<h3>NOTE:</h3><ul><li>Please read the instruction guide below</li><li>I do my best to double-check and test the print profile I create. They are up to date with whatever changes I made to the designs. If you are using profiles made by others, please check if they are updated.</li></ul><p>&nbsp;</p><h3>UPDATE: 3 JAN 2024</h3><p>I have added a version of the BIN that will work with the Bambu Lab Z-Stiffener. It is on Build plate 2.</p><figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/346126/2024-01-03_8bd5d74720bb9.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/346126/2024-01-03_16b719cd2144e.png"></figure></td></tr></tbody></table></figure><p>&nbsp;</p><h3>INTRODUCTION</h3><p>All Bambu printers poop. So here is a Poop Management System (PMS) for A1. The system consists of a purge guide and a bin. I have added the <a target="_blank" href="https://makerworld.com/en/models/91481#profileId-97865" rel="nofollow noopener">Stabilization Bracket for A1</a> in this project build plate. You might want to try using it with/without the <a target="_blank" href="https://makerworld.com/en/models/90586#profileId-96991" rel="nofollow noopener">GRIP bracket</a> to improve the stability of the A1 printer.</p><figure class="table" style="width:89.28%;"><table class="ck-table-resized"><colgroup><col><col></colgroup><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/346126/2023-12-13_c0abab96e0d06.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/346126/2023-12-13_ac7c55c15ff49.jpg"></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/346126/2023-12-13_170cda32f15e3.jpg"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/346126/2023-12-13_508805f48faf6.jpg"></figure></td></tr></tbody></table></figure><p>&nbsp;</p><h3>INSTRUCTION</h3><ul><li>Print build plates 1 & 2</li><li><span style="background-color:rgb(255,255,255);color:rgb(33,43,54);font-size:16px;">Paste a piece of tape over the area as shown in the image below. During purging, the tip of the purge can still be molten and can accidentally adhere to the wall. The tape helps to reduce the chance of this happening.</span></li><li><span style="background-color:rgb(255,255,255);color:rgb(33,43,54);font-size:16px;">Slide the purge guide into the purge wipe as seen in the image. It should fit snugly.</span></li></ul><figure class="table" style="width:96.81%;"><table class="ck-table-resized"><colgroup><col><col></colgroup><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/346126/2023-12-13_19a14b0cca0d8.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/346126/2023-12-13_aa7a5482d8532.jpg"></figure></td></tr></tbody></table></figure><p>&nbsp;</p><ul><li>The bin should be fitted into the left Z-beam as seen in the image below.</li></ul><figure class="image image_resized" style="width:59.91%;"><img src="https://makerworld.bblmw.com/makerworld/draft/346126/2023-12-13_64830ac1a7016.jpg"></figure><p>&nbsp;</p><ul><li>Turn on the A1 printer and do a home to ensure proper clearance.</li><li>All the best and welcome to a poop-free table.</li></ul><p>&nbsp;</p><p>&nbsp;</p><p>&nbsp;</p><p style="text-align:center;"><i>“Friends do not let friends poop everywhere…” Poobymeister</i></p><figure class="image image_resized" style="width:60.09%;"><a href="https://thangs.com/designer/DaveMakesStuff/3d-model/Doggy%20Poo%20Candy%20Box-973574" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/draft/346126/2023-12-13_e2df74deec799.jpg"></a><figcaption>Doggy Poo Candy Box by DaveMakesStuff</figcaption></figure><p>&nbsp;</p><h3>CONCLUSION</h3><p>To date, my designs are free to download and use. There is no Patreon or OnlyFan (hahaha). If you like my designs and wish to contribute to my coffee addiction & help fund the filaments and materials needed for prototyping, a donation of $5-$10 to <a target="_blank" href="https://ko-fi.com/thrutheframe" rel="nofollow noopener">Ko-fi</a> or <a target="_blank" href="https://www.paypal.com/paypalme/shannonheng" rel="nofollow noopener">paypal.me</a> will be greatly appreciated.</p><p>&nbsp;</p><h3><strong>CAVEAT</strong></h3><p>As with all my designs, Prototyping and testing were conducted to ensure printability and meet my own expectations. However, I understand it may and may not work for you. I would request that you read all instructions and print and install them at your own discretion.</p>
