Measure outside fillets (diameters) with this tool – see all the versions below. Pick any two PLA colors and you'll have some stellar measuring tools in no time.<ul><li>2mm to 20mm diameters (1-10mm radius)</li><li>10mm thick</li></ul>The best quality is the Ironed options (not noted) but if you want to save some time, pick the No-Iron option set.<figure class="image image-style-side"><img src="https://makerworld.bblmw.com/makerworld/draft/349738/2023-12-26_4bcc5a8099586.jpeg"><figcaption>S, M, L size gauges</figcaption></figure><h3>All our Versions</h3><ul><li><a target="_blank" href="https://makerworld.com/es/models/109504" rel="nofollow noopener">S – 2-20mm</a> (has set of 3 too)</li><li><a target="_blank" href="https://makerworld.com/es/models/109507" rel="nofollow noopener">M – 20-33mm</a></li><li><a target="_blank" href="https://makerworld.com/es/models/109529" rel="nofollow noopener">L – 34-47mm</a></li></ul>&nbsp;&nbsp;Our Favorite Things for 3D PrintingIncludes Affiliate Links<ul><li><a target="_blank" href="https://amzn.to/3LGX09C" rel="nofollow noopener">Nano Adhesive</a> - Stop using glue sticks - this is 1000% better 😉</li><li><a target="_blank" href="https://amzn.to/3F6S4qw" rel="nofollow noopener">6mm Magnets</a></li><li><a target="_blank" href="https://amzn.to/3LLUkHF" rel="nofollow noopener">Plastic Debur Knife</a> - clean up plastic edges (brims)</li><li><a target="_blank" href="https://amzn.to/3tjdpuB" rel="nofollow noopener">Small Clamps</a></li><li><a target="_blank" href="https://amzn.to/48CusHU" rel="nofollow noopener">Assembly Glue</a></li></ul><a target="_blank" href="https://s.pdxcnc.com/?ref=makerworld-rg-s" rel="nofollow noopener">PDX CNC Products</a>

Diameter / Radius Gauge - Metric 2-20mm (S)

Fillet Gauges

This is a revision of Brandon Raineri's Spool container. One small frustration is that it's so well designed that it was hard to tell which end opened as the “Cap” and which was the container or “cup.” This led to a good chance I was spilling silica beads all over 😅.&nbsp;The major revision here is adding a label to the cap part with a small text addition to label it CAP.&nbsp;I've adjusted the speeds in my print profile and finish strategies which I like a little better.&nbsp;They fit Bambu Lab spools perfectly. Also Hatchbox PLA spools (image included).&nbsp;The filament must be dry for quality PETG printing - holes won't be clear and you'll get buildup. Also, vent your machine.<h3>To Assemble</h3><ul><li>Push the end caps into their appropriate (size is key) parts.<ul><li>Use superglue or E6000 linked below if you'd like to assemble caps with bodies (not the screw mating though).</li></ul></li><li>Add <a target="_blank" href="https://amzn.to/47sBf5F" rel="nofollow noopener">desiccant</a> to the container.</li><li>Screw together container on the spool.</li></ul>&nbsp;Tip: Dessicant is reusable. Put beads in a glass container and microwave for 1-2 mins until color returns to normal. Let cool and reuse.&nbsp;<h4>The 70c spool does not work with this version</h4><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/272280/2023-12-14_e64324a483d62.png"></figure>&nbsp;<h4>Trouble?</h4><ul><li>If you're having any issues printing, make sure to dry your PETG to <20% humidity.</li><li>Lower the volumetric flow rate to 9 mm/s in the filament profile.</li><li>Slow the print speeds.</li><li>Easiest cure-all fix is to just put the printer on Silent mode which prints at 50% and that usually solves a ton of PETG quality issues.</li><li>Use nano adhesive on bed if you're having sticking problems.</li></ul>&nbsp;Our Favorite Things for 3D PrintingIncludes Affiliate Links<ul><li><a target="_blank" href="https://amzn.to/3sx6XA4" rel="nofollow noopener">Filament Dryer we use</a></li><li><a target="_blank" href="https://amzn.to/3LGX09C" rel="nofollow noopener">Nano Adhesive</a> - Stop using glue sticks - this is 1000% better 😉</li><li><a target="_blank" href="https://amzn.to/3F6S4qw" rel="nofollow noopener">6mm Magnets</a></li><li><a target="_blank" href="https://amzn.to/3LLUkHF" rel="nofollow noopener">Plastic Debur Knife</a> - clean up plastic edges (brims)</li><li><a target="_blank" href="https://amzn.to/3tjdpuB" rel="nofollow noopener">Small Clamps</a></li><li><a target="_blank" href="https://amzn.to/48CusHU" rel="nofollow noopener">Assembly Glue</a></li></ul><a target="_blank" href="https://s.pdxcnc.com/?ref=makerworld-fila-container" rel="nofollow noopener">PDX CNC Products</a>
