RXM Plasticcito Grip Module
Print Profile(1)
Description
DISCLAIMER: This is considered an OPEN BETA! I overbuilt the model for safety and heft but I don’t have the huge support network like the big names do, so please reach out if you’d like to share your results, have questions or concerns, or anything else! I’m on FB, IG, X, Discord, Makerworld… I’d love to see your build!
THIS IS NOT A FRAME, IT IS A GRIP! Follow your local laws but this is not governed under the same rules as a normal frame/lower due to the FCU being the serialized part.
RG3D RXM Plasticcito Open Beta
Overview & Changes
Gunder_Mifflin adapted MPMS’s Plasticcatto design to accept the RXM FCU. I built on that work and refined it further.
The compensator was removed along with the thumbrest. Then I added a rail to the bottom for accessories.
I added a printable mag catch that works reliably with the PMAGs supplied with the RXM. Other magazines were not tested—please share compatibility feedback.
All previous Plasticcatto backstraps and magwells from MPMS remain compatible.
Assembly
Assembly is no different than any other grip module. See RXM instruction manual. One of the easiest 3D2A build out there in my opinion. Helpful Tips: Install slide lock spring first. Use a punch/allen wrench from the opposite side to line up the square sided hole with some leverage and carefully push in the pin, it can walk. Then push the rear pin in to lock the FCU in place. Removed the need to use the takedown spring.
BOM
1x) RXM
1x) Glock/rxm mag release spring
1x) M2.5 x 20mm - Back strap
1x) M2.5 x 20mm - Flared magwell
Accreditations
MostlyPeacefulMachineShop - Original Plasticatto Design files and reference cad
https://odysee.com/@TheGatalog-PrintableFramesReceivers:9/PLASTICCATTO:6
Gunder Mifflin - RXM x Plasticatto main conversion work
https://makerworld.com/en/models/1831271-rxm-plasticcatto-grip-module-beta#profileId-1955583
Chairmanwon - RXM Staged Hardware
https://odysee.com/@chairmanwon:a/RXM_Chairmanwon:7
DannyMeatball - Staged Magazine
https://odysee.com/@DannyMeatball:b/DMB-Glock-Mags-(v1.1):1
Recognition for my Makerworld supporters:
@AuxArc @user_3197537916 @Sandstorm.Sys @whitephosphor @Goose72 @Hycinex @CheckersYo @Sundae.Yaris @hurtful @xordac @DiscoKrix @3DPrintThis @SilverCenturion @joshuaterry4504 @user_2979586144 @str8xtc
@Parkwad @LivingInWin @checkers @BigDan13 @RoyaleFeatures @scotchtapeman @user_214879762 @user_3538289637 @3Dinoo @user_1763753541 @WhiteWolfe @user_2060571331 @ssstachu @user_3451143536
@Kneesox @VorpalTempest @DRVNDesign @deesee @user_522956681 @user_3781534920 @ReamusRisen @OldStickyLips @user_450898041 @BKPrintsSome @user145784324 @dryfiredude @user_3446077680 @watson_king
@NomadGunner @user_3890873850 @412jbt @user_2500787994 @userss @user_3890873850 @Tyward514 @tepsley @Pillowheadzz @legendary_soup
@user_1578292560 @MSWTrading @user_39261195 @user_3908544103
License
You may create derivative works based on this object, provided that all such derivative works are published exclusively on the MakerWorld platform and include proper attribution to the original creator. You may not share, upload, host, distribute, or publish this object—or any derivative work of this object—on any other digital platform, marketplace, or distribution channel. Commercial use of this object and any derivative works is strictly prohibited. This includes, but is not limited to, selling, renting, sublicensing, or using the object in any context in which you receive monetary compensation or other financial benefits.
