<p>This is a 3D printable version of the <a href="https://www.irwintools.com/product/59200cd/handi-clamps" rel="nofollow">Irwin Handi-Clamp</a>. Squeeze the handles to close it on your workpiece and the self-locking lever mechanism keeps it closed. Just press on the lever to release.  Great for clamping jobs needing light pressure and one-handed operation. Opens 0 - 39mm (0 - 1.5 in).</p><p>Everything presses or snaps together without glue or fasteners. If you want the clamp to automatically spring open, you will need one small rubber band, like the kind that comes on green onions.</p><p><strong>Printing</strong><br>You want to print this as rigid as possible. I used PLA with 5 perimeter lines and 30% infill. CF filled PLA would be even better. I used 0.2mm layer thickness.</p><p>The bar and lever sides of the clamp do need some supports in specific areas, as indicated last photo. I recommend manually painting on supports as indicated rather than turning on automatic supports everywhere.</p><p><strong>Assembly</strong><br>The leaf  spring has some built-in mouse-ear brims that need to be broken away first. Then insert the short leg of the spring into the slot in the lever-side handle. It should press into place. </p><p>Then, slide the lever over the curved bar on the bar-side of the handle and place the two handle pieces together. The D-shaped pin should be a press fit into place but you may need to tap it into place lightly with a small hammer. (If your pin happens to be a little loose, you might try reprinting it scaled up by 0.5% or so.)</p><p>To make it spring open automatically, you'll need to loop a thin rubber band through the eyelet in the bar-side of the handle and then hook the other end over the little nub on the other side as shown in the fifth photo.</p><p><strong>Operation</strong><br>Squeezing the clamp closed will cause the lever to slide along the curved bar and it self-locks into place when you stop squeezing. Pressing on the end of the lever will cause it to unlock. Note that the little leaf spring may not contact the end of the lever once the clamp is locked. The spring's job is to initially apply a light pressure to the lever to get it to start locking on the bar. When you stop squeezing the clamp, it will flex back and the spring will no longer touch the lever, but the self-locking will still stay engaged.</p><p>And <a href="https://youtu.be/pHbJEg4Dp80." rel="nofollow">here </a>3Dprintsmith has posted a video of his build of the clamp.</p>

Handi-Clamp

Useful

Davron

<div><h1>Summary</h1><div><p>This replaces the acrylic PSU bracket on my cheap open air 2020 test bench case. The acrylic broke while I was carrying it. I designed this to be super rigid so that it won't break. This is way overdesigned. I iterated using the ATX specification, but it turns out that the stickers on Corsair power supplies are about 0.35 mm on either side. This will at least fit a CX650M and smoothly slide in. The holes are sized for M4 screws. With my T-nuts I needed 10mm. You'll need longer 6-32 screws than come with most PSUs.</p><p>If you print it back face down it shouldn't require any supports.</p><p>I'm new to SolveSolid, but I tried to make it easily modifiable. I'm including native file for it, STL and STEP.</p><p>Warning: In Orcaslicer, the STEP file generates a lot of non-manifold regions. Make sure to click "repair" if you import using that.</p></div><h1>Print Settings</h1><p class="detail-setting printer"><strong>Printer: </strong>                         </p><div><p>Bambulab X1C</p></div>                                    <pre><code>                                            <p class="detail-setting rafts"><strong>Rafts: </strong>                     <div><p>No</p></div></code></pre><p></p>                                    <p class="detail-setting supports"><strong>Supports: </strong>                         </p><div><p>No</p></div>                                    <pre><code>                                            <p class="detail-setting resolution"><strong>Resolution: </strong>                     <div><p>0.20 mm (Strength 6 wall loops)</p></div></code></pre><p></p>                                    <p class="detail-setting infill"><strong>Infill: </strong>                         </p><div><p>25%</p></div>                                    <pre><code>                <strong>Filament:</strong>                 <a href="http://www.amazon.com/s?url=search-alias&field-keywords=Inland+PLA%2B" target="_blank" rel="nofollow noopener">                    Inland PLA+                    </a>                Black</code></pre></div>

2020 Open Air Test Bench ATX PSU Bracket

Printed

ANIMAL MODS

<p>I wasn&#39;t happy with slinging the tool head cover over the top rod - leaving it in a precarious position / stressing out the cable during maintenance.</p><p>Here is a simple hanger which loosely rests over the top rod and fits into one of the cover&#39;s triangle openings with a slot to keep it in place.</p><p>Safely stows the tool head cover and frees up your hands so you can get business done.</p><p>No supports needed for print.</p><p>&nbsp;</p><p>The updated design with a deeper slot per user request was uploaded but for some reason makerspace is not updating the link.</p><p>Download the .stl if you are having issues accessing the latest version.</p><p>&nbsp;</p><p>&nbsp;</p><p>&nbsp;</p>
