Duke_AdY

chrisb

This will restrict your cabinet door from opening past a 90 degree angle. Intended for the Ikea Utrusta 110° hinge used on Sektion cabinets. Aka the “Blum CLIP top BLUMOTION” hinge.&nbsp;To install: remove the cabinet door, move the hinge to the “closed” position, and insert the restrictor into the gap by the door edge (see the photo above).&nbsp;Prints pretty easily with all the default settings. PLA works, but PETG or others may resist wear better. Only one is needed per door, but doing both hinges may be more durable. The initial angle is set to less than 90 degrees because it will wear down a lot at first, especially if you open the cabinet hard.&nbsp;Comment and let me know if you&#39;d like a version with a different angle.

90° Angle Restrictor for Ikea Utrusta Hinge

Kitchen

Meister Edel

Heyho :) Yesterday I set myself the task of designing a relatively complex and completely 3D printable contour gauge. Here is the result :) Small disclaimer: I know this tool has many individual and small parts! So make sure your printer is calibrated well so you won&#39;t be disappointed later! Tolerances are set to 0,15 to 0,2 mm.&nbsp;<figure class="media"></figure> Features:1. 100% 3D printable parts!<figure class="image image_resized image-style-align-center" style="width: 57.76%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_w8htl8d0w0b1.jpg"></figure>2. Different pencils usable! (Metal dorn adapter will come soon!)  <figure class="image image_resized image-style-align-center" style="width: 57.81%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_oytbes7eb6tx.jpg"></figure>3. All parts are replaceable! So there can be added new designs later on or if they wear down you can renew them!  <figure class="image image_resized image-style-align-center" style="width: 64.61%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_2moiuv37ryaz.jpg"></figure>4. Integrated wheel as a depth stop to protect your pens or set a maximum scraping depths with metal dorns!  <figure class="image image_resized image-style-align-center" style="width: 67.5%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_a2lv0rrw7kdw.jpg"></figure><figure class="image image_resized image-style-align-center" style="width: 67.53%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_vsmotx5pzdfr.png"></figure>5. Pencil position is completely locable!A) Temporarily lock the position into place by squeezing the sides.<figure class="image image_resized image-style-align-center" style="width: 63.82%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_am7l6wwa5h6q.jpg"></figure>B) Lock the position in place by inserting the “locking pin”. This will push a break out of the side and hold the position in place!<figure class="image image_resized image-style-align-center" style="width: 67.04%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_mmvcr1df2vv7.jpg"></figure><figure class="image image_resized image-style-align-center" style="width: 85.15%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_6fwni8ro84lu.png"></figure> 6. Different lengths! It is quite easy to generate new (longer) Versions of this Tool! I already designed a M and L Version. (+ 40 mm and +80 mm length) If you are looking for even longer tools simply write a comment! - I did not test this with the standard handleparts. But if you need these also slonger simply scale them in z direction (only)!  <figure class="image image_resized image-style-align-center" style="width: 74.53%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_t6oxknmgtjpl.png"></figure>7. Scraping Nail/ Pin: You can use a nail/ needle to scrape the marking. I designed a special adapter Set to hold the nail in place.   <figure class="image image_resized image-style-align-center" style="width: 70.32%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_suywh5dnkh7a.png"></figure><figure class="image image_resized image-style-align-center" style="width: 66.3%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_b12w0601mh7u.jpg"></figure>Bearing: You can simply use a 608 miniature bearing or use a 3D printed alternative!  <a target="_blank" href="https://www.printables.com/model/898602-simple-608-bearing-alternative-for-light-tasks" rel="nofollow noopener">https://www.printables.com/model/898602-simple-608-bearing-alternative-for-light-tasks</a>  <figure class="image image_resized" style="width: 61.24%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_sk3ylssyxef1.jpg"></figure> Printing Instructions: I used PLA for all parts. 3 Perimeter, 25% Infill, Arachne perimeter generator. No supports but a brim for the handle pieces is recommended. Post Processing: If some parts are not working as smoothly as they should you can help a little bit by applying some parafin (candle wax) to lube it.  Assembly Instructions: 1. Complete the Pencil Holder Cage. - Insert the break from the side. - Insert the axis bearing into the wheel and put that into the cage. - Insert the Axis Lock from the side until it clicks into place. Make sure you didn&#39;t forget the bearing (red)! It is hard to change that later on :)  <figure class="image image_resized image-style-align-center" style="width: 67.52%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_6t7cjy1bvur3.jpg"></figure><figure class="image image_resized image-style-align-center" style="width: 67.45%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_lto4i3x1s4x0.jpg"></figure>2. Add the cage, 608 Bearing + Axis and the “wall contact pointer” to the main parts.<figure class="image image_resized" style="width: 67.68%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_svqlduruawx6.jpg"></figure>3. Add the side handpieces to the constructions and clip them into place. (You can remove them later on if you want to change sth.)<figure class="image image_resized image-style-align-center" style="width: 67.04%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_twcglmkr8wq9.jpg"></figure> The “break” pin is optional but you can put that into place now.<figure class="image image_resized image-style-align-center" style="width: 66.68%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_bbqzkx0e18mh.jpg"></figure>4. Add a pencil of your choice to the tool and use the wedge to hold it in place!<figure class="image image_resized image-style-align-center" style="width: 70.83%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_xm5hus2dzugi.png"></figure><figure class="image image_resized image-style-align-center" style="width: 69.77%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_ol0zfe4wm3yk.jpg"></figure>You are done and ready to use the tool!  <figure class="image image_resized image-style-align-center" style="width: 73.7%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000492891/design/2024-06-12_x957m5brxryk.jpg"></figure> Have fun!  Small Update 03.06: Fixed some small things like the &#34;marking pin&#34; being in the center and increasing its tolerance to 0,15 from 0,1 mm. Added an Addon set for Needles/ Nails/ Pins.  I also added Pins with different tolerance sizes (standard is 0,1 mm).

Contour Gauge / Duplicator 100% printable!

tools

Cholas

Remixed TS101 from gridfinity to attachment for multiboard. Holds ts101 and 3 tips (4 if one is attached to the TS). &nbsp;I thought TS101 and TS100 shared dimensions, but my TS101 didn't fit in the original model so needed to resize it.&nbsp;<a target="_blank" href="https://cad.onshape.com/documents/acb9b8556e80ead0511c4fd9/w/7bb8b2299e17486d9d36c526/e/ad3e64144b9e514add8879d9?renderMode=0&uiState=65c7f498ea42f710df983f12" rel="nofollow noopener">onshape link </a>

TS101 + 3 tips for multiboard

Multiboard

maskedjoey

Glue and supports are not needed. It will hold up to 18 paintbrushes. It can be rearranged in different ways.&nbsp;-All parts are press-fitted, but depending on your printer, it will need some cleanup on the edges to fit. -It will fit 18 paint brushes and 2-4 (depending on arrangements) smaller holes for items like tweezers.-They will fit side by side nicely if you print more than one.-See photos for different arrangements. Feel free to make new arrangements. &nbsp;Dimensions:-Hex hole size: 1cm-Supports height: 10cm-Hex hole holder: 6.5cm x 4.2cm x 0.5cm&nbsp;Printing setting recommendation:-0.2mm layer height-10% to 0% infill density&nbsp;Notes for Print files:Brush holder all parts: this has all the parts needed in one fileBrush holder bottom plate: this file is only needed if you want to change the height of the bottom part walls without adding unnecessary height.

Floating Paint brush holder/stand

hobby

EPIQ3D

Have you ever needed a coin for a shopping cart, only to find out that you dont have one? Or maybe just the wrong coin size? Then this fine and dandy shopping cart key is just you. Its universal and can adapt for any coin size (that i can test).Its made to be up to 27mm (1.062 inch), and is tested down to 23mm (0.905 inch) Oh, and its removeable in any size slot. ------------------------------------------------------------------------------------------------- Mine is printet in PLA with 4 walls, and holds up just fine.But if you want to be sure, then go for PETG. ----------------------------------------------------------------- DISCLAIMER - I am i no way responsable, nor can be held acountablefor any broken models inside shoppings carts, due to bad print quality.Or other reasons in that matter.

Shopping Cart Key - Universal and removeable

Everyday

rpinerd

I wanted a more organized brush (or generic tube shaped object) holder for my multiboard, something a bit more sophisticated than a catch-all cup. Thus, this adaptive holder was born! I call it adaptive simply because you can space the two plates out however much you need to vertically.

Multiboard Adaptive Brush Holder

Organisation

ExpiredTapWater

30mm wide slim purge chute and basket system for placing your printer right up against the wall&nbsp;DescriptionThis is a somewhat niche design for those with printers up against the wall and have the printer placed on steel shelving.It provides:<ul><li>Magnetic mounting via a separate mount that can accept thick magnets (~20mm) or multiple thinner ones (8x ~3mm)</li><li>Self-aligning basket mounting to aluminum extrusions.</li><li>Steeper 35 Degree angle for more reliable purging.</li></ul>The goal of all of this is to mount the damn thing securely at the back and not have to touch it regardless blockages and to empty the bin. Using adhesives to mount such a long chute (~285mm) means its a huge pain when it comes to moving the printer out for maintenance. The overkill amount of magnets ensures you can reach around back and scrape off any stuck purges without it shifting alignment, and remove it entirely during maintenance.&nbsp;* If you do not require a slim chute almost every other poop chute design will be more reliable!&nbsp;DimensionsChute has a base of 280mm, when factoring the printing angle, it is effectively 300mm long.The guard rails have a height of 40mm. If aligned perfectly with the poop chute of the machine, it will extend ~50mm past the left edge and sit ~10mm below the level of the printer. Use the included STEP files to modify for your specific needs.&nbsp;AssemblyMagnetic SupportThe provided STL has 3.2mm deep holes of diameter 8.25mm with a 0.4mm gap so there is no chance of the magnets scratching the rear of the printer. Add a pause at 3.6mm to insert them. Otherwise edit the included STEP file to whatever specs you need. Apply adhesive to the top of the mount, and then mount the chute. The Aux support can be used if you have the space for an even more secure mount.&nbsp;Basket & Basket MountBoth basket and mount has four 2.2mm deep holes of diameter 8.25mm with a 0.4mm gap each. Add a pause at 2.6mm to insert them. Don't forget to ensure opposite polarity for them to attract together once printed. Otherwise edit the included STEP file to whatever specs you need.&nbsp;Other Notes<ul><li>The basket has 2mm thick walls (so print using 5 walls with a 0.4mm nozzle). My previous designs with 1mm thick walls cracked after repeated use as the magnetic alignment tends to bash it against the steel sides of my shelving.</li></ul>
