BryonKonPoint

ochiburi

Version 3 of a printable HueForge Frame for 200x200mm prints. This version uses press in right-angled inserts to hold the frame securely. NO GLUE needed - the inserts are a snug fit! No supports or brim needed.&nbsp;I have Included the F360 file which includes info on which parameters to change for different sized frames. Follow the instructions and the frame will resize automatically, then export the STL or STEP, and make clones on the plate. Note that trying adjust size by just scaling in Bambu Studio will fail because the mitre angles will change.&nbsp;You can now adjust most of the parameters to change height and width of the frame, thickness of the HF Image etc. Guidance is given in the F360 file for ranges of values I have tested. See the comments inside the Modify, Change Parameters dialog box.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/267481/2023-12-13_ea1c6c5a638d1.png"></figure>&nbsp;If the insert is too tight or loose, there is now a parameter in the F360 file for PrinterTolerance as one user commented that it was too tight - mine have always been fine, but printers and PLA do vary, so you can adjust if needed. Apologies to those who uploaded earlier versions, V10 is the latest and greatest and most flexible.&nbsp;I did this special frame for a Die Hard print to make it look more like he was in the air duct, with a frame height of 40mm.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/267481/2023-12-14_597666474a74.jpg"></figure>&nbsp;&nbsp;

HueForge Bevelled Edge Frame 200x200 with inserts (Any size possible, parameterised in F360)

Huefouge

OldSpice3d

Everything is properly setup in the 3mf

Panda led light lamp

Grandkids

JamesThePrinter

A snowflake in a flat pack style. Print twice and slide together. Held together with a friction fit. It can stand on it's own or it can be hung by a string.&nbsp;Check out the rest of my Christmas models <a target="_blank" href="https://makerworld.com/en/u/1360890085/collections/69417" rel="nofollow noopener">here</a>!&nbsp;<a target="_blank" href="https://www.buymeacoffee.com/JamesThePrinter" rel="nofollow noopener">Buy Me A Coffee</a>

Snowflake - Flat Pack Style

Christmas

chiz_m

<h4>REVISION HISTORY</h4><ul><li>2023-07-19: v1 - Initial release</li><li>2023-10-19: v2 - Updated to address the flaws of the original design; now made to be modular.</li></ul>________________&nbsp;If you find that this adapter works great for you, pls hit that BOOST button!&nbsp;This is spool adapter for Bambu Lab AMS that can fit a wide range of 200g/250g mini spools. See illustration for sample 250g spools that can be accommodated.&nbsp;Version 2 addresses the flaws of the original design where the spindle will break easily either by overtightening or by dropping the spool. This release now has the spindle printed separately from the spool, made wider and is now horizontally oriented for added strength.<h4>PROBLEM</h4><ul><li>The Bambu Lab AMS cannot use 250g spools due to its small size</li><li>Adapters for 250g spool currently available are designed for specific brand of spools therefore each spool needs an adapter printed</li></ul><h4>SOLUTION</h4>Design an adapter for 250g spools that can be printed once and can be reused over and over catering to a wide variety of the mini spools.The threaded hub design lets you spin the spool clockwise to tighten, counter clockwise to unlock, which makes the adapter super quick and easy to transfer to another mini spool!<h4>WARNING / IMPORTANT NOTES</h4><ol><li>Printing profile - please make sure you print the spool with 4 or more walls for added strength.</li><li>Supports are NOT needed on any of the parts.</li><li>DO NOT OVERTIGHTEN as you might split the thread layers</li><li>Proper filament types. Ensure that you have properly calibrated your filament and that the layers strongly adhere. Otherwise, you risk delaminating the layers. DO NOT USE SILK AND MATTE FILAMENT as layer adhesion of these type of filaments are usually not strong enough for these types of applications.</li></ol><h4>ASSEMBLY</h4><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012943/design/2023-10-19_286fcc6674729.png"></figure><h4>COMPATIBILITY</h4>This adapter has been tested to work on the following filament brands&#39; mini spools:<figure class="table"><table style="border-style:solid;"><thead><tr><th>Brand</th><th>OD (in mm)</th><th>ID (in mm)</th><th>Width (in mm)</th></tr></thead><tbody><tr><td>3D Genius</td><td>140</td><td>58</td><td>43</td></tr><tr><td>3D Jake ecoPLA</td><td>140</td><td>51</td><td>44</td></tr><tr><td>Amolen</td><td>150</td><td style="border-style:solid;">55</td><td>35</td></tr><tr><td>Bblife</td><td>134</td><td>53</td><td>44</td></tr><tr><td>Bud3D</td><td>150</td><td>53</td><td>35</td></tr><tr><td>Cindeer</td><td>150</td><td>52</td><td>37</td></tr><tr><td>Creality</td><td>141</td><td>55</td><td>38</td></tr><tr><td>Dikale</td><td>140</td><td>58</td><td>43</td></tr><tr><td>MIKA3D</td><td>134</td><td>53</td><td>44</td></tr><tr><td>MKOEM</td><td>134</td><td>53</td><td>44</td></tr><tr><td>Printbed</td><td>120</td><td>52</td><td>37</td></tr><tr><td>Sunlu</td><td>120</td><td>42</td><td>47</td></tr><tr><td>Tecsonar</td><td>150</td><td style="border-style:solid;">55</td><td>35</td></tr><tr><td>Tinmorry</td><td>150</td><td style="border-style:solid;">55</td><td>35</td></tr><tr><td>Tttyt3D</td><td>134</td><td>53</td><td>44</td></tr><tr><td>Yousu</td><td>152</td><td>54</td><td>40</td></tr></tbody></table></figure>&nbsp;Appreciate if you post your make and the brand you used the adapter for so that I can expand the list!

Huefouge

Grandkids

Christmas

Future Prints
