良民宋先生

<p><strong>【1/23/24】更新版：</strong></p><ul><li>底板减少厚度，更加省材料</li><li>底板加了凹槽，可嵌入4颗10x2mm的磁铁，或者做挂钩用</li><li>修改了钉子的形状，增加容错度，嵌入时更加容易</li></ul><p><strong>new version:</strong></p><ul><li>thinkness reduced, less filament used</li><li>add 4 sockets on the backplate, compatible with 10x2mm cylinder magnets.</li><li>optimized the shape of the fins and sockets, so they can put together more easily.</li></ul><p>---</p><p>&nbsp;</p><p>去年我买了一部P1S打印机，一直以来都是下载别人的模型进行打印。这是我第一次尝试自己建模。受到前辈们制作的福字挂饰的启发，我也想尝试一下，于是制作了这个春节的福字挂件，请多指教。</p><p>&nbsp;</p><p>框上的花纹和祥云图案是手绘的，我在Maya软件中进行建模然后导出。由于我没有AMS，不能同時打印多色，所以分开了三個板，祥云单独做了一板，如果有需要可以单独上色。另外我设计了卡扣和插口，这样无需使用胶水也能拼装起来。</p><p>&nbsp;</p><p><strong>拼装时请注意： </strong><br>安装金色框架时，请注意其中一个钉子比其他的短。这个较短的钉子应与背板上的较短孔相对应。此外，较短孔的角落也是正方形的顶角。这个细节将帮助您在安装过程中正确地定位标志。</p><p>&nbsp;</p><p><strong>Installation Note:</strong></p><p>When installing the golden frame, note that one of the clips is shorter than the others. This clip should be matched to the shorter hole on the backplate. Additionally, the corner with the shorter hole marks the top corner of the square. This detail will assist you in correctly orienting the sign during installation.</p>

祥雲福字挂飾（雙色可單獨打印拼裝，免膠，免AMS）

装饰

一百

<h2>铝型材钻孔中心定位 Drill Guide for Aluminum Profile</h2><ul><li>钻套规格：M14（牙距1mm），<a target="_blank" href="https://item.taobao.com/item.htm?_u=jkuhore2d6a&amp;id=529248810954&amp;skuId=3967508225257&amp;spm=a1z09.2.0.0.4e1e2e8dAYqm7Y" rel="nofollow noopener">吴新工具钻套购买地址</a></li><li>推荐使用PAHT-CF，测试PLA容易损坏</li></ul><figure class="media"><div data-oembed-url="https://youtu.be/XTDwwKVNcHE?si=8sgcnFi_a0U1dJlH"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/XTDwwKVNcHE" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure><figure class="table" style="float:left;width:100%;"><table class="ck-table-resized"><colgroup><col></colgroup><tbody><tr><td style="background-color:hsl(0, 0%, 90%);"><h3><strong>更新日志</strong></h3></td></tr><tr><td style="background-color:hsl(0, 0%, 100%);vertical-align:bottom;"><ul><li><u>2024/01/19 15:51:37</u><ul><li>首次发布，适配4040铝型材</li></ul></li><li><u>2024/04/21 23:40</u><ul><li>新增适配2020、3030铝型材</li></ul></li></ul></td></tr></tbody></table></figure><p>&nbsp;</p><p><a target="_blank" href="https://paypal.me/yibaiIOO" rel="nofollow noopener">如果你想请问喝杯奶茶的话 : )</a></p>

Drill Guide for Aluminium Profile

铝型材

3D Print Masters Hub

<p><span style="font-size:20px;"><strong>Stackable Bin Box</strong></span></p><p>-Great for organizing misc hardware parts, batteries, screws, clips and more!</p><p>&nbsp;</p><p>Internal Size:</p><ul><li>3.5&#34; wide x 6&#34; Length x 2.6&#34; High</li><li>90mm wide x 155mm Length x 66mm high</li></ul><p>-Easy print.</p><p>-Scale down as needed.</p><p>-See my profile for more configurations!!</p><p>-<span style="background-color:rgb(230,230,77);">Please like and subscribe! More to come!</span></p><p>-See bio for more exclusive print project ideas.</p><p>🔥🔥 Check out my PRO MODELS HERE! <a target="_blank" href="https://cults3d.com/en/users/FabulousFilaments/3d-models" rel="nofollow noopener">https://cults3d.com/en/users/FabulousFilaments/3d-models</a> 🔥🔥</p>

Stackable Bin Box

工具

WIZZY

<p>Glock 17 with movable parts (Trigger,Magazine)</p><p>on the spring part the support is a little bit tricky to remove<br><br>check out my other models too</p>

Glock 17

玩具

JayRay

<p><i>This is the original #3DBenchy directly from Creative Tools. Not a download of a download, nor all the slightly modified versions found elsewhere (ie, BambuLab Studio, Printables, etc…)</i></p><p>&nbsp;</p><p><strong>I would like to introduce the #3DBenchy to Maker World. During the close beta period, there was no #3DBenchy available to send to the printer from the phone app so I uploaded it here. </strong></p><p>&nbsp;</p><p><strong>Please add your profiles as you see fit for the community to use to run tests. Thanks!</strong></p><p>&nbsp;</p><p>Community members have provided a ton of different profiles. I hope you find one that fits your testing needs. Remember, a bad Benchy print could mean your filament calibrations are off, or a sign of mechanical error (for Bambu Printers.)</p><p>&nbsp;</p><p><i>All models uploaded and the below content is extracted from 3Dbenchy.com.</i></p><figure class="media"><div data-oembed-url="https://youtu.be/_epwuDI9FBI"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/_epwuDI9FBI" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure><p>&nbsp;</p><figure class="image"><a href="http://www.3dbenchy.com/features/" target="_blank" rel="nofollow noopener"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/3DBenchy__Low-slope_surfaces_1-300x300.png"></a></figure><p>#3DBenchy is designed to offer a large array of challenging geometrical features for 3D printers, and touch on different issues related to additive manufacturing.</p><p>The 3D model is designed to print at 1:1 scale without support materials. It is challenging for most 3D printers but the small volume (15.55 cm3) typically prints in well under two hours and does not require much material.</p><p>The different surfaces of the #3DBenchy model reveal typical issues regarding surface finish, model accuracy, warping, etc.</p><p>Visit <a target="_blank" href="http://www.3dbenchy.com/sample-page/features/" rel="nofollow noopener">this link</a> to see a complete list of each feature and correspondent descriptions.</p><figure class="image"><a href="http://www.3dbenchy.com/dimensions/" target="_blank" rel="nofollow noopener"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/3DBenchy_about_features-300x287.png"></a></figure><p>Use #3DBenchy to test and calibrate your 3D printer by adjusting hardware and software settings for optimal results.</p><p>The shape and size of this 3D model is designed to challenge 3D printers. Compare your #3DBenchy results with the dimensions illustrated in <a target="_blank" href="http://www.3dbenchy.com/dimensions/" rel="nofollow noopener">this link</a>. These are easy to measure with a caliper.</p><p>Print and check your 3D-printer’s result for dimensional accuracy, tolerances, warping and deviations related to changes in printing parameters and material types.</p><p>&nbsp;</p><h2>Features</h2><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/3DBenchy_page_features_main_image.png"></figure><p>#3DBenchy is designed to offer a large array of challenging geometrical features for 3D printers, and touch on different issues related to additive manufacturing.</p><p>The 3D model is designed to print at 1:1 scale without support materials. It is challenging for most 3D printers but the small volume (15.55 cm3) typically prints in well under two hours and does not require much material.</p><p>The different surfaces of the #3DBenchy model reveal typical issues regarding surface finish, model accuracy, warping, etc.</p><p>Please see a complete list of each feature and correspondent descriptions below.</p><p>&nbsp;</p><h2>The Hull</h2><p>The hull is a large, smooth overhanging curved surface that is challenging to 3D-print, and clearly reveals any surface deviations.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_hull_curved_overhang-300x300.png" alt="Feature_hull_curved_overhang"></figure><p>&nbsp;</p><h2>Symmetry</h2><p>#3DBenchy is perfectly symmetrical which makes any skewness and warping easy to detect.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_symmetry-300x300.png" alt="Feature_symmetry"></figure><p>&nbsp;</p><h2>High-Resolution STL file</h2><p>The STL file is triangulated at a very high resolution which yields smooth surfaces. The maximum deviation from the original CAD file is set to 0.001 mm.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_high-res_stl_mesh-300x300.png" alt="Feature_high-res_stl_mesh"></figure><p>&nbsp;</p><h2>Planar Horizontal Faces</h2><p>The top surfaces of the deck, box and chimney are planar, horizontal and parallel to the bottom plane.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_planar_horizontal_faces-300x300.png" alt="Feature_planar_horizontal_faces"></figure><p>&nbsp;</p><h2>Tiny Surface Details</h2><p>If you have a high-resolution 3D printer, this is where you can shine! The letters on the stern are less than 2 mm tall and the thickness of #3DBenchy’s nameplate is just 0.1 mm.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_3DBenchy_nameplate_tiny_detail-300x300.png"></figure><p>&nbsp;</p><h2>Cylindrical Shapes</h2><p>The chimney is designed to define concentrical cylindrical shapes with inner and outer diameters. These clearly show deviations in roundness.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_conentrical_cylindrical_shapes-300x300.png" alt="Feature_conentrical_cylindrical_shapes"></figure><p>&nbsp;</p><h2>Overhang Surfaces</h2><p>Overhang issues are the Achilles’ heel of 3D printing. #3DBenchy offers several challenging areas such as in the difficult-to-reach inside of the bridge.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_overhang_bridge-300x300.png" alt="Feature_overhang_bridge"></figure><p>&nbsp;</p><h2>Low-Slope-Surfaces</h2><p>Low-slope-surfaces clearly show the layered structure of 3D printing. If printed horizontally, #3DBenchy’s gunwale and roof of the bridge will reveal the layer-steps.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_low-slope-surfaces-300x300.png" alt="Feature_low-slope-surfaces"></figure><h2>Large Horizontal Holes</h2><p>The rear window offers a large circular horizontal hole and the boat’s wheel offers a round difficult-to-reach secluded feature.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_large_horizontal_hole-300x300.png" alt="Feature_large_horizontal_hole"></figure><p>&nbsp;</p><h2>Small Horizontal Holes</h2><p>The hawsepipe represents a small short horizontal hole and has a very thin flange against the hull.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_hawsepipe_small_hole-300x300.png" alt="Feature_hawsepipe_small_hole"></figure><p>&nbsp;</p><h2>Slanted Small Holes</h2><p>The fishing-rod-holder provides a very small slightly-slanted blind hole.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_fishing-rod-holder_slanted_small_hole-300x300.png" alt="Feature_fishing-rod-holder_slanted_small_hole"></figure><p>&nbsp;</p><h2>First-Layer-Details</h2><p>The shallow letters at the bottom of the boat clearly reveal typical first-layer-squashing.</p><p>&nbsp;</p><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_shallow_letters_bottom_plate-300x300.png" alt="Feature_shallow_letters_bottom_plate"></figure><h2> License</h2><figure class="image"><a href="http://www.3dbenchy.com/wp-content/uploads/2015/04/3DBenchy_frontpage_slider_sea_v041.jpg" target="_blank" rel="nofollow noopener"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/3DBenchy_frontpage_slider_sea_v041-1024x402.jpg"></a></figure><p>&nbsp;</p><p>#3DBenchy by <a target="_blank" href="http://creative-tools.com/" rel="nofollow noopener">Creative-Tools.com</a> is licensed under a <a target="_blank" href="http://creativecommons.org/licenses/by-nd/4.0/" rel="nofollow noopener">Creative Commons Attribution-NoDerivatives 4.0 International License</a>. Permissions beyond the scope and typical usage examples are explained below.</p><p>&nbsp;</p><h2>Feel free to …</h2><ol><li>… <strong>download</strong> the <a target="_blank" href="http://www.3dbenchy.com/download/" rel="nofollow noopener">#3DBenchy STL file</a> and 3D-print it as you please.</li><li>… <strong>give away</strong> and even <strong>sell</strong> 3D-prints of the <a target="_blank" href="http://www.3dbenchy.com/download/" rel="nofollow noopener">#3DBenchy STL file</a>.</li><li>… <a target="_blank" href="http://www.3dbenchy.com/share/" rel="nofollow noopener"><strong>publish</strong></a> images and videos of your 3D-prints – <i>you own them!</i></li><li>… <strong>redistribute</strong> the <u>unmodified</u> <a target="_blank" href="http://www.3dbenchy.com/download/" rel="nofollow noopener">#3DBenchy STL file</a> as you please. Such as hosting your own downloads, attaching to emails, including the file on DVDs, USB-sticks, and in software distributions, bundling the STL or pre-sliced print file with 3D printer kits, etc.</li><li>… <strong>experiment</strong>, be <strong>inventive</strong> and <strong>creative</strong>! We made #3DBenchy as a tool for playing around with and testing 3D printers. Improve your skills and challenge your machine and its software. Try every setting, variation and material you can think of!</li><li>… modify #3DBenchy for <strong>personal</strong> use. Feel free to publish texts, images and videos of your experimentation (these are your work and you own them!). Please respect the above list items regarding not distributing modified STL files of #3DBenchy.</li></ol><h2>Consistency</h2><p>#3DBenchy is designed to be a calibration tool for testing 3D print settings and comparing the performance of different 3D printers. Therefore it is <u>important</u> that the same unmodified <a target="_blank" href="http://www.3dbenchy.com/download/" rel="nofollow noopener">STL</a> file is consistently used for this purpose.</p><h2>Attribution</h2><p>We designed the little #3DBenchy boat and this expanding web page <u>to help</u> 3D printer operators on this planet to better navigate the vast sea of 3D printing possibilities!</p><p>It is also meant to be a fun object to experiment with and discover 3D printing. If you enjoy #3DBenchy and the content on this site, please give us attribution in your publishings. Simply include the word <a target="_blank" href="https://www.google.se/webhp?sourceid=chrome-instant&ion=1&espv=2&ie=UTF-8#q=%233dbenchy" rel="nofollow noopener">#3DBenchy</a> and the URL <a target="_blank" href="http://3dbenchy.com/" rel="nofollow noopener">3DBenchy.com</a>. The team behind #3DBenchy highly appreciates your help!</p>

BENCHY

测试文件

schutz

<p><i>Update 3-Apr-24: Added a second print profile that provides narrower slits to catch smaller pieces of desiccant. The first print profile (white picture) slits are 2mm wide. The updated (blue picture) is 1.5mm wide.</i></p><figure class="image image_resized" style="width:34.69%;"><img src="https://makerworld.bblmw.com/makerworld/draft/809741/2024-04-03_8d36d08b0cce7.png"></figure><p>For my first model on MakerWorld, this AMS desiccant holder provides a clean fit and finish that snaps into the AMS so nicely, you&#39;d think this is what Bambu Lab had originally intended. Using color-indicating desiccant with this model makes it easy to see when it needs a recharge, and the large opening on the back is protected by a U-shaped cantilever snap-in cover to make sure those desiccant beads stay where they belong until it&#39;s time for a change.</p><p>&nbsp;</p><p>Keeping your AMS dry has never been easier…unless you like to fidget with plastic snap fits, in which case those satisfying clicks may keep you standing over your open AMS longer than intended.</p><p>&nbsp;</p><p>This model was created from scratch, but inspired primarily by <a target="_blank" href="https://www.printables.com/model/409676-bambu-lab-ams-rear-desiccant-refillable-tray" rel="nofollow noopener">Mikyleee&#39;s similar model</a> (printables.com link).</p><h3>Printing</h3><p>I printed in PLA with the 0.20mm Standard profile. Supports are NOT needed on the interior, but they ARE needed on the rear snap fit and along the front, as well as a couple underneath.</p><figure class="image image_resized" style="width:43.3%;"><img src="https://makerworld.bblmw.com/makerworld/draft/809741/2024-03-06_f15fe781ce57f.png"></figure><p>The bottom cover is small and the end of the cantilever snap does not have much contact with the print bed. Print this part slowly to avoid adhesion issues. <strong>You should not need a brim!</strong></p><h3><i>“Critical feedback is always appreciated”</i></h3><p>I have never done a snap cover like this, and I know it is far from ideal. Posting your makes and comments encourages me to improve. Tell me what you think!</p>
