Universal Premium Coaster Generator

Tired of your glass sticking to the bottom of your coaster and then dropping onto the table? This parametric premium generator solves that problem completely. The raised procedural inner patterns create a functional air gap that prevents suction, while the calculated solid rim catches any condensation or spills before they reach your furniture.

🧠 Behind the Design (For Makers & Moderators)

This is a fully parametric OpenSCAD engineering tool, not a basic 2D coaster extrusion. The algorithm dynamically calculates complex fluid-dynamic air gaps using advanced mathematics such as utilizing sqrt(3)/2 and modulo operators for staggered isometric honeycomb matrices, and calculating radial ray distribution using PI for sunburst topologies. Furthermore, it executes precise multi-level boolean operations (difference() and intersection() with micro-offsets for manifold geometry) and utilizes dynamic ternary operators for the Z-axis offset to ensure custom typography is debossed perfectly flat, guaranteeing structural stability for glassware.

🛠️ What can you customize?

• Dimensions: Adjust the diameter for standard glasses, giant coffee mugs, or oversized beer cans.
• Rim control: Make the outer edge higher to catch more spills, or wider for a chunky, modern look.
• Personalized text: Type any name or word to make custom gifts. The text is subtracted cleanly from the top surface for perfect stability.
• Anti-stick patterns: Choose between 9 distinct styles.
  • Plain (Standard flat bottom).
  • Hexagon (A premium honeycomb grid).
  • Concentric rings (Classic, clean circles).
  • Sunburst (Radial lines pointing towards the center).
  • Square grid (A sleek, orthogonal matrix).
  • Diamonds (A 45-degree angled luxury grid).
  • Triangles (An isometric pattern for a modern touch).
  • Crosshatch (A clean, woven look).
  • Spiral (A mesmerizing Archimedean swirl).
• Pattern depth & spacing: Fine-tune the thickness of the lines to perfectly match your aesthetic.

🖨️ Print settings
This is a fast, support-free print that works on any machine.

• Material: PETG, ABS or ABS/ASA are recommended if you drink hot coffee. PLA works perfectly fine for cold drinks.
• Two-color text (No AMS required): Add a pause at the layer where the text engraving starts. Swap to a contrasting color (like black on white) so your custom name pops out beautifully from the recess.
• Infill: 15% to 20%.
• Top surface: Enable “Ironing” for the topmost surfaces to give the rim, pattern, and center block a sleek, injection-molded feel.

❤️ Show your setup
Did you make a custom set for your living room or a personalized gift? I would love to see which pattern and name you chose! Please upload a photo in the reviews. If you give permission I will add it to the model gallery.

Happy printing!
