<h2>If you want a commercial license, check out my bio and get it from Patreon.</h2><h2>Personal use only.</h2>&nbsp;This model is design for MakerWorld light contest (2/5). Complete free version is only available on here Makerworld. <h3>Many people have contacted me said they willing to pay for the model. Other platform product manager reach and out said I could use their platform and selling this design for some money, but I have decided to keep it here for free for now. So there will be more people could enjoying it :) So show me your finshed print, I would like to see it. </h3><h3> Anywhere else you see this model upload is Unauthorized (please notify me and report them), beside my own account (SavageLau). </h3>&nbsp;<h2>If you would like purchase LED light needed for this design and filament from Bambu Lab Offical website: Affiliate link is below, so I can get some commission to support my future work. </h2><h2><a target="_blank" href="https://shrsl.com/4h4np" rel="nofollow noopener">https://shrsl.com/4h4np</a> </h2><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-03-23_4ad27b7082fe3.png"></figure><h2>Filaments that I use for this project: (Bambu Lab Offical website:)</h2><h2><a target="_blank" href="https://shrsl.com/4h4ns" rel="nofollow noopener">https://shrsl.com/4h4ns</a> </h2>&nbsp;&nbsp;&nbsp;<h2>You may also like this design:</h2>PeaShooter Lamp Kit 001. <a target="_blank" href="https://makerworld.com/en/models/174475#profileId-191833" rel="nofollow noopener">https://makerworld.com/en/models/174475#profileId-191833</a> &nbsp;&nbsp;&nbsp;My boss saw some Bellsprout light the other day and she want me to design one. I have one LED Lamp kit come with my a1mini and sitting for a while. So why not turning it into what she want. So the design started adpot the lamp kit into Bellsprout.I found this pic on Google, based on the posture and proportion started deisng.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-30_bc131748fd272.png"></figure>&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-02-01_33679f29d502a.png"></figure><h2>Update: </h2><h3>2/2/2024. A new profile was made for a1mini. Increased infill/walls on base and body part. </h3>Model main body have been reduced in size inorder to meet the build plate size for a1mini with muti-color prints. &nbsp;<a target="_blank" href="https://makerworld.com/en/u/2010665163" rel="nofollow noopener">@Sascha2202</a> feedback it is a bit hard to keep banlance. Weight increased on printing profile by adding more infill and walls. Weight for that part from 160g to 202g, lowered center of gravity. Consider head is around 40g + led weight, it should do well now. <h3>2/1/2024. Joints redesigned. </h3>Improved joints firction load, strength, tolerancing. New turning angle sets around 13.5 degrees max for each joints. <figure class="image image_resized" style="width:36.72%;"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-02-01_d00693a8b7acb.png"></figure>“Head” part fit and finish improving. <h3>Revisions and Tests today:</h3><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-02-02_ffe7e41994dec.png"></figure>&nbsp;<h2>Before you print(Important!):</h2>Run the joint test print first with the filament you are going to use for joints and body, before you doing the full print! This is important. Depend on filaments you use for the joint parts, there will be sinkage rate difference, and firction load on joint will be different.&nbsp;I put very tight tolerancing on design, but it may not work as intended when you printing with your filaments, so run the test and confirm joints is very tight to each other. Other wise You will not get the desired result.&nbsp;&nbsp;Joints with other parts are standard size. There is one “Tight” profile for joints. There are two types of joint, regular and with wire clip one. You will need to print total of 12 or above (maybe less than 15) to get good proportion. &nbsp;Joints designed best work with 4 wall layers, and 10% to 20% infill, adding more infill will not improve the strength, will only leading part failure during assembly. &nbsp;<h2>Hard ware:</h2>This design require Lamp LED Kit 001 from Bambu Lab. All other parts are printable. <figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-31_bca061fd80f1d.png"></figure>&nbsp;<h2>Post work:</h2>Removing brims from all parts, when you remove brim from joints part, confirm it is fully removed. <figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-02-02_dec1b2c670225.gif"></figure><h2>Assembly:</h2>Refer these gif image. Joints is a bit hard to push in, refer how I do it, holding the bottom part with you fingure, it will reduce the change of failure. &nbsp;Joints:<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-02-02_5c978e23e8634.gif"></figure><figure class="image image_resized" style="width:51.25%;"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-02-02_9f2e463b2d8a6.gif"></figure>Fully assembly:<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-02-02_9a975d341b61f.gif"></figure>&nbsp;&nbsp;&nbsp;<h2>Design:</h2>Lamp kit is 60mm dia, 8mm thickness. based on that dims and make rough draft to evaluate the overall size.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-30_34bf66e6b20e5.png"></figure>&nbsp;Working on some parts, and integrate them in the end.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-30_4880a9ab2336a.png"></figure>&nbsp;I started with wanting ball joint on the head, so it will able to turn angles. End up why not to have more ball joints on the body.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-30_b08f0ea2e5ee9.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-30_80ec7f991cbaa.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-30_80ed16d7dd498.png"></figure>&nbsp;Ball joints is pain in the axx to work with. I want it to have a lot of friction load in normal condition. so the outter shell shall have very small tolerance to the ball or even smaller. Ended spending a lot of time try in truth to testing out different tolerances and make design revisions.Still not perfect, but it work for this application. You gain a lot of DOF, but it is a bit brittle, depends on your materials.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-30_153933e0ba5bb.png"></figure><h2>Revisions and tests:</h2><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-31_641c974fd0d58.png"></figure>

BellSprout Lamp LED Kit 001

pokemon

KNDesign

Recommend using .2mm nozzle as the text are tiny. Dice is design to be 30mm .&nbsp;Requirement:<ul><li>Super Glue</li></ul>Assembly Instruction: Dice ConstructionGeneral Rule: Ensure that the sum of the numbers on opposing sides equals 13.Example:<ul><li>1 + 12</li><li>2 + 11</li><li>3 + 10</li><li>4 + 9</li><li>5 + 8</li><li>6 + 7</li></ul>Assembly image:&nbsp;<img src="https://makerworld.bblmw.com/makerworld/draft/794707/2024-03-30_11fcc9306e121.jpg"><img src="https://makerworld.bblmw.com/makerworld/draft/794707/2024-03-30_663a703ed7567.jpg">

D12 Mario Party Dice

thoeb3d

Growing up I played this game with my parents on a large wooden cutting board that we'd drilled holes into. I wanted to make a more compact version that could be stored more easily so I came up with this version that is made up of 4 quadrants that are held together with magnets. This is very similar to Wahoo or Aggravation, but the board layout is ever so slightly different. Based on the rules I found on wiki for both games, the gameplay is basically the same. Generally speaking, you roll dice and move around the board clockwise with the goal of getting all of your marbles out of the base and into the home. From what I can tell, those games are typically played with 4 marbles per player, but we always did 5 each so I uploaded models with both iterations. There are 3 holes on each of the inside faces for placing 6mm x 3mm magnets to attach the board together. They're slightly oversized but worked well for press fitting them in place. If they're a little loose, a little CA glue should do the trick. Pay attention when placing the magnets so that you have the polarities correct for assembling the pieces together once you print all 4. I printed mine in dual color to highlight the base, starting spot, and home row.
