SMK Z0Z6 version 2.1

You may create derivative works based on this object, provided that all such derivative works are published exclusively on the MakerWorld platform and include proper attribution to the original creator. You may not share, upload, host, distribute, or publish this object—or any derivative work of this object—on any other digital platform, marketplace, or distribution channel. Commercial use of this object and any derivative works is strictly prohibited. This includes, but is not limited to, selling, renting, sublicensing, or using the object in any context in which you receive monetary compensation or other financial benefits.

This user content is licensed under the MakerWorld Exclusive License.

<p><strong>Leichter FPV Racer Frame für 20x20 &amp; 30x30 Stack</strong></p><p>&nbsp;</p><h2>Features</h2><ul><li>Vollständig 3D druckbarer FPV Frame</li><li>Kompaktes Hauben-Design</li><li>20x20 Stack Aufnahme</li><li>30x30 Stack Aufnahme</li><li>Für leichte Analog -Builds geeignet<ul><li>mit der hohen Canopy Version sind auch kleinere digitale vtx möglich (dji 04 lite &amp; Walksnail 1s kit)</li></ul></li><li>Modulare Konstruktion</li></ul><p>&nbsp;</p><h2>Empfohlene Hardware</h2><ul><li>20x20 FC / ESC Stack (z.B speedy bee f405 20x20)</li><li>Leichte Motoren (z.B 2207)</li><li>Analoge VTX Systeme (z.B speedy bee tx800/tx1600)</li><li>Digitale VTX Systeme (z.B Walksnail 1s lite)</li></ul><p>Große VTX-Systeme können zusätzliche Kühlung oder angepassten Airflow benötigen.</p><p>&nbsp;</p><h2>Druckempfehlungen</h2><p>Empfohlene Materialien:</p><ul><li>PETG</li><li>PLA</li></ul><p>Empfohlene Einstellungen:</p><ul><li>4–6 Wände</li><li>Hoher Infill</li><li>Langsame Außenwände für bessere Qualität</li></ul><h2>Nötiges Zubehör</h2><p>niedrige Version des Canopys mit variablen  Kamera Winkel (https://makerworld.com/de/models/2805605-canopy-fur-fpv-racer#profileId-3121874)</p><p>höhere Version des Canopys mit variablen Kamera Winkel    ()</p><h2>Status</h2><p>V2 Prototyp</p><p>&nbsp;</p><p>Flugtests und weitere Updates folgen.</p><p>für durch den Flug entstehende Schäden übernehme ich kein Haftung</p><p>&nbsp;</p>

<p><strong>Lightweight FPV Racer Frame for 20x20 &amp; 30x30 Stack</strong></p><p>&nbsp;</p><h2>Features</h2><ul><li>Fully 3D printable FPV Frame</li><li>Compact canopy design</li><li>20x20 Stack mounting</li><li>30x30 Stack mounting</li><li>Suitable for lightweight analog builds<ul><li>with the high canopy version, smaller digital VTXs are also possible (DJI O4 Lite &amp; Walksnail 1s kit)</li></ul></li><li>Modular construction</li></ul><p>&nbsp;</p><h2>Recommended Hardware</h2><ul><li>20x20 FC / ESC Stack (e.g. SpeedyBee F405 20x20)</li><li>Lightweight motors (e.g. 2207)</li><li>Analog VTX systems (e.g. SpeedyBee TX800/TX1600)</li><li>Digital VTX systems (e.g. Walksnail 1s Lite)</li></ul><p>Large VTX systems may require additional cooling or customized airflow</p><p>&nbsp;</p><h2>Print Recommendations</h2><p>Recommended materials:</p><ul><li>PETG</li><li>PLA</li></ul><p>Recommended settings:</p><ul><li>4–6 walls</li><li>High infill</li><li>Slow outer walls for better quality</li></ul><h2>Required Accessories</h2><p>low version of the canopy with variable camera angle (https://makerworld.com/en/models/2805605-canopy-fur-fpv-racer#profileId-3121874)</p><p>higher version of the canopy with variable camera angle    ()</p><h2>Status</h2><p>V2 Prototype</p><p>&nbsp;</p><p>Flight tests and further updates to follow</p><p>I assume no liability for damages caused by flight</p><p>&nbsp;</p>

FPV Racer Berlin Z0Z6 | 20x20 & 30x30 Stack
