HUEFORGE 0.08mm layer, 2 walls, 100% infill
HUEFORGE 0.08mm layer, 2 walls, 100% infill
Designer
1.5 h
1 plate
5.0(4)

Open in Bambu Studio
Boost
17
35
4
1
30
8
Released

Description

***Scale to 80% to fit the A1 Mini



The layer transitions are already inserted, you will see them once you slice it. If you only have one AMS, change the last swap to one of the colors besides blue and manually replace it while the blue is printing, so when it swaps back to it you will end up with the fifth color.



Hueforge settings:

Print at 100% infill with a layer height of 0.08mm with a base layer of 0.16mm

The Model is 150x200mm in size
You may print at higher layer heights below the Min Depth of 0.48mm
The Max Depth is 2.2mm and the Actual Depth is 2.2mm

Filaments Used:
PLA Elegoo Black Transmission Distance: 1
PLA Anycubic Gray Transmission Distance: 4
PLA Elegoo White Transmission Distance: 5.5
PLA eSUN Blue Transmission Distance: 3.5
PLA Elegoo Sky Blue Transmission Distance: 5
This print uses 5 unique filaments

Swap Instructions:
Start with Black
At layer #7 (0.64mm) swap to Gray
At layer #12 (1.04mm) swap to White
At layer #15 (1.28mm) swap to Blue
At layer #20 (1.68mm) swap to Sky Blue for the rest.
