JesseZhang

chameko小廢物電波塔

<blockquote>12/06 After many tests, I successfully found out the cause of the assembly problems reported by some users, and modified the side panel file "AMS Dry Box-SW_v2".NOTE!I Designed this model not only for ams, I also used it in the vacuum bag that holds the filament, so I needed tight tolerances to make the box strong enough. The tolerance is 0.3mm, please be sure to confirm before printing this model.</blockquote>Open the side lid and pour about 60g of silica.<img src="https://makerworld.bblmw.com/makerworld/draft/306465/2023-12-25_92a6870d48198.jpeg">&nbsp;There is a buckle design on the top, please make sure it is buckled correctly when installing.<img src="https://makerworld.bblmw.com/makerworld/draft/306465/2023-12-25_2f71bc9cf33e9.png">&nbsp;&nbsp;The front and back of the V2 version have relaxed tolerances in most areas, making it easier to install. I kept the last small area because without this part, you might get the box and slide it open like in the second picture, resulting in a mess.Please be careful not to install it in the wrong direction when installing.<img src="https://makerworld.bblmw.com/makerworld/draft/306465/2023-12-25_fcf2db2bab532.jpg"><img src="https://makerworld.bblmw.com/makerworld/draft/306465/2023-12-25_210d78c4699ec.jpeg">&nbsp;If you have trouble assembling them, try using a heavy object to knock them into the correct position.<img src="https://makerworld.bblmw.com/makerworld/draft/306465/2023-12-25_e0f13f6121362.jpeg">&nbsp;As for why I used this complex design, it was because I considered that he had to withstand several kilograms of impact from the filament, so I wanted to distribute the force as equally as possible to each part.<img src="https://makerworld.bblmw.com/makerworld/draft/306465/2023-12-25_90a605e9c843e.png"> <blockquote>Also I have a beautiful model related to AMS! Don’t miss it!</blockquote><figure class="image image_resized image-style-side" style="width:56.75%;"><a href="https://makerworld.com/zh/models/99476#profileId-106044" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/draft/306465/2023-12-23_3d850a0169288.jpg"></a></figure>Do you always find the AMS feeder difficult to press? Are the models on the Internet very difficult to install? I have improved and carefully designed this model. Please be sure to try it!(click on the image to go to the page!)&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;<blockquote>----------中文解說----------</blockquote>打開側蓋後約可倒入60g的乾燥劑. 上方具有卡扣設計,安裝時請確認有正確的扣上.&nbsp;V2版本的正面與背面放開了大部分區域的公差,使其較容易安裝. 我保留了最後一小區域,因為沒有這個部分的話,你可能再拿取盒子時像第二張圖一樣滑開,導致一團糟. 安裝時請注意不要裝錯方向.&nbsp;如果你在組裝上遇到了困難,可以嘗試使用重物敲擊他們使其安裝至正確的位置. 至於為什麼使用這種複雜的設計,是因為我考慮到他必須承受數公斤來自線材的撞擊,因此我想盡可能地讓力量平均分攤到每個部分.

AMS Silica Gel Box[V2]

打印机配件

Amao Chan

1. This is an 3mf file for testing the accuracy of the gap, which contains 4 kinds of movable structures that are often used in my design. 2. Try printing this file before printing my other works to adjust the gcode settings. When confirming that all 4 parts can be rotated, print my other works with the same settings, which can increase the printing success rate. 3. Try controling the gap of movable parts by adjusting the flow rate. 4. If the flow rate drops below 90 and the result still fails, it may be due to the adjustment problem of the machine itself. 5. Whether it can be turned or not, it can be used as a key ring, do not waste materials.&nbsp;1.這是一個測試間隙精準度的3mf檔案，共包含了4種時常用於我的設計中的可動結構。 2.在印我的其他作品前先試印這個檔案，以調整gcode設定，在確定4個部分都可轉動時，就以相同的設定來列印我其他作品，這樣可增加列印成功率。 3.以調整流量方式來控制可動零件間隙。 4.流量降到90以下還無法成功列印，可能是機器本身調校問題。 5.不管能否轉動還是可以拿來當鑰匙圈，別浪費了材料。

Gap test fish

工具

CrazyCoolPrints3D

This is an X1C Desktop Organizer. It was made to organize anything you want. A structured insert is coming soon. This doesn’t need an AMS! It can be printed with layer changes for multi-color. A P1S / P1P version is on the way! This model can also be sized up. Patreon (For Commercial Licenses To Sell And More Models): <a target="_blank" href="https://www.patreon.com/user?u=80724611" rel="nofollow noopener">https://www.patreon.com/user?u=80724611</a> &nbsp;Step By Step Process:<ol><li>Print the parts (made to work with or without the AMS).</li><li>Slide the parts in the order shown in the assembly file (glue shouldn’t be needed).</li><li>Slide the insert in, multiple versions will be available but currently there is only an empty one.</li></ol>&nbsp;Different Versions:P1S Version: <a target="_blank" href="https://makerworld.com/en/models/14742#profileId-14556" rel="nofollow noopener">https://makerworld.com/en/models/14742#profileId-14556</a>P1P Version: <a target="_blank" href="https://makerworld.com/en/models/26072#profileId-22450" rel="nofollow noopener">https://makerworld.com/en/models/26072#profileId-22450</a>&nbsp;Update Log:(9/12/23): Released&nbsp;(Please report any issues to my discord: coaster fan#4551)

打印机配件

工具

有意思
