Summary

Want a cross section showing the moment an allied 37mm armor piercing round hits a German Panzer IV tank? This is a realistic replica depicting the side armor of a Panzer IV being struck by an anti-tank round.

Bambu filaments used

Inner Armor
- Matte Desert Tan
Middle Armor
- Metal Iridium Gold
- Metal Copper
Outer Armor and Iron Cross
- Basic Light Gray
- Matte Black
- Polymaker Metallic Chrome (Amazon link)
37mm Round
- Metal Iron Gray Black
- Sunlu Silk Red Copper (Amazon link)
- GiantArm Silk Gold (Amazon link) for the Gold Casing if you print the separate 37mm round and casing

Assembly

Panzer IV Tank Armor

Connect the 3 pieces together with the 4 pegs provided. Note that the flat part with no knarled edge should be on the bottom – use that edge to ensure you have each piece rotate in the right position.

37mm Round

Simply screw together the 3 parts, that's it. If you decide to print the optional round with casing, then the only remaining step is to insert the black/copper round shown below into the gold casing.

Boost Me (for free)

If you enjoy my work and would like to help support my ability to share more (and even better) models in the future, please consider boosting or buying me a coffee at the link below. Your support is what helps me have enough filament and supplies to do all the print testing required for my models to be high quality and easy to assemble. It takes a mountain of test prints for each model. Thanks :-)

Here's a link to my Buy Me a Coffee page, thanks for the support!

( ! ) Do not sell my prints — I have not authorized selling prints. If you sell my prints on Etsy, Amazon, eBay, etc, I will find out.

This 3D print is intended for decorative purposes only and is not suitable for children. Small parts may present a choking hazard and edges may be sharp. By printing this 3D print, you assume all liability for any harm to yourself or others resulting from its use.
