Tolerance Test
IP Report
GIF
Print Profile(1)
0.2mm layer, 22 walls, 15% infill
Designer
2.1 h
1 plate
Open in Bambu Studio
Boost
62
183
16
6
279
138
Released
Description
This model is designed to serve as a comprehensive reference for making design decisions related to printing in-place sliders, rotating knobs, and cylinders with journals on bushings.
- The model allows you to access its features using a micrometer, as shown in the pictures below.
- To rotate the knobs, you can use the notch located at the bottom of the knob with the help of a medium screwdriver. However, this will only work if the printer is capable of preventing the assembly from fusing together.
- The vertical slim tabs located on the top of the knobs will only print if the slicer can pick them up and the printer is capable of printing them.
- I've noticed that many other prints designed to test tolerances lack clearly marked units. To rectify this, I have added a clear inscription of the units and arrows that indicate the tolerance gap per side rather than the total tolearance. For instance, 0.1mm should be read as 0.1 radius-0.2 diameter.
I hope it helps with the design process.
