Minimalist Kitchen Bottle Organizer

📝 Description

Bring order and style to your kitchen!

This storage container was designed to put an end to the chaos on your kitchen counter. Whether it's vinegar, oil, syrup, or wine bottles – this model ensures a uniform look and a structured presentation on your countertop or shelf.

Highlights:

• Minimalist Design: Fits perfectly into any modern kitchen.
• Stability: The robust wall thickness ensures that even heavy glass bottles stand securely.
• Versatile: Perfect for standard bottles (oil, vinegar, drinks) up to a diameter of 97 mm.
• Cleanliness: Protects surfaces from oil residue or ring formation on the bottom.

📏 Technical Details & Dimensions

To ensure the model fits your shelf, here are the dimensions:

• Outer Dimensions: 100.0 mm x 240 mm x 210 mm
• Inner Diameter (Bottle Compartment): 97 mm
• Wall Thickness: 2 mm
• Required Filament: approx. 290 g (including supports)

🖨️ Print Settings

I recommend the following settings for an optimal result:

• Material: PLA (for decor) or PETG (food-safe & more heat-resistant if near the stove).
• Layer Height: 0.3 mm (Standard).
• Infill: 10-15% ("Lightning" recommended for optimal stability).
• Walls: 2 wall loops.
• Support: Required.

💡 Assembly & Tips

1. Cleaning: Since it is used in the kitchen, I recommend wiping the model with a damp cloth occasionally. (Do not put it in the dishwasher if printed in PLA!).
2. Anti-Slip: Stick small rubber pads or felt gliders under the base so the organizer doesn't slide on smooth surfaces.

A small request:

If you like the model, I would be very happy about a rating and a photo of your print! It helps me to further improve my designs.
