This is a 3D printed model of a Orion Class Heavy Frigate of the MCRN from the tv show the Expanse. This particular ship is named the Deimos. The ship has several features:&nbsp;- Retractable PDCs- Openable Torpedo tubes with torpedos- Extendable Docking Bridge- Openable Drone bay with a Drone&nbsp;The model is a kit and requires no glue. The ship is in scale with my <a target="_blank" href="https://www.printables.com/model/289226-morrigan-class-from-the-expanse" rel="nofollow noopener">Morrigan Class Patrol Destroyer</a>, <a target="_blank" href="https://www.printables.com/model/324572-corvette-class-light-frigate-from-the-expanse" rel="nofollow noopener">Corvett Class Light Frigate</a> and my <a target="_blank" href="https://www.printables.com/model/136343-rocinante-from-expanse" rel="nofollow noopener">Rocinante</a> model. For the assembly I highly recommend to watch the dedicated video about the project. <figure class="media"><div data-oembed-url="https://youtu.be/JuR1xDvDl8s"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/JuR1xDvDl8s" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure>

Orion Class Heavy Frigate from the Expanse

The Expanse

GekoPrime

I tried another spool winder but found it finicky and delicate.I designed this winder from scratch to be simple and robust, using the same self reversing leadscrew mechanism found on industrial cable windersWhy pick this model:<ul><li>Prints on a single build plate</li><li>Doesn't require heat set inserts or exotic hardware</li><li>Fusion and STEP files are available, remixes welcomed</li><li>Generous clearances, simple mechanisms</li><li>Designed to be a tool, not a project</li></ul>Print time:<ul><li>~500 grams of filament</li><li>~22 hours on Bambu Lab X1</li><li>~5 minute assembly</li><li>~2 minute spool transfer</li></ul>Hardware requirements:<ul><li><a target="_blank" href="https://www.amazon.com/s?k=608+bearings" rel="nofollow noopener">14x 608 skate bearings</a></li><li>A scrap of PTFE tubing</li><li>An electric screwdriver or drill with <a target="_blank" href="https://www.homedepot.com/p/DEWALT-MAXFIT-3-5-in-2-Philips-Bit-DWA3PH2MF/309474882" rel="nofollow noopener">a bit cut from ¼ inch hex stock</a> (most <a target="_blank" href="https://www.amazon.com/ITP1201-SCRWDRVNG-2IN-1-IMPAC/dp/B01LZZ7AOS/" rel="nofollow noopener">cheap quick change Philips bits</a> in the US fit this requirement)</li></ul>Print settings:<ul><li>Any. I used "0.16mm Optimal" in BambuSlicer with 5% adaptive cubic infill </li><li>Use 100% concentric infill for spindle_male_driven</li><li>Try the STLs if you have a problem with the 3mf files. I’ve added (xN) to each file name so you know how many to print</li></ul>Materials:<ul><li>Any. I used Polyterra and iiidmax PLA+</li><li>Use TPU for tpu_consumable_wiper_blade. I used Priline 98a. The wiper blades aren’t 100% required but they help keep the windings nice and tight</li></ul>Assembly and usage:<ul><li><a target="_blank" href="https://youtu.be/DxgkYDrRK-U" rel="nofollow noopener">Demo video</a></li><li><a target="_blank" href="https://youtu.be/-Hy69YwRLBw" rel="nofollow noopener">Assembly video</a></li><li>The side that says “Pastamatic" needs to face outwards, away from the spool</li><li>The filament needs to come in under the target spool, like this: O____O<ul><li>[not like this: O‾”‾”‾”O]</li></ul></li><li>The drill/driver needs to run clockwise, as though you're screwing something in</li><li>Accelerate slowly until the winder gets started</li></ul>Change log<ul><li>2023-05-28<ul><li>Initial release</li></ul></li><li>2023-05-29<ul><li>Fix a minor export glitch in "leadscrew_tooth"</li><li>Increase the number of “pin_short” instances in the 3mf from 6x to 8x</li></ul></li><li>2023-05-30<ul><li>Add a second prearranged 3mf with two plates to avoid overlap warnings</li><li>Disable autogenerated brims for the single plate 3mf </li><li>Add STLs for people who have trouble with the 3mf</li></ul></li><li>2023-06-03<ul><li>Add a ring to passive_target_cradle to prevent the far end of the target spool lifting if a user lets the the drill hang loose</li><li>Add a pin to driven_target_cradle prevent the leadscrew popping out</li><li>Fix a minor clearance issue where a dovetail didn't fit quite right</li></ul></li><li>2023-09-30<ul><li>Reduce chamfer on the crossbars to prevent them falling over when bed adhesion is poor</li><li>Add some holes to the crossbars to make them easier to screw down</li><li>Add some popular acessories to the all-in-one .3mf</li><li>Add a printable spool to the all-in-one .3mf</li></ul></li></ul>How to contribute:<ul><li>Post your make, it keeps me motivated to improve the model when I see people using it!</li><li>Post your feedback, idea or remix in the comments!</li><li>There are a few improvements and accessories in development as remixes, check those out if you‘re up for the alpha/beta tester experience<ul><li><a target="_blank" href="https://www.printables.com/model/498743-pastamatic-37-mm-motor-mount" rel="nofollow noopener">Adapter for 37mm gear motor</a></li><li><a target="_blank" href="https://www.printables.com/model/556405-pastamatic-filament-spool-winder-modifications-bra" rel="nofollow noopener">Source spool holder for 5 KG spools</a></li></ul></li></ul>Credits:<ul><li><a target="_blank" href="https://www.printables.com/@MiklosKiszely_486882" rel="nofollow noopener">@MiklosKiszely_486882</a> for the original idea</li><li><a target="_blank" href="https://www.printables.com/@PsychoShaft_33891" rel="nofollow noopener">@Psycho Shaft</a> for the drag/tensioner concept</li><li><a target="_blank" href="https://www.youtube.com/@thang010146" rel="nofollow noopener">thang010146</a> for YouTube videos of mechanical mechanisms, particularly the self reversing leadscrew for a level cable winder</li></ul>&nbsp;

Pastamatic  Filament Spool Winder for Bambu X1C/P1P AMS (level winder with self reversing leadscrew)

Toolbench

smittyrn

Maybe you like the Original Clickfinity Refined but think it uses too much filament, or maybe you were just looking at different Gridfinity baseplates and found this. Either way, this might be what you are looking for.   <a target="_blank" href="https://www.printables.com/model/506105-clickfinity-refined-baseplates-for-use-with-gridfi/files" rel="nofollow noopener">Clickfinity Refined</a> by was created by combining a couple of great variations of the original Gridfinity baseplates into one model, resulting in baseplates that secures bins without magnets and can snap together with connectors to fill any open space you have. These baseplates retain that functionality while needing significantly less filament and print time. You can use anything made for Gridfinity with these plates. I cut the original down down to just what was needed to hold shape and preserve functionality.   PROS:<ul><li>Secures bins as well as the original design</li><li>25% reduction in filament use</li><li>20% saving on print time</li></ul>CONS:<ul><li>No cool baseplate holders or trim pieces (yet)</li><li>Connectors are a bit hard to manipulate if you have sausage fingers</li><li>Very thin sections where the connectors are used (this is very noticeable on the corners, where there are only 2 1mm thick sections attaching each corner)</li></ul>The connectors needed a full 2mm thickness to securely hold the sections together, which left only an 1mm thick area below it. I initially just extruded the bottom by 1mm to make it a little beefier, but that cut the filament savings down to only 11%, pretty much defeating the purpose. They still are sturdy enough, but if you want to reduce flex you can use something like Tinkercad to combine single blocks to get rid of gaps.   As with original Clickfinity Refined, don't print these in PLA; not only will the snap holders deform with time and use, your corners can easily break off. PETG works great, and the flex keeps the corners intact.
