<h2 style="text-align: center">🧮 I designed a 3D-printable mechanical calculator that can perform ➕ addition and ✖️ multiplication!</h2><h3 style="text-align: center">Available in 2 Styles: 🐸 Froggy or 🔢 Basic</h3><h4 style="text-align: center">Entirely 3D-printable, no extra parts required!</h4><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000510362/design/2024-06-23_9e1aa6c2c68a2.gif"></figure><boostme><boosttitle>Boost Me</boosttitle><boostcontent>Huge thanks to everyone who likes, downoads, and comments on my models! All my models are free and always will be, but if you REALLY like this one, please consider boosting it or subscribing to my YouTube channel. Cheers!</boostcontent></boostme><h2>How to Use It</h2>Move the feet to the numbers you want to add/multiply and the hands will point to the answer!There are 2 bases available to print: ✖️ Multiplication and ➕ Addition.<h2>How it works</h2>📐 This mechanical calculator operates using a planar hinge mechanism involving symmetrical isosceles right-angled triangles. The hypotenuses of these triangles slide along number lines, while their vertices are connected, forming a hinged rhombus. By placing the sliding points on different integers, the calculator determines the midpoint of these integers to display the results. This model is based on <a target="_blank" href="https://patents.google.com/patent/US1188490A/en" rel="nofollow noopener">the expired “educated monkey” patent from 1915</a>.<figure class="image image_resized" style="width: 77.87%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000510362/design/2024-06-23_64af858aedd67.png"></figure><h2> </h2><h2>Assembly Guide</h2><h3>Froggy Version:</h3>Step 1: Place the Screws, Feet, and Vertical Bar onto the Base.<figure class="image image_resized" style="width: 70.46%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000510362/design/2024-06-23_fa5748c5a3b0a.png"></figure>Step 2: Add the Legs. The Left Leg must go on top of the Right Leg as pictured.<figure class="image image_resized" style="width: 70.28%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000510362/design/2024-06-23_08df6749dcdd9.png"></figure>Step 3: Add the Right Hand. (Note: The Right Hand is thicker than the Left Hand)<figure class="image image_resized" style="width: 70.15%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000510362/design/2024-06-23_6eb50e987b8cb.png"></figure>Step 4: Add the Left Hand.<figure class="image image_resized" style="width: 70.46%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000510362/design/2024-06-23_ba045250fae8c.png"></figure>Step 5: Add the Face.<figure class="image image_resized" style="width: 70.09%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000510362/design/2024-06-23_2bdd47335ec9f.png"></figure>Step 6: Add the Nuts. You may need to tighten/loosen them for smooth operation.<figure class="image image_resized" style="width: 70.85%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000510362/design/2024-06-23_d300c9da961c1.png"></figure>Step 7: You&#39;re done!<figure class="image image_resized" style="width: 74.17%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000510362/design/2024-06-23_9eb1d1edba93a.gif"></figure><h3> </h3><h3>Basic Version:</h3>Step 1: Place the Screws, Feet, and Vertical Bar onto the Base.<figure class="image image_resized" style="width: 70.1%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000510362/design/2024-06-23_81a2492b8de46.png"></figure>Step 2: Add the Legs. The Left Leg must go on top of the Right Leg as pictured.<figure class="image image_resized" style="width: 69.91%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000510362/design/2024-06-23_1c36c80c6e616.png"></figure>Step 3: Add the Right Hand. (Note: The Right Hand is thicker than the Left Hand)<figure class="image image_resized" style="width: 70.13%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000510362/design/2024-06-23_b35e6f65ba121.png"></figure>Step 4: Add the Left Hand then add the Nuts. You may need to tighten/loosen them for smooth operation.<figure class="image image_resized" style="width: 70.09%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000510362/design/2024-06-23_ed3c8fc1bbb41.png"></figure>

Mechanical Calculator (Addition & Multiplication!)

Kiddos

Roger Borchelt

Here is the Michigan light box I made. I thought I had better pictures. But it did turn out great. there is a clear layer to hold the thin color layers together. I used Inland Natural. Im not sure if or how white would work. I also used Inland Yellow and Inland Dark Blue and Bambu Black.

Michigan Light Box

college light boxes

realdawnerd

Needs to be printed diagonally on most printers. You can just barely squeeze it in on a Bambu without rotation, can print 4 at a time if you really wanted to. Designed to match the height of an ikea alex top drawer with the basic gridfinity baseplate inserted.&nbsp;Larger bins like this do like to warp but I've printed a bunch now with my Bambu Printers and haven't had any real warping using the two profiles I've uploaded. I prefer the angled one as it keeps the PTFE tube and print head from making excessive noise.&nbsp;I'm working on a bringing the print time down in a version 4!

Scotch Scissor Holder for Gridfinity

Gridfinity

SOME Studio

STEM desk model.<ul><li>Science - rocket</li><li>Technology - computer</li><li>Engineering - hard hat</li><li>Math - mathmatical symbols</li></ul>Great for teachers and classrooms.&nbsp;Available in 1 or 4 colors. Small (100mm long), medium (150mm long), and large (200mm long).

STEM Desk Sculpture

Engineering Classroom

Deran 3D print

Simple base plate for classic Lego bricks. My son loves it! :)&nbsp;Dimension are 231x231mm, optimized for Bambu Lab plate.&nbsp;Please write me if you need other dimension.

Lego base plate 231x231mm

Lego

GiorgioMiglia

Remix of <a href="https://www.printables.com/model/63026-print-in-place-customizable-cases-for-button-type-" rel="nofollow">this project</a>, it holds up to 6 batteries

Print-in-Place LR44 battery case

Organization

Shortfin3D

A simple solution to solving the filament spool drag on the rear spool holder. Great for printing with TPU or cardboard spools as this reduces the strain on the extruder.&nbsp;UPDATE: I have tweaked the model dimensions of the roller to allow for some more tolerance with different spool holders. Some people reported it not fitting. These have been added as v2 parts. The originals are still there for people who liked the tighter fit.&nbsp;3 parts to print:<ol><li>Thin spacer which inverts the keying of the rear spool holder allowing you to bolt it in upside down. Uses exactly the same bolts as are currently fitted, no need to find extras.</li><li>The cradle which rests in the now upside down spool holder.</li><li>The spindle which is designed to combine with 2x standard 608 bearings and then rests in the cradle.</li></ol>Extra parts needed:2x 608 bearings (22x7mm w 8mm hole)&nbsp;It's been designed so the spindle is a few mm smaller than the bearings which provide a stop point so your filament roll won't make a run for it. Due to the space the bearings take up, it will only fit spools up to 72mm in width.
