This profile is optimized for reliable, support-free printing in PETG.The model is designed to print cleanly with no supports required. A brim is recommended to improve bed adhesion, especially on printers prone to edge lift or when printing with PETG.For standard use, 20–30% infill provides a good balance of strength and material usage. If you require a completely solid part for maximum durability and airtight performance, 100% infill can be used.PLA can also be used as an alternative material—just be sure to adjust your print temperatures accordingly. Keep in mind that PETG is recommended for better heat resistance, especially in enclosed or warm environments.Print flat on the build plate for best results.

0.2mm layer, 2 walls, 15% infill

Trickle Vent Exhaust Adapter With Quick Disconnect

Doyley

Quick Disconnect Fittings Finished.gif








&nbsp;Window Trickle Vent Adapter Kit – 75 mm Printer Exhaust (Quick Disconnect System)This kit converts a standard window trickle vent into a clean, secure exhaust outlet for your 3D printer. Designed specifically for 75 mm hose systems, it uses a quick‑disconnect coupling so you can attach or remove your exhaust line in seconds without tools. Perfect for users who vent PLA/PETG fumes outdoors and want a tidy, reliable, low‑leakage setup.It can be used without the quick disconnect; just clamp your pipe directly to the vent elbow.<h3>What’s Included</h3><ul><li>Main Trickle‑Vent Adapter – precision‑fitted geometry for common UK window trickle vents</li><li>Quick‑Disconnect Hose Coupler – twist‑lock design for fast attachment and removal</li><li>Retaining Disc / Inner Ring – ensures a tight, rattle‑free fit inside the vent channel</li></ul><h3>Key Features</h3><ul><li>Smooth internal airflow path for reduced back‑pressure</li><li>Strong mechanical joints designed for repeated connect/disconnect cycles</li><li>Print‑friendly geometry with no fragile overhangs</li><li>Optimised for 0.4 mm nozzles and standard PLA/PETG</li><li>Designed for real‑world use: stable, rigid, and tolerant of minor window‑frame variations</li></ul><h3>Printability</h3><ul><li>Supports: enabled, Tree (auto) and tree organic.</li><li>Orientation: as per build blate with flange down to ensure good mating surface.</li><li>Recommended Material: PLA or PETG (PETG preferred for outdoor temperature swings)</li><li>Layer Height: 0.2 mm (can increase to 0.24 to decrease print time by 30 minutes).</li><li>Walls: 2</li><li>Infill: 15%</li><li>Build Plate: Textured PEI recommended for grip and clean underside finish</li></ul><h3>Assembly &amp; Use</h3><ul><li>Attach  the adapter on to the trickle vent opening after the original vent has been removed.</li><li>Attach the quick disconnect fitting to the 75mm exhaust hose using a Jubilee clip/Hose clamp / Worm gear clamp or even a ty-wrap</li><li>Attach your 75 mm hose using the quick‑disconnect coupler</li><li>Twist to lock, twist to release — no clamps, no screws, no fuss</li></ul><h3>Why This Design Works</h3>This adapter solves the common problem of messy, improvised window exhaust setups. The quick‑disconnect system keeps your workspace clean and lets you detach the hose instantly when not printing. The airflow path is tuned for Bambu Lab printers and similar high‑flow systems, ensuring efficient chamber purge and minimal restriction.<a target="_blank" rel="noopener noreferrer ugc" href="https://makerworld.com/en/models/2851844-75mm-trickle-vent-exhaust-kit-90dg-elbow-connector#profileId-3180960">75mm Trickle Vent Exhaust Kit,90dg elbow connector - Free 3D Print Model - MakerWorld</a>

75mm Trickle Vent Kit with 90deg elbow with quick connects

Vent Blank





This end‑cap fitting forms the quick‑disconnect seal for the 75 mm exhaust hose system. It locks onto the main adapter with a smooth twist‑fit action, giving you an airtight connection while still allowing instant removal when the printer isn’t venting. Designed for durability, repeatable use, and clean airflow.<h3>Print Settings</h3><ul><li>Layer Height: 0.2 mm</li><li>Walls: 2</li><li>Infill: 10%</li><li>Supports: Not required</li><li>Orientation: Print face‑down for strongest flange and clean mating surfaces</li><li>Material: PLA or PETG (PETG recommended for warm environments)</li></ul><h3>Features</h3><ul><li>Twist‑lock geometry for fast connect/disconnect</li><li>Thickened rim for long‑term wear resistance</li><li>Smooth internal bore to maintain airflow efficiency</li><li>Compact, low‑profile cap ideal for window‑vent setups</li></ul><h3>Usage</h3>Attach to the hose‑side connector and twist to lock onto the main window adapter. Removes instantly with a quarter‑turn. Perfect for setups where the hose is only connected during printing.

End Cap/Blank for Trickle Vent Exhaust window adapter

You may create derivative works based on this object, provided that all such derivative works are published exclusively on the MakerWorld platform and include proper attribution to the original creator. You may not share, upload, host, distribute, or publish this object—or any derivative work of this object—on any other digital platform, marketplace, or distribution channel. Commercial use of this object and any derivative works is strictly prohibited. This includes, but is not limited to, selling, renting, sublicensing, or using the object in any context in which you receive monetary compensation or other financial benefits.

This user content is licensed under the MakerWorld Exclusive License.

&nbsp;75mm Window Vent Adapter for 3D Printers used on H2D| PETG | No Supports | Easy Install<h3>Description:</h3>This 75mm window vent duct adapter is designed to help vent fumes from your 3D printer safely outside, improving air quality in your workspace.It mounts directly to a standard PVC window breather vent using just two screws and connects to 75mm ducting, making it a simple and effective solution for enclosed or indoor printing setups.Printed in PETG for durability and heat resistance, this model is designed to print cleanly with no supports required, saving time and material.For an improved seal, you can apply 3M double-sided tape or foam tape around the mounting surface to create a simple gasket. This helps reduce air leaks and improves overall ventilation efficiency, especially on uneven window vent surfaces.<h3>Dimensions:</h3><ul><li>Duct inner diameter: 75mm</li><li>Overall size: 232.55mm (L) × 29mm (W) × 112mm (H)</li><li>Mounting hole spacing: 218mm </li></ul><h3>Print Details:</h3><ul><li>Material: PETG (recommended)</li><li>Supports: None required</li><li>Print time: ~4 hours (depending on settings)</li><li>Orientation: Print flat on the bed</li><li>Layer height: 0.2mm</li><li>Infill: 20–30%</li><li>Walls/Perimeters: 3–4</li><li>Bed adhesion: Brim recommended (optional)</li></ul><h3>Features:</h3><ul><li>Fits standard 75mm ducting/vent hose</li><li>Compatible with PVC window vents</li><li>Quick installation with 2 screws</li><li>Strong, heat-resistant PETG construction</li><li>Optimized for support-free printing</li><li>Optional gasket solution using tape for a better seal</li></ul><h3>Use Case:</h3>Perfect for venting fumes from enclosed 3D printers to the outside, helping maintain a cleaner and safer printing environment.
