Oman License Plate Keychain - Customizable

🌟 Design Features:

• 🔢 Full Customization: Enter your plate number and Arabic and English letters, and they will immediately appear in the design
• 🎨 Plate Types: Choose your plate type (Private 🟡, Commercial 🔴, or Test 🟢). Colors change automatically in the preview!
• 🖋️ Font Styles: We have provided you with the new official font and Font 2 (classic) for the word "Oman"
• ⚙️ Extreme Precision: Letters and spacing are engineered to fit the printing nozzle (0.4mm Nozzle) ensuring clear and clean details
• 🔑 Strong Keychain Loop: We designed a durable loop integrated with the base, and you can choose its position in any corner you like (right, left, top, bottom) 🔄

🛠️ How to Design Your Keychain (Customization Method):

1. Click the Customize 🖱️ button on the page
2. In the text field, enter your preferred plate number and letters
3. Choose the plate type (to adjust the colors accordingly)
4. Choose the font style for the word "Oman" according to your preference
5. The site will prepare a custom STL file for you, download and print immediately! 📥

Here is a detailed "field by field" explanation for the Oman plate customizer program, written in a style that helps the user understand the function of each option and how to adjust it to get the best result

🛠️ Oman Vehicle Plate Settings Guide (Step-by-Step Guide)

Here is a detailed explanation for each field that appears in the modification menu, and how it affects the final shape of the keychain:

1️⃣ Field: Structural Dimensions

This field controls the actual size and strength of the keychain

• Total Width: The total width of the keychain in mm. (The ideal size for keychains is 80-100 mm)
• Total Height: The height of the keychain. (The ideal size is 25-30 mm)
• Base Thickness: The thickness of the plate base. We recommend 3 mm to ensure the keychain does not bend or break
• Border Width: The thickness of the outer frame surrounding the plate; it gives strength to the keychain and an official aesthetic shape

2️⃣ Field: Plate Type & Colors

This field is dedicated to defining the official plate classification, and it changes the colors in the "Preview" to help you visualize the final result before printing:

• Plate Type: You can choose from the list of only 3 types:
  • Private: Displays the base in yellow (for printing with black filament for letters)
  • Commercial: Displays the base in red (for printing with white filament for letters)
  • Test: Displays the base in green (for printing with white filament for letters)
• Preview Mode: An option to enable or disable colors in the software; to ensure clear visibility of letter details before exporting

3️⃣ Field: Plate Content

This field is used to enter the text that will appear on the keychain

• Plate Number: Enter the plate numbers here (e.g., 7896)
• Arabic Letters: Enter the Arabic letters (e.g., ب ب)
• English Letters: Enter the corresponding English letters (e.g., B B). They will automatically appear below the Arabic letters in a consistent manner
• Don't forget to put a space between each letter if the number contains two letters

4️⃣ Field: Oman Branding Style

This field controls the official word on the side of the plate to ensure its accuracy:

• Font Style: Allows you to choose between two styles for the word "Oman":
• Official: The official font is similar to the one currently adopted in new Omani plates
• Font 2 : Font 2 is another font of our personal design

• The Official Font
• Font 2

5️⃣ Field: Keychain Loop

Related to the keychain's hanging location and method

• Add Keychain Hole: (Enable/Disable) to add a circular loop for hanging keys
• Hole Diameter: The diameter of the loop hole. (3.5 mm is suitable for most chains)
• Hole Offset: Controls the distance of the hole from the corner; make sure to leave enough space so that the keychain corner does not weaken and break

💡 Tip for Users:

Once all fields are adjusted, make sure to select "Preview" to check, and if all letters are clear with no overlap, click "Render" then download the STL file for printing

🖨️ Printing Instructions (for best results):

• nozzle: 0.4mm 📏
• Layer Height: 0.2mm
• Filament Swap: 🌈
  • Start with the base color (e.g., yellow for the private plate)
  • Place a "pause" or "filament change" at a height of 3.2mm to print the text in the second color (e.g., black)
• Infill: 15% to 20% (the design is sturdy and doesn't require much)

🔥 Don't forget to share a picture of your printed keychain in the comments! 🔥 Your support with a Like and Download encourages us to publish more Omani designs! 😇🙌
