IntroI was tired of looking for a generic modular setup for Socket trays that you could swap sizes and completely customize on the fly when adding a new socket (or losing one). So I made a simple model and expanded it to fit any possible size(outside of oversized) and am self dubbing it the Gridfinity Universal Socket Trays (G.U.S.T). This setup was not build to maximize space, but instead to maximize visibility and simplicity by being able to reorganize at any point in time without the need to reprint everything. Enjoy rate and let me know if there are any issues not noted below. If you find you need a specific size I don&#39;t have in here, let me know. Lastly let me know if there are any improvements you would like to see made. &nbsp;Links to the full G.U.S.T. setsI don&#39;t usually like it when people put all their “check out my models here” but by (an unexpected) amount of demand, here are the links to ONLY the models related to the G.U.S.T. sets to help users navigate to the other sets directly online or in the app,&nbsp;<a target="_blank" href="https://makerworld.com/en/models/493996#profileId-407884" rel="nofollow noopener">Standard short sockets of 12-36mm diameter</a><a target="_blank" href="https://makerworld.com/en/models/495122#profileId-409200" rel="nofollow noopener">Deep sockets up to 68mm in height and 12-31mm in diameter</a> (Will be adding up to 39mm soon)<a target="_blank" href="https://makerworld.com/en/models/502884#profileId-418220" rel="nofollow noopener">the Deeper sockets up to 100mm in height and 12-39mm in diameter</a><a target="_blank" href="https://makerworld.com/en/models/495080#profileId-409150" rel="nofollow noopener">Label inserts for all three sets</a>&nbsp;Model Features<ul><li>These holders will fit any socket set since you measure your own sockets and print the appropriate tray pieces</li><li>The tray system is based on the Gridfinity standard and will fit all standard Gridfinity bases</li><li>on the bottom of the trays, I included the standard 6x2mm magnet inserts. This helps keep the tray from coming out of their spot in the grid if you slam your tool drawers like I do</li><li>The optional label system designed was made to be very simple. Doesn&#39;t require magnets, Stays secure even when slamming the tool drawers.</li><li>NO Guess work needed, when sizing out you entire socket collection</li><li>Got extra random sockets? Print one off socket trays for each one to store in the corner of your drawer</li></ul>Instructions<ol><li>download and open the profile in Bambu studio  </li><li>Take note of the current socket height. If this height is taller than or equal to 100mm…..sorry. I didn&#39;t design a universal set for DEEEEEEEEEP sockets yet. If you have a set that is more than 100mm in height. leave me a comment or a message of what size your socket is and I&#39;ll start working on an addition to the sets.  </li><li>measure your Socket diameter (do not use the socket size printed on the socket as the size you use to select a tray) This set is 12-39mm diameter by up to 99.9mm in length <img class="image_resized" style="width: 16.5%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000502884/design/2024-06-19_ae731cfec37d2.jpg">  </li><li>round the diameter up to the nearest whole number (ex. like the above, anything between 17.01-18.00mm goes to 18mm)  </li><li>Add a new empty plate and select it <img class="image_resized" style="width: 27.19%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000502884/design/2024-06-19_88b1516efebf6.png">  </li><li>Right click on the model for the needed size (in this ex. its 18mm) and hit clone, it should clone to the selected empty plate <img class="image_resized" style="width: 26.06%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000502884/design/2024-06-19_dd40c5c6fe8ae.png"></li><li>Repeat for all socket sizes needed and then print. <img class="image_resized" style="width: 37.91%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000502884/design/2024-06-19_91c1acb26c49a.png">  </li><li>go to my profile to find the <a target="_blank" href="https://makerworld.com/en/models/495080#profileId-409150" rel="nofollow noopener">Label inserts</a>, premade with many common sizes. linked below. Or just ignore the label part of this if you don&#39;t want to do it. (the labels make it look really nice and easy to read everything and return it to the right spot in an instant.)  <img class="image_resized" style="width: 45.18%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000502884/design/2024-06-19_4638d3fbeb1f.jpg"></li><li>For your sockets that are less than 68mm in length, go to <a target="_blank" href="https://makerworld.com/en/models/495122#profileId-409200" rel="nofollow noopener">this model</a> For your standard short sockets, go to <a target="_blank" href="https://makerworld.com/en/models/495080#profileId-409150" rel="nofollow noopener">this model</a></li></ol>IssuesIf a description is still below here, then I haven&#39;t fixed it yet. If you find any new issues, let me know in a comment or a message an I&#39;ll try and resolve it as soon as possible.
