📦 **Ultimate Parametric Drive Belt Engine (Bilingual Customizer)** 📦 Easily create custom timing belts and drive belts for your 3D printers, robotics, and engineering projects! Fully optimized for TPU printing 💡 **Key Features:** • **Industry Standard Profiles:** Supports GT2 (2mm, 3mm, 5mm), HTD (3mm, 5mm), XL, L, MXL, T2.5, T5, T10, and AT5 • **Authentic Geometries:** Correct pitch-line differential (PLD) calculation and rounded/trapezoidal tooth shapes for perfect pulley engagement • **Two Modes:** Generate endless circular loops or straight linear belts (open length) • **Double-Sided Option:** Supports Inside, Outside, or Double-sided teeth • **Fully Customizable:** Easily tweak width, tooth count, pitch, and backing thickness 🛠️ **Printing Tips:** • **Material:** Highly recommended to print with 95A or 98A **TPU** (Flexible filament) • **Walls/Infill:** Use 3-4 walls and 100% infill for maximum tensile strength • **No Supports:** Designed to print cleanly without any support material
