T-Track Low Profile CNC Table Clamp - 1/4-20
Print Profile(2)
Bill of Materials
Description
I went through a bunch of different revisions and like this one the best. Accommodates ¾ and ½ plywood with and without 1/8" spoiler board. Just supply a ¼-20 hex bolt or T-bolt and cut to size.
I added a keychain hole and a spot for (2) 10x3 neodymium magents for easy storage of the tightening tool.
Latest rev can use either PLA or PETG HF. I also add a locking washer so it stops the clamp from sliding when tightened down.
Boost Me (for free)
Thanks for looking and happy printing!
