<h2>Four Noble Persons traditional Chinese lantern（四君子中国传统灯笼）</h2><h3> </h3><h3>Introduction(简介)</h3>The "Four Gentlemen" refer to the following plants: plum blossom, orchid, bamboo, and chrysanthemum. They are regarded as the "Four Gentlemen" with each representing a specific quality: pride, elegance, modesty, and leisure, respectively. Referred to as the "Four Gentlemen ," they symbolize the aspirations of the Chinese people and are commonly depicted in poems, writings, and artworks as an allegory for various virtues.You can see their figures on this lantern, and I hope you also like them. Wishing you a delightful time.&nbsp;【“四君子”分别是指：梅花、兰花、翠竹、菊花。被人称为“四君子”，其品质分别是：傲、幽、澹、逸。“四君子”成为中国人借物喻志的象征，也是咏物诗文和艺人字画中常见的题材。你可以在此灯笼上看到它们的身影，希望你们也喜欢它们，祝你们玩的愉快。】<h3> </h3><h3>Printing Instructions（打印注意事项）</h3>To illuminate the lantern, you need to have the LED Lamp Kit-001. If you have already printed the LED Lamp 001, you can disregard the following content.<ul><li>Purchase LED Lamp Kit-001</li><li>Search for the model of LED Lamp Kit-001 on MakerWorld. You only need to print the LED base.</li></ul><figure class="image image_resized" style="width:26.94%;"><img src="https://makerworld.bblmw.com/makerworld/draft/493250/2024-02-04_398a70a57cdbd.png"></figure>&nbsp;【为了让灯笼亮起来，您需要拥有001号LED灯套件，如果你已经打印了LED Lamp 001那么下面的内容可以忽略。<ul><li>购买001号LED灯</li><li>在makerwolrd里搜索001号LED灯套件模型，只需要打印led底座即可】</li></ul>&nbsp;I really like the built-in textured PEI print bed of the P1S. If the model's outer surface is flat, I often directly print it on the print bed without using a raft, and this allows me to achieve a good surface finish without activating the bed heating. When printing, please:<ul><li>Clean the oil stains on the print bed to prevent poor adhesion of the printed parts.</li><li>When printing the first layer, I often activate the silent mode, significantly increasing the probability of achieving a perfect first layer.</li></ul><figure class="image image_resized" style="width:50.83%;"><img src="https://makerworld.bblmw.com/makerworld/draft/493250/2024-02-04_aea6fd67f8893.png"></figure>【我非常喜欢P1S自带的纹理PEI打印板，如果模型的外表面是平面的话，我经常把外表面就直接打在打印板上，这样就不需要开启熨烫，就能获得比较好的表面，打印时请：<ul><li>清理打印板上的油污，避免打印板粘不住打印件</li><li>打印第一层时，我经常开启静音模式，大大提高获得完美首层的概率】</li></ul><h3> </h3><h3>Assembly Instructions（组装注意事项）</h3>This is everything printed out. You also need to prepare a roll of double-sided tape.<figure class="image image_resized" style="width:75.71%;"><img src="https://makerworld.bblmw.com/makerworld/draft/493250/2024-02-04_882b71f8a1db4.png"></figure>【这是打印出来的所有东西，您还需要准备一卷双面胶】&nbsp;Step 1: Affix the 3D image onto the red border, paying attention to the orientation.<figure class="image image_resized" style="width:76.43%;"><img src="https://makerworld.bblmw.com/makerworld/draft/493250/2024-02-04_76ba013d00ea4.png"></figure><figure class="image image_resized" style="width:75.97%;"><img src="https://makerworld.bblmw.com/makerworld/draft/493250/2024-02-04_0b6299a48ffde.png"></figure><figure class="image image_resized" style="width:75.47%;"><img src="https://makerworld.bblmw.com/makerworld/draft/493250/2024-02-04_950d6f10ba1b3.png"></figure>【第一步：将立体图片贴在红色边框上，请注意方向】&nbsp; Step 2: Install the LED light.It might be a bit tight; you may need to apply some force.<figure class="image image_resized" style="width:76.62%;"><img src="https://makerworld.bblmw.com/makerworld/draft/493250/2024-02-04_bdd9ada34c332.png"></figure><figure class="image image_resized" style="width:75.78%;"><img src="https://makerworld.bblmw.com/makerworld/draft/493250/2024-02-04_6cbc5dae620c4.png"></figure><figure class="image image_resized" style="width:75.33%;"><img src="https://makerworld.bblmw.com/makerworld/draft/493250/2024-02-04_f78c90efd42e2.png"></figure>【第二步：安装led灯，可能有些紧，需要用力】 Step 3: Insert the red border into the base; you may need to apply some force..<figure class="image image_resized" style="width:74.32%;"><img src="https://makerworld.bblmw.com/makerworld/draft/493250/2024-02-04_1383af3e608e8.png"></figure><figure class="image image_resized" style="width:77.95%;"><img src="https://makerworld.bblmw.com/makerworld/draft/493250/2024-02-04_e8f70a777e87d.png"></figure>【第三步：将红色边框插在底座上,可能有些紧，需要用力】&nbsp; Step 4: Install the lantern top. It might be a bit tight, so you may need to apply some force.&nbsp;<figure class="image image_resized" style="width:76.27%;"><img src="https://makerworld.bblmw.com/makerworld/draft/493250/2024-02-04_e8ad12679e802.png"></figure>【第四步：安装灯笼顶,可能有些紧，需要用力】&nbsp; Mission accomplished!<figure class="image image_resized" style="width:76.63%;"><img src="https://makerworld.bblmw.com/makerworld/draft/493250/2024-02-04_54865a1899ce4.png"></figure>&nbsp;【大功告成】&nbsp;&nbsp;&nbsp;

Four Noble Persons traditional Chinese lantern（四君子中国传统灯笼）

cool

Sevro

Update:28.03.2024 - I redesigned the lamp a bit. I made it a little thicker, so now it is compatible with 12 mm LED strip and is also stronger.&nbsp;I used to this version LED STRIP from Bambu Lab Store<a target="_blank" href="https://store.bambulab.com/collections/led-strip-light/products/white-cct-tunable-cob-led-strip-light?skr=yes" rel="nofollow noopener">https://store.bambulab.com/collections/led-strip-light/products/white-cct-tunable-cob-led-strip-light?skr=yes</a>&nbsp;&nbsp;The diffuser has a larger flange and fits better into the main ring.I enlarged each piece by 110% so it now better takes advantage of bed size of the Bambu Lab printers <figure class="image image_resized" style="width: 68.55%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/2024-03-28_e7c1da1fbecee.jpg"></figure>I created new print profile with this new design and will be develop this project with this size of lamp.If you want use front panels of other designers make sure that is proper size. If it too small just easy enlarge it to 110 % in X and Y axis <figure class="image image_resized" style="width: 44.26%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/2024-03-28_867e2b9fbfc93.png"></figure>&nbsp;02.02.2024 - New front panel added : Deer in the forest05.02.2024 - New front : Birds in love&nbsp;&nbsp;Overview.A Ring Lamp that can be changed to different situations. I designed base with various panels which can adapt to various style and occasion. You can simply change color of it as well as pattern on it, by changing color of diffuser and changing different panels.WARNINGSLed strips can emits some heat depends on what type of led you and voltage you use. In my case temperature of Main Ring achieve 60 °C . Due to this I recommend use filament that can resist that temperature especially for Main Ring. I tested ASA and it works well. Other high temperature filaments should work too (ABS, PETG but I didn&#39;t test it) PLA in this case can bend over time especially if you use heavy panel like budha.So in summary I tested and recommend :Main Ring - ASABase, Diffuser - PLAPanels- PLA or ASAIf you want change panel, always wait to cool down the ring lamp, otherwise PLA cover can bend during take off.Electric parts you need.<ul><li> led stripe - I used: LED COB 8W/1M 12 V, 8mm wide - choose one that can be cut every 2.5 cm</li></ul><figure class="image image_resized" style="width: 430.185px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/6db55f53-37bb-4cbb-ba60-486465aa3c52.webp"></figure><ul><li>dc connector - I used 2.1/5,5 mm , the diameter of the mounting hole is 11.5 mm</li></ul><figure class="image image_resized" style="width: 424.403px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/8867176f-a9e4-4554-8087-7b1fd3a6b430.webp"></figure><ul><li>OFF-ON SWITCH</li></ul><figure class="image image_resized" style="width: 424.332px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/5cf1687e-913a-4186-92f2-75d8d2bac909.png"></figure><figure class="image image_resized" style="width: 425.98px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/4ed0768e-9f72-45b5-9dc0-72aa2a703338.png"></figure><ul><li>Charger 12V</li></ul><figure class="image image_resized image-style-align-center" style="width: 434.759px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/1b0daae1-d790-41b4-a6da-4028c899a774.webp"></figure>Printed PartsMain Ring, Base and Panels can be printed in draft mode 0.28-0.30 mm layer height with no issue.Diffuser should be printed with 0.2 mm layer height.<ol><li>After print, glue led strip to inner side of Main Ring</li></ol><figure class="image image_resized" style="width: 539.361px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/55f0a8a9-5b68-4a7a-b60e-def1c0cf337a.webp"></figure>Start from hole on bottom side<figure class="image image_resized image-style-align-center" style="width: 537.429px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/8f453fdd-01d6-476e-baaa-f03826eac490.webp"></figure>2. Put Main Ring into base. It should fit tight without glue.<figure class="image image_resized image-style-align-center" style="width: 538.864px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/f03a229b-e68e-4835-9d5f-37f66a2677d0.webp"></figure>3. Insert the electric part into the base and connect them by soldering<figure class="image image_resized" style="width: 535.014px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/2e73757c-be70-46f0-8fbb-ebc700b2e62a.webp"></figure><figure class="image image_resized" style="width: 531.08px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/75ca1515-ddbf-47b2-ab0d-34d6c3b795b9.webp"></figure>4. Insert Diffuser to Main Ring”. The Main Ring has a groove into which the Diffuser should be inserted and sit steadily. The flat side to the back.<figure class="image image_resized" style="width: 529.148px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/dd5e9b3f-84e4-47dc-8964-6b93b4f6ee46.webp"></figure><figure class="image image_resized" style="width: 527.23px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/3fc14977-a473-4279-b0d1-25f667c08fba.webp"></figure>5. Insert Panel into Main ring. The Panel has cuts at the bottom to avoid cutting the cables<figure class="image image_resized" style="width: 531.08px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/f414f9b5-fc71-4e83-af57-faf01b92199e.webp"></figure><figure class="image image_resized" style="width: 529.148px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/d3004065-f61c-4175-b595-6235c7b8ead8.webp"></figure>&nbsp;If you any question or suggestion write to me&nbsp;Have fun
