Clay_2077

xallex digital design

Fallout Fusion Core / Stash Container Desk / Ornament Replica / Cosplay Accessory Multi-part locking stash container / Desk Ornament Replica of the Fusion Core from the popular game Fallout  <figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000430340/design/2024-04-17_82adf2aefef13.png"></figure> Screws: x4 M2 x 4mm Stainless Steel Hex Socket Head Cap Screws (Attach bottom) – (<a target="_blank" href="https://amzn.to/3Wgm5Ou" rel="nofollow noopener">https://amzn.to/3Wgm5Ou</a> or <a target="_blank" href="https://amzn.to/49TxXta" rel="nofollow noopener">https://amzn.to/49TxXta</a>) x1 Black M3 x 6mm (Attach knob) – (<a target="_blank" href="https://amzn.to/4aP4hPd" rel="nofollow noopener">https://amzn.to/4aP4hPd</a>) Material: Yellow - Hatchbox PLA <a target="_blank" href="https://amzn.to/3U9sl8c" rel="nofollow noopener">(https://amzn.to/3U9sl8c</a>) Red - Hatchbox PLA (<a target="_blank" href="https://amzn.to/4b52FRa" rel="nofollow noopener">https://amzn.to/4b52FRa</a>) Black - IIIDMAX PLA+ (<a target="_blank" href="https://amzn.to/3wcbjhK" rel="nofollow noopener">https://amzn.to/3wcbjhK</a>)  Glow - Duramic 3D PLA (<a target="_blank" href="https://amzn.to/3xUMPdl" rel="nofollow noopener">https://amzn.to/3xUMPdl</a>)

Fallout Fusion Core Stash Container Desk Replica

NoycePrints

Meet Dum-E, the handy desk helper industrial robot. I designed it with purpose in mind as it can function as a phone stand, webcam mount (logitech c920) and a business card holder. It doesn&#39;t end there though, as I aim to develop this platform with further attachments in future. These may be recommended from others and/ or what I think might be useful. I hope you find it useful and please feel free to comment any recommendations for attachments you would like to see in future. I look forward to seeing your different uses/ prints and colour schemes. Thank you for your continued support :)&nbsp;To keep files from getting complicated, I have only included the phone stand attachment in this upload. I have placed optional attachments in a sperate upload available on my profile titled “Dum-E optional attachments”. This will be periodically updated with new wrist attachments I think may be of use or other people suggest. Printing helper<figure class="table"><table><tbody><tr><td>Part</td><td>Quantity</td><td>Infill</td><td>Supports required</td></tr><tr><td>Arm 1</td><td>1</td><td>25%</td><td>YES</td></tr><tr><td>Arm 2</td><td>1</td><td>25%</td><td>NO</td></tr><tr><td>Shoulder Joint</td><td>1</td><td>30%</td><td>YES</td></tr><tr><td>Wrist to attachment connector</td><td>1</td><td>40%+</td><td>YES</td></tr><tr><td>Turntable</td><td>1</td><td>20%</td><td>NO</td></tr></tbody></table></figure><figure class="table"><table><tbody><tr><td>Part</td><td>Quantity</td><td>Infill</td><td>Supports required</td></tr><tr><td>Base</td><td>1</td><td>20%</td><td>NO</td></tr><tr><td>Feet</td><td>1</td><td>20%</td><td>NO</td></tr><tr><td>XL motor</td><td>1</td><td>15%</td><td>NO</td></tr><tr><td>Large motor</td><td>1</td><td>15%</td><td>NO</td></tr><tr><td>Medium motor</td><td>1</td><td>15%</td><td>NO</td></tr><tr><td>Small motor</td><td>1</td><td>15%</td><td>NO</td></tr></tbody></table></figure><figure class="table"><table><tbody><tr><td>Part</td><td>QTY</td><td>Infill</td><td>Supports required</td></tr><tr><td>Phone stand backing</td><td>1</td><td>25%</td><td>NO</td></tr><tr><td>Phone stand bottom</td><td>1</td><td>25%</td><td>NO</td></tr></tbody></table></figure>Required for assembly Superglue for fake motor attachment and Nitrile cord.1mm nitrile rubber cord, 16cm should be enough for 1 complete arm. This is only required between joints if you intend on supporting the weight of a phone etc. Alternatively, if you have TPU filament you can use Fat Tony&#39;s handy TPU O-rings. They&#39;re a quick print and don&#39;t require superglue to fit. You can get them here: <a target="_blank" href="https://makerworld.com/en/models/205832#profileId-225948" rel="nofollow noopener">https://makerworld.com/en/models/205832#profileId-225948</a> Thanks again for the great alternative Tony!&nbsp;As an optional extra, I&#39;d recommend using 4x 3M 6mm Anti-slip sticky back rubber feet. They fit in recessed circles in the corners of the feet.&nbsp; Screws: A total of 13 are required for the arm plus 3 for the phone stand, listed below.M3x10mm - QTY 12 - available on the store, linked below.M3x15mm - QTY 3M5x30mm - QTY 1Foot: 4x M3x10mm countersunk.Base: 1x M3x15mm countersunk.Shoulder joint to Arm 2 rotation point: 1x M5x30mm countersunk.Turntable: 4x M3x10mm countersunk.Rotation point between Arm 1 and Arm 2: 1x M3x15mm countersunk.Arm 1 to wrist connector rotation point: 1x M3x15mm countersunk.Coupling attachment to wrist: 1x M3x10mm countersunk.3 M3x10mm screws are required for the Phone stand. Assembly tipsCut 3 lengths of Nitrile cord, 74, 55 and 30mm in length. Glue one side of each and cure into individual circles. These will be glued on one side between the 3 separate joints on the arm. Doing this will vastly improve the holding capacity of the arm as it will provide more friction between the joints, helping to prevent them from sagging under weight.The 74mm circle goes between the elbow joint and arm 2.The 55mm circle goes between the arm 1 and 2 joint.The 30mm circle goes between the arm 1 and wrist attachment connector.I have added 3 pictures as a guide at the end of the gallery.

Dum-E the handy desk buddy. Lamp, stand, holder

Jerryie

&nbsp;&nbsp;This set includes screws, nuts and washers of all kindsISO 4017 DIN 933&nbsp;With smaller screws and nuts, it is necessary to set the height as low as possible so that the screw works correctly for example at M3, M4 and M5&nbsp;&nbsp;&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/194263/2023-11-22_69ea780efc7e4.png"></figure>&nbsp;<figure class="image image_resized" style="width:25.39%;"><img src="https://makerworld.bblmw.com/makerworld/draft/194263/2023-11-22_379d07fbbf734.png"></figure>&nbsp;&nbsp;The screws are optimized for easy twisting, but if there is a problem with any type, write it in the comments and I will fix it I tested it from PLA and they worked fine&nbsp;NO SUPPORT!&nbsp;&nbsp; There is a bonus in files for people who often lose their extension :)
