marek.fries


0.2mm layer, 2 walls, 0% infill, 7 Layer top, 7 layer bottom

<div><h1 class="thing-component-header summary summary">Summary</h1><div><p>Update 12.2024:<br>Strömung verbessert und ein glatterer Verlauf generiert.</p><p><strong>Wichtig ohne Infill drucken, dafür aber mit 7 Layern unten und oben, mehr nicht.</strong></p><p>Falls jemand die kürzer / länger braucht, aufgrund einer Adapterplatte etc., meldet euch, dann wird es zusätzlich hochgeladen.</p><p>Ansaugmuffe für die Simson S50/S51/S70 Herzkasten in Verbinung mit einem VM20.</p><p>28mm auf 40mm<br>Herzkasten 29,3mm<br>Vergaser 42mm<br>Länge 54mm</p></div><h1 class="thing-component-header settings print-settings">Print Settings</h1><p class="detail-setting printer brand"><strong>Printer Brand: </strong>                         </p><div><p>Creality</p></div>                                    <pre><code>                                            <p class="detail-setting printer"><strong>Printer: </strong>                     </p><div><p>Ender 3</p></div></code></pre><p></p>                                    <p class="detail-setting rafts"><strong>Rafts: </strong>                         </p><div><p>No</p></div>                                    <pre><code>                                            <p class="detail-setting supports"><strong>Supports: </strong>                     </p><div><p>No</p></div></code></pre><p></p>                                    <p class="detail-setting resolution"><strong>Resolution: </strong>                         </p><div><p>0,2</p></div>                                    <pre><code>                                            <p class="detail-setting infill"><strong>Infill: </strong>                     </p><div><p>0%</p></div></code></pre><p></p>                                    <p class="detail-setting filament_material"><strong>Filament Material: </strong>                         </p><div><p>TPU</p></div></div>


<div><h1 class="thing-component-header summary summary">Summary</h1><div><p>Update 12/2024:<br>Improved airflow and a smoother flow generated.</p><p><strong>Important: Print without infill, but with 7 layers on the top and bottom, no more.</strong></p><p>If anyone needs a shorter/longer version due to an adapter plate etc., please contact me, and it will be uploaded additionally.</p><p>Intake manifold for the Simson S50/S51/S70 crankcase in conjunction with a VM20.</p><p>28mm to 40mm<br>Crankcase 29.3mm<br>Carburetor 42mm<br>Length 54mm</p></div><h1 class="thing-component-header settings print-settings">Print Settings</h1><p class="detail-setting printer brand"><strong>Printer Brand: </strong>                         </p><div><p>Creality</p></div>                                    <pre><code>                                            <p class="detail-setting printer"><strong>Printer: </strong>                     </p><div><p>Ender 3</p></div></code></pre><p></p>                                    <p class="detail-setting rafts"><strong>Rafts: </strong>                         </p><div><p>No</p></div>                                    <pre><code>                                            <p class="detail-setting supports"><strong>Supports: </strong>                     </p><div><p>No</p></div></code></pre><p></p>                                    <p class="detail-setting resolution"><strong>Resolution: </strong>                         </p><div><p>0.2</p></div>                                    <pre><code>                                            <p class="detail-setting infill"><strong>Infill: </strong>                     </p><div><p>0%</p></div></code></pre><p></p>                                    <p class="detail-setting filament_material"><strong>Filament Material: </strong>                         </p><div><p>TPU</p></div></div>

Simson Muffe Original Intake Manifold on VM20 Tuning
