4" Aroid Pot — Aroid/Orchid Pot + Drip Saucer

IP Report

Print Profile(1)

All
H2S
A2L

0.24mm layer, 3 walls, 0% infill
0.24mm layer, 3 walls, 0% infill
Designer
3.2 h
1 plate

Open in Bambu Studio
Boost
4
10
0
0
3
3
Released

Description

A 2-piece system for aroids — designed for any high airflow requirement plants. Print in clear PETG to watch root development and moisture levels.

🌿 The Pot (4" / 102mm rim, 110mm tall, ~0.55L)

  • Hollow central air cone (55mm) open to the underside with 6 vents — air feeds straight into the root zone, no soggy core
  • 45° funnel floor drains everything to an 8-slot ring around the cone — zero standing water in the media
  • 5 arched feet let air in and water out even on a flat surface
  • 12 side vents at 4.5mm — walls breathe, sphagnum stays put

💧 The Saucer (122mm)

  • Internal pedestal ring holds the pot 5mm above standing water so the media can't wick from the tray — ~50ml runoff buffer

🖨️ Printing

  • Zero supports on all three parts, print as-oriented
  • Clear/translucent PETG, 0.2mm layers, 0.4 nozzle
  • Pot: 3 walls (~60g) · Saucer: any (~53g)
  • ~115g total
