Blank Cover - Volkswagen

This is a high-precision 3D replica of the official Volkswagen dummy button cover (part number 1K0-959-623-D), commonly known as a "blank switch cover" or "dash blank." This component is an authentic OEM fitment designed to cover unused button cavities on the dashboard of various Volkswagen vehicles.

Compatibility:
Compatible with multiple Volkswagen models including:

• Golf Mk6 (2008-2013) and Golf V
• Jetta (Mk5-Mk6)
• VW Beetle (9C1)
• VW Eos
• VW Caddy
• VW Touran and other models featuring the same dashboard architecture from the mid-2000s to early 2010s

Features:

• Accurate 1:1 replica of the genuine Volkswagen OEM part
• Precise dimensions matching the original dashboard cavity fitment
• Black color matching factory standard
• Ultra-fine layer resolution for superior surface finish
• Clean, professional appearance
• Seamless integration with factory dashboard design

Print Settings & Orientation:
The part is already positioned in the project file for optimal print results. For best results, print the file exactly as provided without any modifications or rotations. This orientation has been tested and refined through multiple successful prints and ensures the best surface finish, minimal support material, and highest dimensional accuracy.

Recommended Print Parameters (Bambu Lab P1S with BBL X1C Filament):

Primary Material: PETG Black

• Nozzle Temperature: 240°C
• Bed Temperature: 80°C (dynamic bed leveling enabled)
• Layer Height: 0.08mm (ultra-fine quality mode for exceptional surface finish)
• Print Speed: Standard profile (0.20mm Strength profile settings)
• Infill: 80% (for structural integrity and durability)
• Infill Pattern: Rectilinear
• Wall Loops: 6
• Supports: Enabled with tree supports
• Support Type: Auto-generated (predefined style)
• Support Angle: 25°
• Z-offset Overlap: 15%
• Support Direction: 45°
• Top Surface Pattern: Rectilinear
• Top Layers: 5
• Bottom Layers: 3
• Wall Thickness: 1mm (single wall with 6 perimeter loops)

Note: This configuration uses 0.08mm ultra-fine layer height with the 0.20mm Strength profile parameters for optimal results. All other settings left at standard/default values. This combination has been optimized and validated through multiple successful prints, delivering exceptional detail and finish quality.

Alternative Materials:

• ABS or ASA (for increased UV resistance and durability in high-temperature environments)
• PLA (not recommended for automotive interior use due to lower temperature resistance)

Use Cases:

• Direct replacement for cracked, missing, or damaged OEM dummy covers
• Customization of Volkswagen interiors
• Restoration projects
• Parts replacement for vehicles where the original cover is unavailable or costly
• Dashboard cavity coverage for a clean, factory-finished look

Notes:
This is a non-functional decorative component designed to improve interior aesthetics and protect dashboard cavities from dust and debris. It snaps into place using standard Volkswagen dashboard bracket systems. No electrical connections required.

Assembly:
Simply snap the dummy cover into the corresponding dashboard cavity—no tools or modifications needed. It aligns perfectly with the factory opening without additional fasteners.
