Rc sport jet edf 50mm flying rc plane

Plane is designed to be printed in vase mode, ensuring highest surface finish, light yet strong print thanks to included internal structures and no additional supports
The plane is not for beginners it's a small fast flying jet to hand launch or bungee launch as you can see from videos.

For Photos of building, tips and tricks and to ask general please join the official discussion:
https://www.rcgroups.com/forums/showthread.php?4091079-super-bandit-50mm-edf-LW-PLA-Maiden-video

Components required:
• 4 x 4.3g servos
• 2 x 40cm servo extension
• EDF 50 mm (powerfan, FMS, Freewing type. Adapter on request)
• 4s 1300 mah battery
• ESC 40A
• Radio and receiver
• 2x 5x10 mm small magnets and velcro for battery hatch
• carbon or steel piano wire for aileron and elevator hinge axle 1.2-1.3mm diameter

• 4x nylon control horns

What you find:

• Slicer settings
• Assembly manual

I will add further revision if necessary, is always a work in progress,

Flight video


Model Specs
• Lenght 900 mm
• Wing span 900 mm
• Weight (incl. battery): 700g
