GregorB

dalet11

This is a fully calibrated profile for Elegoo PLA+ Black.This is a cheap and great filament I really like and print a lot, costs around 13-15$ per 1kg on Amazon most times.<h3>Calibrations done:</h3><ul><li>Temp tower</li><li>Flow rate</li><li>Pressure advance</li><li>Volumetric flow for optimal printing speeds.</li></ul>&nbsp;With this profile & filament prints are beautiful and consistent.&nbsp;This is made with X1C, and should work the same on P1 series.&nbsp;Download RAW file - can't upload a profile with custom filament profile :)&nbsp;

Elegoo PLA+ Calibrated profile

Addons/Upgrades

DGA3DP

This is model of soldering iron press for threaded inserts. For this stand I used an old 2 pc 8x370mm rods from my printer( rods have groves so were useless in 3d printer) and 2x LMU08 bearings. Parts were printed in Bambu Lab PET-G Basic Blue filament.Threads M4 in base and end cap was tapped in the material. In slider I used a M4 threaded inserts. Tap is to long to make the thread inside this hole. Used items: 8x370mm steel rods from printer-2pc LMU08 berings -2pc Tension spring 30mm long- 2pc Fasteners used: Screws: M3x25mm Socket Head Screw- 2pc M4x8mm Socket Head Screw- 6pc M4x25mm Socket Head Screw- 2pc Nuts: M3 Nylock Nut- 2pc M4 Nylock Nut- 5pc Washers: M3 washer- 4pc M4 washer- 8pc Inserts: M4x8mm threaded insterts- 2pcMaterial: PLA, PET-G, ABS, etc.Layer High: 0,3 or lower ( 0,2 will be good)Support needed under rib in slider.

Soldering Iron Press for Threaded Inserts

Random

Targetfun DIY

<h2>Summary</h2>Hi everybody, This is a K40 Panel renewal. The objective is to change original panel, replacing it with a PMMA one, obtained through laser cut. Link to SVG vector file: <a target="_blank" href="https://targetfundiy.it/wp-content/uploads/2022/11/Pannello-V5.svg" rel="nofollow noopener">https://targetfundiy.it/wp-content/uploads/2022/11/Pannello-V5.svg </a>, so you can easily modify and cut with your K40.The panel keeps the original digital panel on nano board, with exception of test file that I soldered with a dedicated button. It also provide space to place an Amperometer with standard panel mounting:<a target="_blank" href="https://it.aliexpress.com/item/33039635263.html?spm=a2g0o.order_list.0.0.1ae33696jTmpy1&gatewayAdapt=glo2ita" rel="nofollow noopener">https://it.aliexpress.com/item/33039635263.html?spm=a2g0o.order_list.0.0.1ae33696jTmpy1&gatewayAdapt=glo2ita</a>and a digital thermometer.Buttons for water pump, air extraction, laser power, light, extra light and air assist and dedicated laser test complete the design.I also painted, masking laser power indicator and red light windows, in order to have them transparent and not cutted. With windows masked I used a primer first and a black paint later on the back of the panel, engraving and cutting in the opposite side (you may need to flip design, select items to engrave or cut etc.) I finally got lucid black panel, with transparent windows and labels, ready for mounting.Holes are for 16mm switches buttons for digital panel can be done with TPU caps using 3d printer. I made some, to be used with 9mm separators between panel and nano board.This is intended to be a starting job for your personal version of the panel.Added support to put on top of nano board to hold the 8 relay board as in attached photo.8 relay Board: <a target="_blank" href="https://s.click.aliexpress.com/e/_DBLygFx" rel="nofollow noopener">https://s.click.aliexpress.com/e/_DBLygFx</a>switch: <a target="_blank" href="https://s.click.aliexpress.com/e/_DEPwZBP" rel="nofollow noopener">https://s.click.aliexpress.com/e/_DEPwZBP</a>have fun Sandro Stay tuned on: www.targetfundiy.it
