SolidWorks Gridfinity Baseplate - No Magnet Holes

Gridfinity baseplate • SolidWorks parametric design

This SolidWorks part file lets you generate any Gridfinity baseplate size using simple width/length parameters — no rebuild errors, no broken features, no guesswork. I designed this because every other parametric SW baseplate I found failed when changing dimensions, so this model is built cleanly, robustly, and fully compliant with the Gridfinity spec.

The design is intentionally minimalist with no underside extrusion, making it ideal for:

• Laying into drawers or tool chests
• Integrating into larger assemblies
• Embedding into custom organizers or multi‑part builds

Included in the download:

• SolidWorks part file (fully parametric)
• Pre‑generated 3MF baseplates from 1×1 to 5×5

Perfect for makers who want to build custom Gridfinity bins, tool organizers, or modular storage systems without fighting broken CAD features.

Note that MakerWorld won't let me upload more than one SolidWorks part file per listing, so I had to split this design into three listings.

• Here is the Gridfinity baseplate with magnet holders
• Here are the parametric design and 3MF for Gridfinity bins

I'm happy to make adjustments if you need something. I'm also interested to learn how you use this design.

We love to see your creations and how you use ours. Please share pictures :)
