Megumin233

鱼小兑

NAU模块化桌面支架说明书NAU Modular Desktop Stand Instruction Manual 大部分功能在视频中都有提到 其余还有几处可固定走线的位置，期待你解锁更多新功能Overview: The NAU Modular Desktop Stand boasts a myriad of functions, many of which have been highlighted in my video, with additional cable management features awaiting your discovery for even more utility.<figure class="image image_resized" style="width: 33.59%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000451095/design/2024-05-02_4bef7395861ca.jpg"></figure>**打印**&nbsp;打印文件为3mf文件，包含我设置好的切片参数，以180mm打印盘为基础设计，所以适配大部分打印盘尺寸 匹配自己的打印机型号、打印盘类型、耗材这三者即可打印 我使用的是petg，需要在底板喷胶，否则会翘边 组装组件为 底座+上半主体+耳机挂架+拓展增高模块+卡盒（可选）+任选组件 以按照我推荐的白灰蓝配色进行分盘，不需要ams（多色打印模块）Printing Guidelines:<ul><li>File &amp; Settings: The provided 3mf file includes pre-configured slicing parameters tailored for a 180mm print bed, ensuring compatibility with most bed sizes. Adjust your printer model, bed type, and filament choice accordingly. I utilized PETG, requiring bed adhesion to prevent warping.</li><li>Components: Assemble with the base, upper body, headphone hanger, expansion riser module, card holder (optional), and any chosen accessories. For aesthetics, follow my recommended white-gray-blue color scheme without the need for multi-color printing modules.</li></ul><figure class="image image_resized" style="width: 28.52%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000451095/design/2024-05-02_adee64458a024.png"></figure> **安装**&nbsp;在测试后我使用0公差设计，支架主体的槽口有一定形变能力，在使用petg材料时可以提供足够的固定力，pla未测试 但即便是同类型材料，不同品牌的收缩性亦有区别， 所以可能导致部分组件太松或者太紧，以下是我的建议&nbsp;如果组件太紧 请尝试打磨与槽位结合的几条边缘 尤其是有brim的组件&nbsp;如果组件太松 对于需要受力的组件，太松会直接导致掉落，最好的方法是确定位置不需要更换后，再用胶水固定 其次建议垫些薄纸片加固，这样不会丧失灵活性&nbsp;打印完成可在底部预留的四个圆孔位置贴上胶贴防滑 如果希望支架整体可以更稳一点，除了在底部放物品外，可以打印时提高底座的稀疏填充的百分比（默认是10%的自适应立方体）&nbsp;Assembly Instructions:<ul><li>Design Tolerance: After thorough testing, a zero-tolerance design was adopted. The stand&#39;s slots possess some flexibility, providing ample retention with PETG; PLA no tested. Due to varying shrinkage rates across brands, components may fit too tightly or loosely. Here are my recommendations:<ul><li>If Too Tight: Gently sand the edges that mate into the slots, particularly those with brims.</li><li>If Too Loose: Glue is ideal for load-bearing parts if they&#39;re excessively loose after positioning. Alternatively, consider slipping thin paper shims to reinforce without compromising adjustability.</li></ul></li><li>Anti-Slip Measures: Attach adhesive pads to the four designated circular holes on the base for added stability. Enhance overall sturdiness by increasing the infill density of the base during printing (default is 10% adaptive cubic).</li></ul>&nbsp;**修改**&nbsp;我提供了以fusion360为基础的源文件，如果有一定基础，你可以打开后自定义修改组件&nbsp;未来可能的升级方案 1.便携式SD卡盒设计 2.可旋转的地台 3.超级模块化+更多可替换组件Customization:<ul><li>Source Files: For advanced users, Fusion360 source files are included, enabling customization of individual components.</li></ul>Future Upgrade Possibilities:<ol><li>Portable SD Card Holder Design</li><li>Rotatable Base Platform</li><li>Enhanced Modularity + Additional Swappable Components</li></ol><figure class="image image_resized" style="width: 31.3%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000451095/design/2024-05-02_a5de48f511f26.png"></figure>感谢大家的支持，我是鱼小兑，https://space.bilibili.com/313019007 别忘了常来B站看看我的新视频哦~Acknowledgments: Thank you for your support. I&#39;m YOTURN, remember to drop by my Bilibili space at <a target="_blank" href="https://space.bilibili.com/313019007" rel="nofollow noopener">https://space.bilibili.com/313019007</a> for fresh content and videos!Please note that this translation captures the essence of your original text and aims to maintain clarity and technical accuracy for English readers.

NAU模块化桌面支架 Modular Desktop Stand

收纳

幻模堂

此款模型的创建为了满足日益充盈的收纳需求，我所使用的打印设备为X1CC打印参数层高0.2，填充15，材料选用了PETG，拼装的连接螺栓为M5*12，螺母为M5。拼装比较简单，可以无缝拼接，板块交界处亦可以悬挂置物架。The creation of this model is to meet the increasingly filling storage needs. The printing equipment I used is X1CC, with a printing parameter layer height of 0.2 and a filling of 15. The material used is PETG, and the assembled connecting bolts are M5 * 12 and the nuts are M5. Assembly is relatively simple and can be seamlessly assembled. Shelves can also be hung at the junction of plates.

IKEA宜家洞洞板

洞洞板

muitxer

Joystick guards for traveling without a case.<figure class="media"><div data-oembed-url="https://www.youtube.com/shorts/1GBEGRWATAA"><div class="ck-media__wrapper" data-oembed-url="https://www.youtube.com/watch?v=1GBEGRWATAA"> <div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"> <iframe src="https://www.youtube.com/embed/1GBEGRWATAA" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="encrypted-media" allowfullscreen=""></iframe> </div> </div></div></figure>&nbsp;<ul><li>Use 6x2mm magnets and snap in gently. If they are lose, can be glued (not my case at least).</li><li>No supports needed.</li><li>Bolts are not needed since it has a hinge printed in place</li></ul>

Steam Deck Joystick Guards

steamdeck

Techmo3D

This is a cable holder for the Bambu Lab A1 which is attached to the upper X axis to keep the AMS cable outside the printing plate and the printing area to prevent damage to the cable or the component.&nbsp;The holder was printed from PLA grey, the strength of the material is sufficient as it is not mechanically stressed.&nbsp;The following parameters were adjusted in Bambu Studio:<ul><li>Thickness: Wall lines: 3</li><li>Thickness: Filling pattern: Gyroid </li><li>Support: Support stuctures active</li><li>Type: Tree, Support critical areas only</li><li>Other: Border type: No border</li></ul>I wish you lots of fun and success with printing.Your Techmo3D <a target="_blank" href="https://www.instagram.com/techmo3d/" rel="nofollow noopener">Techmo3D (@techmo3d) • Instagram-Fotos und -Videos</a>

收纳

洞洞板

steamdeck

A1配件
