<h2>Modular Rack System for Gridfinity Drawers</h2>This is a completely modular customizable rack system for gridfinity drawers.&nbsp;Please scroll down to find the list of all available models and links to the download pages.&nbsp;The system currently consist of three types of elements. Elements for a single rack tower, elements for a double rack tower and elements for a customizable rack multi tower / drawer wall.&nbsp;All elements are housing drawers with space for a 5x5 gridfinity base plate and are currently available in the following heights:3U, 4U, 6U, 8U and 10U.&nbsp;A xU drawer can fit standard xU gridfinity boxes.&nbsp;The side, back and connector elements contain dove tail connectors with friction fitting.To connect and disconnect them, a little bit of force is needed. I found that lightly tapping with the back of a scredriver does the trick.To connect the elements vertically, connection pins have to be printed.The top of a rack tower can be finalized with the modular top lid elements. To connect these lid elements, screw in connection pins are provided.&nbsp;Every element can be printed on a Bambu Lab X1C or P1P/S build plate (256x256).&nbsp;I drew a lot of inspiration from the FOSBOS and BaBo systems, but I wanted to create a system that would not need screws or glue and could be reconfigured at any time.<h3>Print settings</h3>Every element has its own print profile (follow the links below) with the following settings included:<figure class="table" style="width: 56.4%"><table class="ck-table-resized"><colgroup><col><col></colgroup><tbody><tr><td>Layer height</td><td>0.2</td></tr><tr><td>Walls</td><td>4</td></tr><tr><td>Material</td><td>Structural Parts (PLA+, ABS etc.)  Connection Pins / Screw in Pins (PETG)</td></tr><tr><td>Infill</td><td>15 %</td></tr></tbody></table></figure><h3>Connection Test</h3>If you are unsure about the calibration of your printer, you can use the following test print.&nbsp;<figure class="table" style="width: 31.6%"><table class="ck-table-resized"><colgroup><col></colgroup><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2024-01-13_06fc36b103019.png"></figure><a target="_blank" href="https://makerworld.com/en/models/134987" rel="nofollow noopener">Connection Test</a></td></tr></tbody></table></figure><h3>Dove tail connections to tight?</h3>If your Bambu lab printer (or any other 3d printer) prints the dove tail connections to tight, you can try one of the following suggestions by users that were successfull:<ul><li>User bvogl changed the settings (Bambu Lab / Orca Slicer) in Quality → Precision (X-Y hole compensation and X-Y contour compensation) to make the dove tail connections slightly less tight.</li></ul><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2024-06-03_3aeebd2707a1d.png"></figure><ul><li>One user reduced the flow rate of the material by 7%, which led to the dove tail connectors fitting nicely.</li><li>Make sure to run the flow dynamics and flow rate calibrations for your chosen filament to get the required tightness.</li></ul><h3>Overview</h3><figure class="table" style="width: 86.17%"><table class="ck-table-resized"><colgroup><col><col><col></colgroup><tbody><tr><td><h3>Single Tower</h3><figure class="image image_resized" style="width: 100%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_e01d718c823f.png"></figure></td><td><h3>Double Tower</h3><img class="image_resized" style="width: 100%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_c67869ec30151.png"></td><td> <h3>Customizable Multi Tower</h3>Please download the STEP file to get all parts.<figure class="image image_resized" style="width: 84.18%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_78a40b312a80d.png"></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_edd164e3dcd6f.png"></figure><a target="_blank" href="https://makerworld.com/de/models/84388" rel="nofollow noopener">5x5x3U</a>254mm x 256mm x 33mm</td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_2c343b472c0cb.png"></figure><a target="_blank" href="https://makerworld.com/de/models/110751" rel="nofollow noopener">5x5x3U</a>490mm x 256mm x 33mm</td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_8a78ae8dd53b1.png"></figure>5x5x3U</td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_55b6dce44f955.png"></figure><a target="_blank" href="https://makerworld.com/de/models/87380" rel="nofollow noopener">5x5x4U</a>254mm x 256mm x 40mm</td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_fb757f49d8ac3.png"></figure><a target="_blank" href="https://makerworld.com/de/models/110781" rel="nofollow noopener">5x5x4U</a>490mm x 256mm x 40mm</td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_6238d5bbb41b8.png"></figure>5x5x4U</td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_1d0b47626731.png"></figure><a target="_blank" href="https://makerworld.com/de/models/87382" rel="nofollow noopener">5x5x6U</a>254mm x 256mm x 54mm</td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_3947b3d4de8.png"></figure><a target="_blank" href="https://makerworld.com/de/models/110791" rel="nofollow noopener">5x5x6U</a>490mm x 256mm x 54mm</td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_e91f9bc384fc8.png"></figure>5x5x6U</td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_591bd9f03c6ee.png"></figure><a target="_blank" href="https://makerworld.com/de/models/87383" rel="nofollow noopener">5x5x8U</a>254mm x 256mm x 68mm</td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_ff333f2cf79a3.png"></figure><a target="_blank" href="https://makerworld.com/de/models/110817" rel="nofollow noopener">5x5x8U</a>490mm x 256mm x 68mm</td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_9ce4e42f0bcf1.png"></figure>5x5x8U</td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_54de9ddc754e7.png"></figure><a target="_blank" href="https://makerworld.com/de/models/87384" rel="nofollow noopener">5x5x10U</a>254mm x 256mm x 82mm</td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_1695666dcbb0d.png"></figure><a target="_blank" href="https://makerworld.com/de/models/110823" rel="nofollow noopener">5x5x10U</a>490mm x 256mm x 82mm</td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_994a691dcc7cd.png"></figure>5x5x10U</td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_da082adf8555a.png"></figure><a target="_blank" href="https://makerworld.com/de/models/87385" rel="nofollow noopener">Lid</a>254mm x 256mm x 10mm</td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_a371eb43475a6.png"></figure><a target="_blank" href="https://makerworld.com/de/models/110831" rel="nofollow noopener">Lid</a>490mm x 256mm x 10mm</td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000085205/design/2023-12-28_02c666d9d2951.png"></figure>Lid</td></tr></tbody></table></figure>&nbsp;

Modular Rack System for Gridfinity - Overview

Random

COLOCO

Only 6 15x4 magnets are needed to have a magnetic suction scheme for rotating the rice box material tray, It can be adapted to commonly used rice boxes to prevent them from frequently opening and affecting the moisture-proof effect of the material tray. The test results were excellent and very suitable for those who have not yet purchased AMS. Strongly recommended!!! Paired with the A1mini printable rice box material tray holder that I designed before, the effect is unbeatable, and the rice box is moisture-proof enough to graduate!The diameter of the large nut is 7cm, and if you need a larger diameter, you can download the 3mf of the 8.4cm large nut separately.仅需要6颗15x4的磁铁，即可拥有米箱料盘回转的磁吸方案，可适配常用米箱，防止米箱经常打开而影响料盘的防潮效果。测试后效果非常棒，非常适合手头还未入手AMS的小伙伴。强烈推荐！！！搭配我之前设计的A1mini可打印的米箱料盘支架，效果无敌，米箱防潮可以毕业了！大螺母直径7cm，需要更大直径可以单独下载8.4cm大螺母的3mf&nbsp;Introduction and installation video介绍及安装视频<a target="_blank" href="https://www.bilibili.com/video/BV18x4y1q7Xd/?share_source=copy_web&amp;vd_source=887edaf19ea101d7ffde181953e749de" rel="nofollow noopener">https://www.bilibili.com/video/BV18x4y1q7Xd/?share_source=copy_web&amp;vd_source=887edaf19ea101d7ffde181953e749de</a>&nbsp;A1mini可打印的5.8L米桶料盘防潮湿度计一体底座<a target="_blank" href="https://makerworld.com/zh/models/385538#profileId-302513" rel="nofollow noopener">https://makerworld.com/zh/models/385538#profileId-302513</a>&nbsp;&nbsp;
