Super Mario Bros - Warp Pipes Brick Planter

Enhance your 3D printing collection with this complete set of Warp Pipes and a matching base, inspired by the iconic NES game, Super Mario Bros. The collection includes four different sizes of Warp Pipes, each capturing the nostalgic essence of the classic game. The base, designed to resemble a traditional brick structure, not only adds stability to your display but also enhances the authenticity of your setup. Perfect for showcasing your Warp Pipes, this combination brings a touch of retro charm to any project, making it an ideal addition to your collection.

Features:

• Authentic Design: Modeled after the iconic Warp Pipes from Super Mario Bros., this planter base provides a perfect display platform, enhancing the nostalgic appeal of your setup.
• Warp Pipes:
  • Small: 44 mm x 44 mm x 28 mm (Filament: 4.25m, 12.58g | Print Time: 35m)
  • Medium: 44 mm x 44 mm x 42 mm (Filament: 5.42m, 16.03g | Print Time: 46m)
  • Large: 44 mm x 44 mm x 56 mm (Filament: 6.55m, 19.39g | Print Time: 58m)
  • Extra-Large: 44 mm x 44 mm x 70 mm (Filament: 7.71m, 22.80g | Print Time: 1h 9m)
  • All Four Warp Pipes: (Filament: 23.35m, 69.08g | Print Time: 2h 25m)
• Base:
  • Inner Dimensions: 166 mm x 37 mm x 4 mm
  • Outer Dimensions: 178 mm x 49 mm x 7 mm (Filament: 11.81m, 34.93g | Print Time: 50m)
• Detailed STL Files: High-quality files ensure clear and precise prints.
  • All Four Warp Pipes + Base: (Filament: 35.16m, 104.01g | Print Time: 3h 15m)

Print Settings:

• Print Mode: DRAFT @ KOBRA 3 (0.35 mm nozzle) for a balance between quality and speed.
• Layer Height: 0.35 mm (yields faster production without sacrificing too much quality, perfect for displaying the rough finish brick style)
• First Layer Height: 0.35 mm
• Vertical Shells (Wall Thickness): 2 perimeters (approx. 0.98 mm)
• Horizontal Shells:
  • Top Layers: 4 layers (for a solid top finish)
  • Bottom Layers: 3 layers (for a solid bottom finish)
  • Minimum Shell Thickness: Top: 1.2 mm, Bottom: 1.6 mm (for layer height 0.35 mm)
• Infill:
  • Fill Density: 10% (minimizes filament use while maintaining strength)
• Brim (if needed):
  • Type: Outer brim only
  • Width: 1 mm
  • Separation Gap: 0.15 mm
• Support: None required.

For practical use as a planter, consider scaling up the design to provide a wider base, which supports better plant growth. Also, these warp pipe planters are designed for ease of printing without the need for supports. Please note that the base may not be fully solid depending on the inherent traits of your individual printer.

For optimal results, I recommend increasing the infill to 30% - 50% to enhance thickness and improve water retention, as this design does not include a drainage hole.
