BluSaphyre3D

Mister.D

&nbsp;A minimal Desk Organizer designed for your workspace. I personally like a PLA Marble filament for this model. This Model is for personal use only (non-commercial). DO NOT redistribute the files to anyone else.&nbsp;Those who are interested in product design, prototyping, product presentation and much more could contact me; my bio contains the contact details. Also, those who want to support my work, there is a link to do it:&nbsp;<a target="_blank" href="https://www.buymeacoffee.com/iammister.d" rel="nofollow noopener">https://www.buymeacoffee.com/iammister.d</a>&nbsp;Have a good day, MR.D

Desk Organizer / v1

Useful Prints

GekoPrime

I tried another spool winder but found it finicky and delicate.I designed this winder from scratch to be simple and robust, using the same self reversing leadscrew mechanism found on industrial cable windersWhy pick this model:<ul><li>Prints on a single build plate</li><li>Doesn't require heat set inserts or exotic hardware</li><li>Fusion and STEP files are available, remixes welcomed</li><li>Generous clearances, simple mechanisms</li><li>Designed to be a tool, not a project</li></ul>Print time:<ul><li>~500 grams of filament</li><li>~22 hours on Bambu Lab X1</li><li>~5 minute assembly</li><li>~2 minute spool transfer</li></ul>Hardware requirements:<ul><li><a target="_blank" href="https://www.amazon.com/s?k=608+bearings" rel="nofollow noopener">14x 608 skate bearings</a></li><li>A scrap of PTFE tubing</li><li>An electric screwdriver or drill with <a target="_blank" href="https://www.homedepot.com/p/DEWALT-MAXFIT-3-5-in-2-Philips-Bit-DWA3PH2MF/309474882" rel="nofollow noopener">a bit cut from ¼ inch hex stock</a> (most <a target="_blank" href="https://www.amazon.com/ITP1201-SCRWDRVNG-2IN-1-IMPAC/dp/B01LZZ7AOS/" rel="nofollow noopener">cheap quick change Philips bits</a> in the US fit this requirement)</li></ul>Print settings:<ul><li>Any. I used "0.16mm Optimal" in BambuSlicer with 5% adaptive cubic infill </li><li>Use 100% concentric infill for spindle_male_driven</li><li>Try the STLs if you have a problem with the 3mf files. I’ve added (xN) to each file name so you know how many to print</li></ul>Materials:<ul><li>Any. I used Polyterra and iiidmax PLA+</li><li>Use TPU for tpu_consumable_wiper_blade. I used Priline 98a. The wiper blades aren’t 100% required but they help keep the windings nice and tight</li></ul>Assembly and usage:<ul><li><a target="_blank" href="https://youtu.be/DxgkYDrRK-U" rel="nofollow noopener">Demo video</a></li><li><a target="_blank" href="https://youtu.be/-Hy69YwRLBw" rel="nofollow noopener">Assembly video</a></li><li>The side that says “Pastamatic" needs to face outwards, away from the spool</li><li>The filament needs to come in under the target spool, like this: O____O<ul><li>[not like this: O‾”‾”‾”O]</li></ul></li><li>The drill/driver needs to run clockwise, as though you're screwing something in</li><li>Accelerate slowly until the winder gets started</li></ul>Change log<ul><li>2023-05-28<ul><li>Initial release</li></ul></li><li>2023-05-29<ul><li>Fix a minor export glitch in "leadscrew_tooth"</li><li>Increase the number of “pin_short” instances in the 3mf from 6x to 8x</li></ul></li><li>2023-05-30<ul><li>Add a second prearranged 3mf with two plates to avoid overlap warnings</li><li>Disable autogenerated brims for the single plate 3mf </li><li>Add STLs for people who have trouble with the 3mf</li></ul></li><li>2023-06-03<ul><li>Add a ring to passive_target_cradle to prevent the far end of the target spool lifting if a user lets the the drill hang loose</li><li>Add a pin to driven_target_cradle prevent the leadscrew popping out</li><li>Fix a minor clearance issue where a dovetail didn't fit quite right</li></ul></li><li>2023-09-30<ul><li>Reduce chamfer on the crossbars to prevent them falling over when bed adhesion is poor</li><li>Add some holes to the crossbars to make them easier to screw down</li><li>Add some popular acessories to the all-in-one .3mf</li><li>Add a printable spool to the all-in-one .3mf</li></ul></li></ul>How to contribute:<ul><li>Post your make, it keeps me motivated to improve the model when I see people using it!</li><li>Post your feedback, idea or remix in the comments!</li><li>There are a few improvements and accessories in development as remixes, check those out if you‘re up for the alpha/beta tester experience<ul><li><a target="_blank" href="https://www.printables.com/model/498743-pastamatic-37-mm-motor-mount" rel="nofollow noopener">Adapter for 37mm gear motor</a></li><li><a target="_blank" href="https://www.printables.com/model/556405-pastamatic-filament-spool-winder-modifications-bra" rel="nofollow noopener">Source spool holder for 5 KG spools</a></li></ul></li></ul>Credits:<ul><li><a target="_blank" href="https://www.printables.com/@MiklosKiszely_486882" rel="nofollow noopener">@MiklosKiszely_486882</a> for the original idea</li><li><a target="_blank" href="https://www.printables.com/@PsychoShaft_33891" rel="nofollow noopener">@Psycho Shaft</a> for the drag/tensioner concept</li><li><a target="_blank" href="https://www.youtube.com/@thang010146" rel="nofollow noopener">thang010146</a> for YouTube videos of mechanical mechanisms, particularly the self reversing leadscrew for a level cable winder</li></ul>&nbsp;

Pastamatic  Filament Spool Winder for Bambu X1C/P1P AMS (level winder with self reversing leadscrew)

BluSaphyre3D Favorite Prints

kevr102

Christmas is approaching fast and something which I have wanted to do for quite some time is a Solitaire board with a difference, one which can be used with either pegs or steel balls.This board is the 2nd iteration as my first attempt was far too small as I was wanting to use 6mm steel balls so I upped the anti so to speak.The board and its components use many of the tools available within Fusion 360 and its good to have a play around with it.To compliment the Solitaire board are the 3D printed pegs which can be used or 11mm steel balls or maybe marbles, I didn't have any marbles to try unfortunately but I did have the steel balls to hand, to further compliment the board there is a lidded container for the pegs or Steel Balls.All components printed as is with no support with the exception of the peg's which I flipped over.Would nice in some brighter colours, I only have Blue and Black PLA at this moment in time.&nbsp;All in all just a bit of fun but a great project to make and would make an ideal gift for someone.&nbsp;Rules of the game&nbsp;The objective is to remove all the steel balls or pegs from the board except one, by making valid moves according to the following rules: 1: Player starts off by removing the center piece. 2: Select a piece and jump over the adjacent one into a vacant hole. 3: Never jump diagonally, always horizontally or vertically. 4: The ‘jumped over’ piece is removed from the board. 5: The player repeats this move until there are no more pieces left to jump over. 6: The game is over when the player cannot jump over any of the other pieces. 7: The player can only finish a game successfully, by landing in the center hole with the final move.Having solved this puzzle, refill the board and remove a marble from any other cup and again finish in the cup that was left empty at the start.

Solitaire's the only game in town board

Creative Curiosities

The Big Greek

★★★ Update ★★★ 03.01.2024 ★★★&nbsp;after some people asked if I could make a version for 6x3mm magnets, i have finished the files for you.you can find these versions here <a target="_blank" href="https://makerworld.com/de/models/121783#profileId-131090" rel="nofollow noopener">https://makerworld.com/de/models/121783#profileId-131090</a>As I do NOT want to be banned for profile spamming, I have created a new download page.&nbsp;Please take this into account.---------------------------------------------------------------------------------------------------------------------------------------------&nbsp;Automatic Z-axis Lube Helper&nbsp;Easy to use easy to grease - No Supports needed&nbsp;I think all the tools that are available to download here are really great, only one thing bothers me, they only lubricate one side and the threads don't get enough in my opinion, and you have to do it manually.I thank SavageLau for the food for thought and everyone else.&nbsp;&nbsp;Why do it manually when you can do it on the touchscreen?&nbsp;&nbsp;That's why I developed this tool, and it works perfectly.&nbsp;The height is selected so that you can use it without a buildplate. Please do it that way, because you don't want to have any fat on the plate. you can't get that down so well.&nbsp;You can use it with or without magnets and it is suitable for all Z-axes (including the rear one). Of course you can also use it manually :-)&nbsp;The tip at the end is there so that you can remove the excess grease from the ball bearing or clean the threads again or, if you think there is too much grease, simply wipe it out.&nbsp;First print the tool (there are 2 versions, one with and one without Logo)&nbsp;&nbsp;<img src="https://makerworld.bblmw.com/makerworld/draft/464558/2023-12-29_6ca3e4a64ef4b.jpg">&nbsp;Next there is the option to insert magnets. if you do this, you will need some in the size 5x3mm. It also works without magnets, if none are available. These also hold the tool to the screws next to the ball bearing.The elevations that hold the magnet fit perfectly into the recess next to the ball bearing where the screws are.&nbsp;&nbsp;<img src="https://makerworld.bblmw.com/makerworld/draft/464558/2023-12-29_ed4fc73d9864a.jpg"><img src="https://makerworld.bblmw.com/makerworld/draft/464558/2023-12-29_0b93a148f8791.jpg">&nbsp;&nbsp;Once all this is done, we can start using the tool.&nbsp;First move your heatbed downwards, then position the tool on the desired axis. Press slightly diagonally over the axis and then downwards until it sits perfectly flush.&nbsp;&nbsp;<img src="https://makerworld.bblmw.com/makerworld/draft/464558/2023-12-29_660b48243315.jpg"><img src="https://makerworld.bblmw.com/makerworld/draft/464558/2023-12-29_1df0e77ce806b.jpg">&nbsp;&nbsp;then fill in the lubricating grease at the top. either the one supplied or a good one of your choice&nbsp;&nbsp;<img src="https://makerworld.bblmw.com/makerworld/draft/464558/2023-12-29_da5f4714cba24.jpg"><img src="https://makerworld.bblmw.com/makerworld/draft/464558/2023-12-29_758ad73d9a70c.jpg">&nbsp;&nbsp;next, raise the heatbed with the touchscren. be careful not to go all the way to the stop, otherwise you could damage your printer. it's best to do it bit by bit and don't forget to add grease, as one filling won't be enough.&nbsp;&nbsp;<img src="https://makerworld.bblmw.com/makerworld/draft/464558/2023-12-29_2bdb6b4176f4c.gif">&nbsp;&nbsp;if you don't like the result after the first run (as we all know, tastes differ), repeat this procedure until you are satisfied.it takes a little practice and skill, but then it works perfectly.&nbsp;easy to use, easy to grease&nbsp;Have fun building and greasingIf you like my work/project consider supporting me with these options:<ul><li>leave a like</li><li>leave a comment</li><li>download the file</li><li><a target="_blank" href="https://www.buymeacoffee.com/thebiggreek" rel="nofollow noopener">or By me a Coffee</a></li></ul>&nbsp;If you like the project, simply like and download it.

Useful Prints

BluSaphyre3D Favorite Prints

Creative Curiosities

Basic tools
