></figure>

Build Plate Cleaner

zuim

<p>Mount 22.5mm width cameras on the TBS Source One V5. Also contains a bumper and adjustment of angle using two screws.</p><p><strong>No supports needed!</strong></p><p>Printed using PETG.</p>

TBS Source One V5 22.5mm camera mount

RestoreDoctor

<p><strong>Radius Gauge R1-30mm</strong></p><p><i>Simple tool for determining the radius. A must for being able to draw parts!</i></p><p>&nbsp;</p><p><i><strong>Settings:</strong></i></p><ul><li>0.20mm Standard </li><li><i>Infill 20 %</i></li><li><i>no support</i></li><li><i><strong>PLA/</strong> <strong>PETG</strong></i></li><li><i><strong>Use Multimaterial painting - Smart fill in Prusa Slicer. (Bambu Lab see below)</strong></i></li></ul><figure class="image"><img src="https://media.printables.com/media/prints/578621/rich_content/fa528cba-7f9d-4977-a2a8-8de6a90157df/thumbs/cover/800x466/png/screenshot-2023-09-10-171052.webp"></figure>

Radius Gauge R1-30mm

Tools

KYZ Design

<p>Gridfinity baseplates completely remodelled from scratch, designed to minimise print time.</p><ul><li>Lower overall height (top trimmed)</li><li>Flares on the bottom removed</li><li>Smaller radii</li></ul><p>Designed for PLA and other materials with good first layer adhesion. You may need to add a brim to print with ASA/ABS.</p><p><br>Print <a target="_blank" href="https://makerworld.com/en/models/76537" rel="nofollow noopener">these bins</a> next!<br><img src="https://makerworld.bblmw.com/makerworld/draft/285381/2023-11-28_4d90d07fb6c75.png"></p><p>&nbsp;</p><p>Check out <a target="_blank" href="https://makerworld.com/en/u/11128021/collections/26498" rel="nofollow noopener">this collection</a> for my other Gridfinity models and</p><p>check out <a target="_blank" href="https://makerworld.com/en/u/11128021/collections/18964" rel="nofollow noopener">this collection</a> for my Honeycomb Storage Wall models.</p>

Tests

P1S

FPV

Tools

Gridfinity
