Darzuale

MFDesigns3D

Poker themed LED Lightbox.If you only have 1 AMS, I added instructions on how to use more than 4 colours.Be sure to check out my other models!

Poker King LED Lightbox

poker

Wildside_Concepts

Dive into the iconic moment on a journey taken many years ago. This will take you back to the start of your Kanto journey picking your new pokemon.&nbsp;This hueforge is compatible with all bambu printers and can be scaled up as large as desired. Just keep z height the same for the layer changes to be right. (3.07mm)&nbsp;Initial layer height 0.2mmLayer height 0.16mm&nbsp;Begin print with blackSwap to grey at 1mm -Layer 6Swap to White at 1.80mm - Layer 11Swap to Red at 2.60mm - Layer 16 and finish.&nbsp;*** Added a bonus picture frame that can be printed and glued separate :)

Pokemon Red/Blue Nostalgia HueForge

Pokémon

aman

Print at 100% infill with a layer height of 0.08mm with a base layer of 0.16mmFilaments Used: PLA BambuLab Basic Black Transmission Distance: 0.6 PLA BambuLab Basic Red Transmission Distance: 4 PLA BambuLab Basic Yellow Transmission Distance: 6 PLA BambuLab Basic Jade White Transmission Distance: 5Swap Instructions: Start with Black At layer #10 (0.88mm) swap to Red At layer #16 (1.36mm) swap to Yellow At layer #19 (1.6mm) swap to Jade White for the rest.

naruto (hueforge)

anime

How To Homemade

Things you wanted to know before:Be aware of the effort involved in this project, you can&#39;t just put everything together in 10 minutes. You should also be good at soldering and know how to handle cables. It took me about 3 hours to solder all the strips together correctly. I would also set up the software first and connect the ESP to the first LED segment. After soldering on a new segment, you can now always check whether all connections are working.<h4> </h4><h4>Required Parts:</h4><h5> 3D Printed:</h5><ul><li>1x Base</li><li>1x Grid</li><li>1x Cover</li><li>127x Prism Cap (you can vary between small, medium, large and extra large)</li></ul>Used Filament:<ul><li>Black: <a href="https://www.redline-filament.com/products/pla-black" rel="nofollow">Redline Filament</a></li><li>White: <a href="https://amzn.eu/d/iBXuM7A" rel="nofollow">Sunlu</a></li></ul><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000448943/design/2024-04-30_s3pr5rnasn2u.png"></figure>&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000448943/design/2024-04-30_rb1m7zhzeejh.png"></figure>&nbsp;Extra Components:<ul><li>127 Leds (2,12m 60leds/m WS2812b [<a href="https://www.amazon.de/dp/B01CDTEJBG" rel="nofollow">DE</a>, <a href="https://www.amazon.com/dp/B09PBHDXSM" rel="nofollow">US</a>], SK6812 [<a href="https://www.amazon.de/dp/B079ZW2CTG" rel="nofollow">DE</a>], etc.)</li><li>LED Controller (ESP32 [<a href="https://www.amazon.de/dp/B08BTS62L7" rel="nofollow">DE</a>, <a href="https://www.amazon.com/dp/B08246MCL5" rel="nofollow">US</a>], ESP8266, etc.)</li><li>5V power supply (or phone charger)</li><li>Old USB Cable [<a href="https://www.amazon.de/dp/B07NSMK97T" rel="nofollow">DE</a>]</li><li>14x M2x4mm screw [<a href="https://www.amazon.de/dp/B0CFXVKZDD" rel="nofollow">DE</a>]</li><li>14x M2x2.5x3.2 heat nut insert [<a href="https://www.amazon.de/dp/B09B7F2XM3" rel="nofollow">DE</a>]</li></ul>&nbsp;<h4>Assembly: </h4>Step1:Cut the LED strip to pieces of the correct length.<figure class="table"><table><tbody><tr><td>Amount</td><td>Length (Leds)</td></tr><tr><td>2</td><td>7</td></tr><tr><td>2</td><td>8</td></tr><tr><td>2</td><td>9</td></tr><tr><td>2</td><td>10</td></tr><tr><td>2</td><td>11</td></tr><tr><td>2</td><td>12</td></tr><tr><td>1</td><td>13</td></tr></tbody></table></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000448943/design/2024-04-30_ie6z3ztbgjcy.png"></figure>&nbsp;Step 2:Press the 14 heat nut inserts into the holes in the base with your soldering iron.&nbsp;Step 3:Insert the USB cable through the hole provided and solder it to the beginning of the first LED strip. Then all LED strips must be soldered together one after the other. I used cables with lengths of 21, 26 and 31mm. Make sure to always connect GND to GND, data to data and 5V to 5V.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000448943/design/2024-04-30_o38lxg6ggn9p.png"></figure>&nbsp;Make sure the arrows on the LED strip are aligned correctly:<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000448943/design/2024-04-30_wfeuvk05ppre.png"></figure>&nbsp;Step 4:Press the cables into the corners:<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000448943/design/2024-04-30_fcon3pmly82x.png"></figure>&nbsp;Step 5:Press the Cover between the Base and the Grid and then screw the grid onto the base with the 14 M2x4mm screws (the image don&#39;t show the cover):<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000448943/design/2024-04-30_71v9wmkqqnf1.png"></figure>&nbsp;Step 6:Press the 127 caps onto the grid:<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000448943/design/2024-04-30_kxg3m0s8pp32.png"></figure>&nbsp;Step 7:Solder or plug your cable onto the ESP, connect the cable as shown below:<figure class="table"><table><tbody><tr><td>LED-Strip</td><td>ESP</td></tr><tr><td>GND</td><td>GND</td></tr><tr><td>Din</td><td>G16</td></tr><tr><td>+5V</td><td>5V</td></tr></tbody></table></figure>&nbsp;<h4>Software:</h4>&nbsp;Step 1:Connect your ESP to the computer and install <a href="https://install.wled.me/" rel="nofollow">WLED </a>on it. Go to the WLED webpage.(If you have any problems, check out the first part of this <a href="https://www.youtube.com/watch?v=TOEnFKLm9Sw" rel="nofollow">tutorial</a>)&nbsp;Step 2:<ol><li>Download the zip folder PrismLume_WLED_Config.zip from “Other Files” or <a href="https://howtohomemade.de/downloads/PrismLume_WLED_Config.zip" rel="nofollow">here</a> and unzip it.</li><li>Go to Config → Security &amp; Updates and upload the PrismLume_config.json file to “Restore configuration” and press upload.</li><li>Then Upload the PrismLume_presets.json to “Restore presets” if you want to use my presets and press upload.</li><li>Then scroll to the bottom of the page and press “Save”.</li><li>Go to Config → 2D Configuration and upload the PrismLume_gap.json file to “Gap file:” and press upload.</li><li>Then scroll to the bottom of the page and press “Save”.</li><li>Search for WiFi networks on your phone and connect to the “WLED-AP” network (password: wled1234).</li><li>Type 4.3.2.1 in your brower.</li><li>Go to Config → WiFi Setup and enter your WiFi credentials.</li></ol>Now you can make the lamp light up in different patterns on the Presets page, or create your own patterns.&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000448943/design/2024-04-30_qrsuh58egmdz.png"></figure>&nbsp;Have fun building the project! Stay ceative!
