Description
Content has been automatically translated.
the new and improved version of the superburner,
Important details regarding the previous version:
now uses 2 5015 fans for greater airflow
the hotend has been changed, it is now a TZ V6 2.0/3.0
the belt grippers can now be attached and removed more easily as they use screws instead of glue
the printhead is now much lighter, allowing faster movements
Required materials:
TZ V6 2.0/3.0 hotend
Sprite Extruder SE
1 4010 fan
2 5015 directed fans
1 Teflon tube about +-6cm
a box of M3 screws
3 M5 screws
2 sleeves with internal M5 hole
eccentric nut with internal M5 hole
3 wheels for T-profiles
3 M5 lock nuts
60g of filament (recommended to use PETG or PET)
That's all
happy printing
