1lb Ant Weight Lifter Robot TPU Parts
IP Report
Print Profile(2)
0.2mm layer, 4 walls, 15% infill
Designer
17.8 h
2 plates
0.2mm layer, 4 walls, 15% infill
Designer
20.2 h
3 plates
Open in Bambu Studio
Boost
63
145
16
4
160
33
Released
Description
A new update has been added, being the fastback design. This improvement aids in getting the bot back on its wheels and back in action.
1lb ant weight combat robot. This bot features a powerful lifter and tanky design.
Parts List-
-6x M3 x12mm screws
-8x M3 x20mm screws
-2x M2x12mm screws
-2x M2 nuts
-14x M3 Threaded heatset inserts
-1x NSDRC RS100 micro servo
-1x NSDRC 8.4v micro Bec
-1x NSDRC 3m threaded micro servo horn
-1x Repeat Robotics ant weight drive bundle w/ 4mm shafts
-1x Fingertech power switch
-1x Fly Sky FS2A receiver
-1x Tattu 450mah 75c 3s Battery
-2x Just Cuz Robotics Flanged Hubs 4mm
-18 gauge wire
-1x xt30 connector pair
-Heat shrink
-Semi-perinate thread locker
