[Intro]An A1 mini version of the Scifi crated I had previously created! Remodeled from scratch to fit the A1 Mini&#39;s bed size, while still retaining the looks of the original. This one has a full flip top! And includes magnets to help keep the lid closed and the choice of a knob or a key to keep it secure.&nbsp;This crate follows the same ideas and goals as the first one. Aiming to be a model that was bigger than the printers build volume, but didn&#39;t feel like just a chopped up to fit model. Also to make it fun and stylish! While still remaining practical.&nbsp;[Community Spotlight]<a target="_blank" href="https://makerworld.com/en/@mjrdcrker" rel="nofollow noopener">mjrdcrker </a>has made some 3d printable m3 nuts to help reduce the external hardware cost! Check them out <a target="_blank" href="https://makerworld.com/en/models/459843#profileId-368189" rel="nofollow noopener">HERE</a>. &nbsp;&nbsp;[What you&#39;ll need]&nbsp;Featured Filament: Bambu PLA Matte Lemon Yellow &amp; Bambu PLA Basic Blue Gray Bambu PLA Basic Bronze, Gold &amp; Bambu PLA Matte Charcoal&nbsp;Tools:Hex Driver/Alen Wrench #3Flat head screwdriverFile for cleaning up edges where the brim is used, or whichever tool you&#39;d prefer for the job.Drill bits for clearing out holesSome sort of pointy tool and/or tweezers for clearing out the pockets for the m3 nuts after the holes have been cleared&nbsp;Hardware:Screws1 - M3x6 - Used for the latch14 M3x8 - 2 used for the latch, 12 for the sides12 M3x12-16 - Used to attach the sides to the mid section. 12mm to 16mm screws work.2 M3x16 - Used for the hinges!24 M3 NutsMagnets4 4x6mm magnets Here&#39;s a few sources! <a target="_blank" href="https://www.amazon.com/dp/B075PMYRFT" rel="nofollow noopener">Amazon US 1</a>, <a target="_blank" href="https://www.amazon.com/Hyoocct-Decorative-Magnets-Whiteboard-Refrigerator/dp/B0C99NPBS4/ref=sr_1_3?dib=eyJ2IjoiMSJ9.FHDJ0oqOVxvWcW1x95_xHo2MW_YBNVZR7aWRaQYLpE3grQUtv0WGjgnHvXRgNq3rnODupeRRTnaORbJSTkeJhUlnWBUziN9bBpPsSSRaO9WcXrywYt3pVaUMfvKpuUiuCNxuTfH1iH6cxOEkrMbGvs7CbXCdLMFXYt_adOTHK3oK9u_4Lh4A6V7IQrd0RHFdZt6vZzSD5n60Bx1GTPvjDLIIoX1d8WlgDMyeE22j6YA.TMWFX8yKk1vTMb3GPUUZAs5LPzZLguMFGHwrWC67jCI&amp;dib_tag=se&amp;keywords=4x6mm+magnet&amp;qid=1713635375&amp;sr=8-3" rel="nofollow noopener">Amazon US 2</a>, <a target="_blank" href="https://suprememagnets.com/products/neodymium-magnet-4x6mm-disc" rel="nofollow noopener">SuperMagnets</a>, <a target="_blank" href="https://dev.apexmagnets.com/magnets/4mm-x-6mm-cylinders-neodymium-magnet" rel="nofollow noopener">Apex Magnets</a>&nbsp;[Assembly]First we&#39;ll want to prepare the pieces once they&#39;ve been printed. We&#39;ll want to drill out all of the holes. The holes were capped off in key locations to help get a cleaner print.<figure class="image image_resized" style="width: 47.57%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000375579/design/2024-03-16_1e2a22250a916.png"></figure>In the mid sections, we&#39;ll have 8 holes on each side to drill out. Be careful not to go too far in, as we only want to clear out for the M3 Nut pockets. Once we have the holes drilled out, clear out the pockets and make sure they are as free from debris as you can get them. Insert the M3 Nuts now and make sure they are firmly pressed into place. They can be a little loose, so may fall out if you jiggle the model around too much.<figure class="image image_resized" style="width: 53.2%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000375579/design/2024-03-16_62ffdf5307b5a.png"></figure>Before we move on to the end sections, we&#39;ll want to install the latch. You can do this at any point, but it&#39;s easiest to do before the main box is assembled. USe a M3x6 screw for the lower section. To screw the latch/knob together, we&#39;ll use two M3x8 screws!<figure class="image image_resized" style="width: 54.41%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000375579/design/2024-03-16_fc03d5936c46.png"></figure>On the end sections, drill out the holes as indicated. There will be 9 holes on either side to clear out. While we&#39;re here, we&#39;ll also want to insert the M3 nuts into their seated beds. We can do this later, but it&#39;ll be much easier to do it now before we start assembling everything. Make sure to press them in as much as you can.<figure class="image image_resized" style="width: 52.78%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000375579/design/2024-03-16_677422314cf9a.png"></figure>Now we&#39;ll start attaching the sides to the mid sections. Use M3x12-16 screws! I mean, you can use from sizes 12 to 16mm long. 12 is the minimum! For the hinges, use M3x16mm screws! We want that little extra length, for sure. Make sure not to over-tighten the screws as it can deform the plastic and cause troubles with the fit!<figure class="image image_resized" style="width: 52.07%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000375579/design/2024-03-16_5e88ab0baf27.png"></figure>For the hinge, we&#39;ll want to make sure the screw is in all the way. If it doesn&#39;t feel like it&#39;s all the way in just by pushing it, then screw it in to help guide it past any points of friction that might be holding it up. Along with the screw plugs for the ends, there should have been two little bars which we&#39;ll insert into the holes for the hinge screws, to help keep them firmly secure.<figure class="image image_resized" style="width: 50.71%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000375579/design/2024-03-16_adc2516606597.png"></figure>We&#39;ll attach the end caps using M3x8 screws! This can be a little fiddly, as the clearances are tight for the depth of the screws. You may need to press the M3 nut in a little more to help it catch the threads of the screw. There will be 6 screws on either side.<figure class="image image_resized" style="width: 55.38%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000375579/design/2024-03-16_08297f81c7a8e.png"></figure>Use a flat headed screw driver to install the screw plugs. Careful not to over tighten them!<figure class="image image_resized" style="width: 54.28%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000375579/design/2024-03-16_2b6946d6f537f.png"></figure>Lastly, we&#39;ll install the magnets! I&#39;ve adjusted the clearence on this model so should be easier than previous models I&#39;ve done that use these magnets. Press them in on one side, using like a screw driver to help guide them. Then just put the magnets for the other side ontop of the ones you just inserted and press the lid down to press everything into place!<figure class="image image_resized" style="width: 52.13%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000375579/design/2024-03-16_82972264a633.png"></figure>That&#39;s it! Enjoy!&nbsp;-------If you like my work, consider showing your love by <a target="_blank" href="https://www.buymeacoffee.com/josh3d" rel="nofollow noopener">Buying me a coffee</a>. Additionally, if you&#39;re looking to sell prints of my design, please check out my <a target="_blank" href="https://www.patreon.com/josh3d/" rel="nofollow noopener">Patreon</a> page for more information.
