This lampshade is designed for the <a target="_blank" href="https://makerworld.com/sv/models/13717#profileId-13429" rel="nofollow noopener">Bambu Led Lamp 001</a> kit ←- Follow this link to get the model for the base that holds the electronics and that this globe shade locks into.&nbsp;This is a moon lithophane model for the LED Lamp kit base built using NASA SVS data.&nbsp;Before printing, it is highly recommended to test and calibrate the filaments. Test Prints are provided in a profile to test the trickier parts of the print, in particular the top of the moon. Printing the sliced off moon top will give an idea if the flow rates need to be calibrated or if the layer heights need refining.Both of these are eSun PLA, and both were printed using the same eSun PLA+ profile. <img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000031191/design/2023-10-06_e7cbdab0e3545.jpg"> The one on the left (&#34;creamy&#34;) needed different flow rate settings to avoid the gaps in the thin walls. Moral of the story: spend the extra 20 minutes to at least run the Auto Calibration for a new filament (and Manual isn&#39;t so bad to do either particularly if you print on the textured plate).&nbsp;The extra big brim is out of an abundance of caution. There is nothing worse than being ten minutes from the end of a 17 hour print and hearing *CRACK* followed by a spaghetti detected notification. If the test print indicates your filament needs a small center support for the top of the moon, “Normal/Snug” supports will work best. Use Manual supports (Auto will result in a ton of exterior supports for the base of the moon) and paint a small dot in the underside of the top of the Moon. The latest version of the model has been made a little thicker and is more forgiving for printing with most filaments. The part that interfaces with the lamp kit base can easily be made a different filament to match the LED holder material or just for variety. Just set the base filament for the “ModifyBaseSettings” modifier. Doing will require only one filament purge, no prime tower is necessary.<figure class="image image_resized" style="width:41.3%;"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000031191/design/2023-10-06_33ea3c815b5ef8.png"></figure>&nbsp;If using the modifier to make a material change at the base, make sure to pick two filaments that have good adhesion to each other.Because the print requires supports in the base and cleanly removing those supports is important for a snug fit to the lamp kit base, a test print is provided to make sure the filament and support settings will release cleanly. Normal snug supports provided the best results (tree supports required much more effort).&nbsp;<figure class="image image_resized" style="width:17.23%;"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000031191/design/2023-10-06_f00e2d2199c81.jpg"></figure>&nbsp;If you do use the center support, when removing don&#39;t pull at individual folds from the bottom. Use something to grab on multiple folds as far up as possible (a pair of kitchen tongs works well) and twist.<figure class="image image_resized" style="width:17.52%;"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000031191/design/2023-10-06_c2509972a68348.jpg"></figure>Twisting will put less stress on the top of the sphere and less risk of pulling away the moon surface. If you have wisps of filaments, resist the urge to use a heat gun because the variable thickness of the shell will contract non-uniformly under the heat. This is the result using a heat gun on a lithophane:<img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000031191/design/2023-10-06_a27a97fbc55ec.jpg">&nbsp;

Moon Globe for LED Lamp 001

visual

mcmaven

This is a 3D-printed model of a triple-axis tourbillon, which is based on the tourbillon in a Jacob and Co. Twin Turbo Furious watch. A tourbillon is a mechanism employed to counteract the effects of gravity within a watch. This intricate model includes an escape wheel, triple-axis outer frame, and a base with an integrated motor. It functions on the same fundamental principles as a traditional watch tourbillon.&nbsp;With precise assembly and calibration of the escape wheel, spring, and base drive gear, this tourbillon can smoothly rotate in three axes and maintain accurate timekeeping. The provided print settings in the Triple-axis Tourbillon Model for Kit-007.3mf file are already customized to ensure that all screw holes are clear and ready for assembly.&nbsp;Printed plastic ‘screws’ are printed to scale and used as caps to cover the steel screws that actually hold it together.<a target="_blank" href="https://youtu.be/2-7S2i6AUyM" rel="nofollow noopener">Here </a>is a real-time video of the tourbillion in action.&nbsp;Note: There are two different designs defined for the Tourbillon: the 3MF version and the STL version.&nbsp;The 3MF (Triple-axis Tourbillon Model for Kit-007.3mf file) version was designed specifically to work with Bambu printers and the Bambu slicer, and uses the Triple-axis Tourbillon Model Hardware Kit motor to drive it. It is a slightly modified version of the original STL tourbillon version. To build the 3MF version you only need to order the <a target="_blank" href="https://shrsl.com/4d484" rel="nofollow noopener">Triple-axis Tourbillon Model Hardware Kit</a>, which provides all the non-printed parts (screws, bearings, shafts cut to length, motor, etc.) needed to build a complete model. <a target="_blank" href="https://www.youtube.com/watch?v=HRNbihDXNwE" rel="nofollow noopener">Here </a>is a video of assembling the 3MF version with the Bambu 007 hardware kit. Note that some of the sections in the Furious Build Notes PDF file below also apply to assembling the 3MF version, with the primary difference being the construction and components of the Base and the drive mechanism.&nbsp;The STL (Raw Model Files) version is a set od files that was designed to work with any printer or slicer. It also uses a more complex Arduino controlled stepper motor mechanism to drive it. To build the STL version you can order a kit of all the non-printed parts <a target="_blank" href="https://www.makerrx.com/collections/projectkits/products/twin-turbo-furious-tourbillon-kit" rel="nofollow noopener">here</a>, otherwise you will need to order the parts listed in the Furious Build Notes PDF instructions individually. If you order the STL version of the hardware kit or buy the parts yourself, you will need to program the firmware into the Arduino before it will work. The Furious Build Notes PDF file below, describes the assembly process for the STL version. For some of the larger parts, ‘full’ (e.g., Base Outer Ring.STL) and ‘split’ versions (Base Outer Ring a.STL and Base Outer Ring b.STL) of the same part are included. The ‘full’ parts require at least a 220x220 bed for printing. The ‘split’ parts may be printed separately on a diagonal on a smaller bed, then glued together to form the larger part.&nbsp;The following filaments can be used to create a model that looks like the pictured gold, silver, copper and black version:<ul><li><a target="_blank" href="https://shrsl.com/4cim5" rel="nofollow noopener">PLA Silk Gold</a></li><li><a target="_blank" href="https://shrsl.com/4cim4" rel="nofollow noopener">PLA Silk Silver</a></li><li><a target="_blank" href="https://shrsl.com/4cim3" rel="nofollow noopener">PLA Silk Copper</a></li><li><a target="_blank" href="https://shrsl.com/4cim2" rel="nofollow noopener">PLA Basic Black</a></li></ul>Here is a video of the construction of the 007 kit. And some sections in the Furious Build Notes.PDF file may be useful for constructing the 007 kit.<figure class="media"><div data-oembed-url="https://www.youtube.com/watch?v=bHEU9rnnu88"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/bHEU9rnnu88" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure>&nbsp;Disclaimer: This model is part of the Creator Program, When you purchase the Triple-axis Tourbillon Model Components Kit through the links below, creators may earn an affiliate commission as a reward of their work. (The creator program is currently in the trial phase. The application is not yet open to public.)&nbsp;The Hardware Kit for the Triple-axis Tourbillon Model for Kit-007.3mf file can be found here: <a target="_blank" href="https://shrsl.com/4d484" rel="nofollow noopener">Triple-axis Tourbillon Model Hardware Kit</a><a target="_blank" href="https://shrsl.com/4cfzj" rel="nofollow noopener">.</a>
