MINI Top Handle HD
Print Profile(1)
Description
MINI Series HD Top Handle MSTH
Heavy-Duty Handle for Safe Transport
Want to carry your little monster safely or move it around? Try this heavy-duty designed handle—no need to worry about breaking it.
Installation Instructions
- Place the Handle:
- Start by placing the handle flush on top of the tower.
- Insert into the Rail Slot:
- Slowly push the handle into the bearing rail slot. It’s a tight fit, so wiggle it slightly to get it in place.
- Align and Secure the Front Screw:
- Once the handle is centered, insert the front long screw and tighten it just enough.
- Check the alignment of the bolt holes on the tower side to ensure they line up.
- Install the Top Screws:
- Install the 3 top screws loosely.
- Tighten the Bolts:
- Tighten all 4 bolts securely, but be careful not to overtighten.
Now you're ready to safely carry your little monster!
A1 MINI printing MSTH on Ludicrous:
V1.0 Specifications
Material: PETG (recommended for durability and strength).
Printer Settings:
- Profile: Standard
- Layer Height: 0.20 mm
- Mode: CERTIFIED LUDICROUS
- Infill: 20%
- Walls: 3
- Bottom Layers: 3
- Top Layers: 5
Printing Details:
- Supports: Not required
- Print Time: 2:19
- Filament Usage: 2.04 oz
Estimated Cost: ~$1.45 (based on a $26 PETG spool)
Boost Me (for free)
🚀 Boost Your Project! 🚀
If you love what I'm working on, hit the Boost button! Your support helps me continue to create, improve, and share even more exciting designs. Thank you for being part of this journey!
Enjoy your printing journey, and remember—keep your fingers away from the poop chute, she's angry!
"I’ll be sure to keep you updated with any future developments. If you come across any issues or need assistance, don’t hesitate to reach out—I’m here to help!"
You shall not share, sub-license, sell, rent, host, transfer, or distribute in any way the digital or 3D printed versions of this object, nor any other derivative work of this object in its digital or physical format (including - but not limited to - remixes of this object, and hosting on other digital platforms). The objects may not be used without permission in any way whatsoever in which you charge money, or collect fees.
Current ver.1.0_10/16/2024
