Cyclone Dust Separator for Vacuum Cleaner (Customizable)
(Now also available in a version that doesn’t require screws)
This is a simple cyclone dust separator designed for easy integration with a vacuum cleaner system.
It helps separate dust and debris before they reach the vacuum, improving filtration and protecting the motor.
🔧 Customizable & Parametric
This model is fully customizable – the download includes an OpenSCAD (.scad) file that allows you to adjust the connector to perfectly fit your vacuum pipe.
📘 Instructions
This model is a parametric tapered sleeve designed to fit different pipe diameters.
The sleeve consists of:
- a fixed external tapered section for easy alignment
- a straight parametric section that fits inside a pipe
🔧 How to customize the model
Adjust the following parameters:
param_inner_d // inner diameter of your pipe param_length // length of the straight section
That’s it — all other dimensions are fixed and calculated automatically.
Perfect for workshop dust collection, DIY setups, and custom vacuum systems.
Assemby 1st version:
