FlorinV

cover








0.2mm layer, 3 walls, 15% infill


Jonathan Poisson








0.16mm layer, 3 walls, 25% infill, PETG/ASA&nbsp;I recommend using a 20mm brim on the vertical parts to avoid warping issues, and 10mm brim on the legs for ASA specifically.I've had several failures with 10cm with PETG/ASA.&nbsp;You can print it with 0.2mm layer height, but you will most likely have visual defects around the curved areas.&nbsp;Using 0.16mm leads to perfect contours with PETG and near-perfect with ASA for me.&nbsp;Use normal supports for the connector piece to maintain the integrity of the hole structure, they come off very easily with mild pressure from the bottom.&nbsp;I've also used adaptive layer height (max quality, adaptive) on the vertical parts to help with curves/quality.&nbsp;The profile uses 3 walls, feel free to add more if you want but the angle of the part makes it challenging to increase strength due to the angle of the layers (45 degree printing angle would be fantastic in the future).&nbsp;It is very important to use Gyroid infill pattern on the vertical pieces rather than Grid to avoid vibrations from sharp turns.&nbsp;I used Bambu PETG-HF on a Bambu A1 on a textured PEI plate without glue (white tripod)I used Bambu PETG-HF on a Bambu P1S on a textured PEI plate without glue (dark blue tripod)I used Matter3D Performance ASA on a Bambu P1S on a smooth PEI plate with Magigoo liquid glue (black tripod).&nbsp;PETG-HF works beautifully but I still got mild defects on the top portion of the holder with ASA, YMMV (just slow it down a bit perhaps)

0.16mm layer, 3 walls, 25% infill, PETG/ASA

You shall not share, sub-license, sell, rent, host, transfer, or distribute in any way the digital or 3D printed versions of this object, nor any other derivative work of this object in its digital or physical format (including - but not limited to - remixes of this object, and hosting on other digital platforms). The objects may not be used without permission in any way whatsoever in which you charge money, or collect fees.

This user content is licensed under a Standard Digital File License.

<ul><li>simple to print and assemble</li><li>light tripod ( aprox. 150gr )</li><li>easy to carry and store.</li><li>it floats, you cannot loose this one. 😁🍻</li><li>Based on a request, I&#39;ve added another part which can be used to extend the height of the tripod. Not tested by me, but based on the user feedback it works fine. You can find it here:  &nbsp;<figure class="image image_resized" style="width: 44.16%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000488945/design/2024-09-05_b3125f763cc1e.png"></figure></li></ul> <a target="_blank" rel="noopener noreferrer ugc" href="https://makerworld.com/en/models/1562133-strong-fishing-rod-belt-holder#profileId-1641833">Please check my new Fishing Rod holster: </a><figure class="image image_resized" style="width: 55.83%"><a href="https://makerworld.com/en/models/1562133-strong-fishing-rod-belt-holder#profileId-1641833" target="_blank" rel="noopener noreferrer ugc"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000488945/design/2025-06-30_5d341a558222a8.jpg"></a></figure>&nbsp;

Fishing tripod
