UPDATE v1.1: Whoops! I realized that the original profile accidentally colored two bottom jaw pieces purple instead of gray.  This update recolors those pieces to match the original creator, moves them to the gray plate, and slightly rearranges items on the gray and purple plates to compensate.  No other changes were made so all the pieces are still compatible.  If you&#39;ve already printed part of the model and care about the correct colors you can just print the two pieces of the bottom jaw shown in the final photo.&nbsp;Description:This is a really cool model but I couldn&#39;t stomach the amount of waste it would create printing the whole thing in multi-color.  I cut the model into plates by color to minimize the use of multi-color AMS.  A few small pieces still use the AMS, as it wasn&#39;t practical to cut them and the waste amount was small.&nbsp;Alignment connectors were added to the cut pieces where possible to make reassembly easier.  Unfortunately there are a couple places (e.g. the green tips in front of the purple collar) where even the smallest connectors would be too large and would leave holes in the walls.  So those pieces need a steady hand to glue or solder back together.&nbsp;The Statistics (i.e why choose this profile?):Total print time was reduced ~50% from 51h to 24h20m.Total filament consumed was reduced ~50% from 927g to 471g. &nbsp;Instructions:Simply print all the plates and use the second and third photos as a guide to reassemble the cut pieces.  Once everything looks like the third photo, you can follow the original creator&#39;s video guide to complete assembly.  Note that melting the plastic together with a soldering iron (as shown in his video) is recommended over super glue (CA glue).  The glue will create a white discoloration on whatever pieces you bond with it, and on such a small model the white fuzz can cover a large area.

Faster Print! Less Waste! (Cut and Plated by Color)

Melted Plastic




2024-08-25_1a9d492157f36

_(1).2024-08-25_aa3b394ab615b

_(2).2024-08-25_d474b8c9a521b

_(3).2024-08-25_8167d7fe50d2d

_(4).2024-08-25_fe07e15629499

_(5).2024-08-25_d5b1f155a3f0e

_(6).2024-08-25_29a41c042433d

_(7).2024-08-25_7de66503e7eca

_(8).2024-08-25_774efe46195af

_(9).2024-08-25_f21cd9f1688ff

_(10).2024-08-25_92e89c2f75f21

.2 2 10%&nbsp;A1 Mini profile at 80% scale with some adjustments to printing&nbsp;Colors are the Eva 01 Berseker Colors feel free to change them&nbsp;

80% Scale A1 Mini




CNC Wood Projects




In some parts i cut the model for avoid changes and better quality printing.The larger antenna its horrible to print with my P1S (with my filament and knowledge) i cut every color in one file for print.I cut the green part of another piece (easy one to cut and latter glue) for avoid a lot of changes.&nbsp;Be careful and print with your settings, i put some parts in 0.24mm layer height and i used a lot of hard supports, use your better settings.&nbsp;I&#39;m not expert and i printed correctly with my p1s, but your filament or printer maybe can&#39;t do it.

Original size some parts cutted less filament no ams READ !

You shall not share, sub-license, sell, rent, host, transfer, or distribute in any way the digital or 3D printed versions of this object, nor any other derivative work of this object in its digital or physical format (including - but not limited to - remixes of this object, and hosting on other digital platforms). The objects may not be used without permission in any way whatsoever in which you charge money, or collect fees.

This user content is licensed under a Standard Digital File License.

This is a multi-color version of the evangelion unit 01 I designed a while ago. The inner structures were redesigned a bit.All the parts were remade to fit with each other. The parts were thickened for FDM printing.If you like it, print yours and post it as well.The model is free and I hope all the EVA fans will like it and the more people print the more models I will design.An assembly video will be uploaded to my bilibili channel. <figure class="media"><oembed url="https://www.bilibili.com/video/BV12ZWEeJECU/?spm_id_from=333.999.0.0&amp;vd_source=b23d425c45d9687312eaa110c68fcd90"></oembed></figure><boostme><boosttitle>Boost Me</boosttitle><boostcontent>Print your EVA UNIT01</boostcontent></boostme>新世纪福音战士头像改良版增加了头部内的结构和分件改良了分件厚度更容易FDM打印了组装视频会分享到自己的b站频道上一共用了6种颜色，分件最多一个用3种颜色应该带AMS的都可以打印喜欢的话自己也打印一个吧&nbsp;
