Small Container Light
Print Profile(1)
Bill of Materials
Description
“Small Container light”
The transparent, diffuse lamp housing and the spiral LED strip mounting perfectly distribute the light throughout the entire lamp
This lamp, approximately 18 cm high and 10 cm wide, features a container design and consists of 9 parts. An LED strip with a maximum width of 10mm can be glued spirally to the internal connecting rod to evenly distribute the light. I used the 6500K White LED Light Strip (1pcs) - KA004 kit from Bambu Lab for this
The lid is attached using a twist lock mechanism. It fits quite snugly and requires a bit of force to turn. The two screws for the handle and the upper inlay are secured with a drop of superglue. The handle remains pivotable
I recommend printing with supports, as indicated in the profile. I printed the transparent part very slowly, at approximately 50mm/s for both inner and outer walls, to achieve maximum transparency
Boost Me (for free)
If you like my work, I would appreciate a boost. Thanks in advance
